XLT Ovens H3E-1832 Series Installation & Operation Manual

Gas oven & hood
Hide thumbs Also See for H3E-1832 Series:
Table of Contents

Advertisement

Quick Links

XLT Gas Oven & XLT Hood
Installation & Operation Manual
Read This Manual Before Using This Appliance.
Current versions of this manual, Technical/Rough-In Specifications, Parts & Service Manual, Fire
Suppression Installation, Architectural Drawings, & a list of International Authorized Distributors
For use with the following XLT Gas Oven Versions:
Standard (S)
H
Original Instructions
US: 888-443-2751 FAX: 316-943-2769
are available at:
www.xltovens.com
For use with the following XLT Gas Hood Versions:
Standard (S)
2000887
XLT Ovens
PO Box 9090
Wichita, Kansas 67277
INTL: 316-943-2751
XD 9004A
SHHE
01/02/2020
E
WEB:
www.xltovens.com
