HIKVISION Network Camera User Manual

Hide thumbs Also See for Network Camera:

User manual (165 pages)

User manual (46 pages)

User manual (44 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual See also: User Manual

Network Camera

User Manual

V3.0.3

Hikvision Digital Technology Co., Ltd.

http://www.hikvision.com

Table of Contents

Need help?

Do you have a question about the Network Camera and is the answer not in the manual?

Questions and answers

Summary of Contents for HIKVISION Network Camera

Page 1 Network Camera User Manual V3.0.3 Hikvision Digital Technology Co., Ltd. http://www.hikvision.com ...
Page 3 EU Conformity Statement This product and ‐ if applicable ‐ the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC. 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 4 User Manual of Network Camera Safety Warnings and Cautions Please pay attention to the following warnings and cautions: Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by employees from our company with knowledge and training in working with these types of devices that contain live circuits. Power Supply Hazardous Voltage: AC mains voltages are present within the power supply assembly. This device must be connected to a UL approved, completely enclosed power supply, of the proper rated voltage and current. No user serviceable parts inside the power supply. System Grounding (Earthing): To avoid shock, ensure that all AC wiring is not exposed and that the earth grounding is maintained. Ensure that any equipment to which this device will be attached is also connected to properly wired grounded receptacles and are approved medical devices. Power Connect and Disconnect:The AC power supply cord is the main disconnect device to mains (AC power).The socket outlet shall be installed near the equipment and shall be readily accessible. Installation and Maintenance:Do not connect/disconnect any cables to or perform installation/maintenance on this device during an electrical storm. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 5 This device includes a battery which contains perchlorate material. Taiwan battery recycling: Please recycle batteries. Thermal and Mechanical Injury:Some components such as heat sinks, power regulators, and processors may be hot; care should be taken to avoid contact with these components. Electro Magnetic Interference:This equipment has not been tested for compliance with emissions limits of FCC and similar international regulations. This device is not, a nd may not be, offered for sale or lease, or sold, or leased until authorization from the United States FCC or its equivalent in other countries has been obtained. Use of this equipment in a residential location is prohibited. This equipment generates, uses and can radiate radio frequency energy wh ich may result in harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipmen t on and off, the user is required to take measures to eliminate the interference or discontinue the use of his equipment. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 6 3. Do not connect several devices to one power adapter as an adapter overload may cause over‐heating and can be a fire hazard. If use the POE as the power supply, please make sure that the POE Switch have th e sufficient power .(Whether supporting PoE power supply lies on the specific camera model) 4. Please make sure that the plug is firmly inserted into the power socket. 5. When the product is installed on a wall or ceiling, the device should be firmly fixed. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 7 User Manual of Network Camera 6. If smoke, odor, or noise rise from the device, turn off the power at once and unplug the power cable, then contact the service center. 7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We sh all not assume any responsibility for problems caused by unauthorized repair or maintenance.) © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 8 The average time varies because of differences between operating environment and usage history, so regular checking is recommended for all users. Please contact with your dealer for more details. 10. Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 9: Table Of Contents
2.2 Access over Client Software ................29 2.2.1 Live View ....................29 2.2.2 Camera Parameters Configuration ............30 2.2.3 Wireless Parameter Configuration ............34 Chapter 3 Access over Internet ................... 35 3.1 Access network camera with static IP ............. 35 3.2 Access network camera with dynamic IP ............36 Appendix 1 SADP Introduction..................40 Appendix 2 Port Map ....................42 Appendix 3 Pin Definition ................... 44 © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 10: Chapter 1 Network Camera Connection
User Manual of Network Camera Chapter 1 Network Camera Connection 1.1 Cable Network Two methods can be used to connect between network camera and PC, shown as below: Figure 1.1.1 Cross Line Connection Figure 1.1.2 Direct Line Connection 1.2 Wireless Network Note: This section is only for wireless network camera with mark '‐W' in the model number. Figure 1.2.1Point‐to‐point Communication Through Wireless Network Figure 1.2.2 Communication Via Wireless Switching Equipment © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 11: Network Connection
Figure 1.3.1 Select the device, and set its IP address and mask at the same network segment with the PC. For the detailed introduction of SADP, please refer to Appendix 1. Note:The network camera is set with the factory default IP address of “192.0.0.64”, the port of “8000”, the super user name of “admin” and the password of “12345”. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 12: Chapter 2 Network Access
Figure 2.1.1 Adjust the Security Level 2.1.1 Live View Step 1:Install Active‐XControl Type the IP address of the network camera and press Enter, then the ActiveX mention dialog will pop up. Click Install to install the ActiveX control. Figure 2.1.2 Install the ActiveX Control © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 13 Capture Picture Start/Stop Record Digital Zoom Video Parameters Digital Zoom : Click mouse in the desired position of live video image and scroll the mouse to realize zoom in and zoom out function. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 14: Parameters Configuration
Figure2.1.5 Video Parameters different camera models. 2.1.2 Parameters Configuration Click Configuration to enter the Parameters Configuration interface. 2.1.2.1 Local Configuration Figure2.1.6 Local Configuration © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 16 Figure2.1.8 Display Settings transparent &unflickering, nontransparent & flickering, or nontransparent &unflickering. Channel ParametersVideo Settings: Figure2.1.9 Video Settings Parameter Description Channel Name Input the channel name for your need © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 17 Figure 2.1.10 Schedule Record If video is required to record in different time sections, select Pre Record: “No PreRecord”, “5 s”, “10 s”, “15 s”, “20 Section Recording and set the s”, “25 s”, “30 s” optional. Start Time and End Time. There Post Record: “5 s”, “10 s”, “30 s”, “1 min”, “2 min”, “5 are up to 4 sections available. min”, “10 min” optional. Select the checkboxes below “Copy To:” to copy this Note: The time of each segment day’s settings to whole week or some days in one can’t be overlapped. week. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 19 Figure2.1.14 Front Parameters Config There are two modes: IrisFirst and manual optional. Power Mode: There are two modes: 50Hz and 60Hz optional. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 22 Figure 2.1.20 NTP Settings Click "Save" button to save the modified parameters. Note: Please reboot the network camera to validate the modified parameters. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 25 Figure2.1.27 Alarm Deployment Time modified parameters. Settings User Management: Figure 2.1.28 User Management When the current login user is admin, it is allowed to create other users. Up to 15 users can be © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 26 Figure 2.1.30 Modify User Note: Only the password of the user admin can be modified. HDD management Figure 2.1.31 HDD management In this page, user is allowed to view the hard disks’ No., capacity, remaining memory and working status, as well as format the hard disks. Item Description HDD No. Hard disk’s serial number. Capacity(MB) Hard disk’s total capacity. Free Space(MB) The remaining memory of the hard disks. Status The working status of the hard disks. Format Select the hard disk you want to format and press this button. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 27 Figure 2.1.33 Restore Default except IP address, subnet mask, gateway and port. Reboot Device: Click OK to reboot the network camera. Figure 2.1.34 Reboot Device © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 28 Figure 2.1.37 Please refer to “Client Software‐4000(v2.0)_ENG.pdf” for a more detailed parameters configuration. You can find the document in the PC Operating System after the installation of client software 4000 v. 2.0 by selecting “Start”‐> “All Programs”‐> “client software 4000 v. 2.0”. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 29: Wireless Parameters Configuration
IP address in the same network segment as the IP address of wireless network camera. Select "View Wireless Networks" in the computer's "Wireless Network Connection". Find the device which has the same name as the SSID number of the wireless camera. Then point‐to‐point communication through wireless network is established successfully. So, there is no need to use an Access Point (AP) between the PC and wireless network camera. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 30: Access Over Client Software
If users need to enable encryption, select the appropriate encryption type and set the corresponding encryption parameters. In the remote parameter settings interface, select "WiFi parameters"‐> "Wlan Settings" to enter the Wlan settings interface, as shown in Figure 2.1.39. Figure 2.1.39Wlan Settings Interface In the "Wlan settings" interface, user can set the wireless network camera's parameters like wireless IP address, subnet mask, gateway and DNS server address, etc. Unplug the network cable from wireless network camera. The wireless network camera now can be accessed through wireless network after the related network parameters have been set. The way that accesses to wireless network camera through wireless network is similar to cable network. Refer to section 2.1. 2.2 Access over Client Software Please refer to “iVMS‐4000(v2.0) introductor.pdf” for detailed client software installation. You can find the document in the PC Operating System after the installation of client software 4000 v. 2.0 by selecting “Start”‐> “All Programs”‐> “iVMS 4000( v. 2.0)” ‐> “iVMS 4000( v. 2.0)”. 2.2.1 Live View Right click to add devices in the setup interface of client software. Please refer to “iVMS‐4000(v2.0) introductor.pdf” for more detailed device added process. You can find the document in the PC © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 31: Camera Parameters Configuration
“Config Sensor Parameters”. If the information in the actual interface of “Config Sensor Parameters” is not different from the information shown in this section, then subject to the actual interface information. For viewing better image, you can set the parameters of the camera, and operate as following: © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 32 [ConfigSensor Parameters…] box will pop up. Figure 2.2.2 Sensor Parameters Step 2: Video Parameters Configuration Adjust the value of “Brightness”, “Contrast”, “Saturation”, “Hue”, “Sharpness” and “Gain”for your need, which can be set from 1 to 100. Figure 2.2.3 Video Parameters Step 3: White Balance Configuration Select the mode to Auto1 or Off for yourneed. Figure 2.2.4 White Balance © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 35: Wireless Parameter Configuration
“Remote Configuration” to enter the remote configuration interface. The way to configure the parameters in the client software is the same as the way in IE browser. Please refer to section 2.1.3 for more detailed parameters configuration. Figure 2.2.11 Client Software Wireless Configuration Interface © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 36: Chapter 3 Access Over Internet
When there is a static IP from an ISP, open some ports (such as 80 and 8000 ports) in the router. Then a user can visit it through a web browser or client software via the internet. The steps for port forwarding are different for each model of router. Please call the router manufacturer for assistance with port forwarding or visit www.portforward.com. Note: Refer to Appendix 2 for a detailed explanation about Port Map. Users can directly connect the network camera to the internet without using a router. Figure 3.1.1 Access IPC through Router with Static IP Figure3.1.2 Access IPC with Static IP directly For the client software to view the camera, in the adding equipment column, select the normal model, and then fill in the IP info. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 37: Access Network Camera With Dynamic Ip
Please restart the network camera after completion of configuration. Then the network camera can obtain a dynamic IP from an ISP operation business. However, the obtained IP address is dynamically assigned via PPPoE, so the IP address always changes accompanied with modem rebooting. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 38 If the camera connects to the internet via a router, users should port forward the router. Please refer to Appendix 2. Input domain names in the client software or IE to view the network cameras. Take the client © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 40 IP address to the resolution server. When the client software connects to the network camera, it will connect to the resolution server and tell the resolution server the expected camera’s name. And the server will find the camera from all the registered cameras and send its IP address to the client software. Once the client software gets the IP address, it can connect the network camera. Figure 3.2.6 Selecting Private Domain Mode © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 41: Appendix 1 Sadp Introduction
2. Search active devices online After installing WinPcap, double click sadpdlg.exe. The software will start to search active devices in LAN, and device type, IP address, Port number, Device Serial No., subnet mask, MAC address, the number of channels, main control and encoding version and device initiating time are showed in the list, as following: 3. Modify device information Select the device that needs modification in the device list, then basic information of the device will be demonstrated in the information column on the right. Click “modify” button to activate IP address, subnet mask, device port editing and password validating box, as follows: Select the device that needs modification in the device list, then basic information of the device will be demonstrated in the information column on the right. Click “modify” button to activate © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 42 User Manual of Network Camera IP address, subnet mask, device port editing and password validating box, as following: Input new IP address, subnet mask, and port number, and click “save” button. If a dialog pops up, showing “saved successfully”, that means you have modified the configuration information; if “saving failed” turns up, click the “cancel” button to quit it. 4. Recover default password You can reset the password of the super user as “12345” in the case of a lost password. Input certain validation code into the ‘Resume default password’ box, and click ‘OK’ to finish the administrator’s password initiating. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 43: Appendix 2 Port Map
2. Set the “network parameter” of the router as the below figure. The setting includes subnet mask and gateway. 3. Set the port map in the virtual severs of Forwarding. By default, camera uses port 80, 8000, 554 and 8200. You can change these ports value with IE or client software. The following figure gives the illustration. One camera’s ports are 80, 8000, 554, 8200 and its IP address is 192.168.1.23. The other camera’s ports are 81, 8001, 555, 8201 and IP is 192.168.1.24. Afterwards, enable all or TCP protocols. Enable the port map after pressing the ‘Save’. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 44 As the settings mentioned above, map the router’s port 80 and 8000 to the network camera at 192.168.1.23; and port 81 and 8001 to the network camera at 192.168.1.24. In this way, user can access the 192.168.1.23 through accessing the router’s port 80 and 8000. Note: The port of the network camera cannot conflict with other ports. For example, some router’s web management port is 80. User can amend the router’s or the camera’s port to solve this problem. © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
Page 45: Appendix 3 Pin Definition
User Manual of Network Camera Appendix 3 Pin Definition (1)UTP between the network port of camera and HUB (Direct Cable) (2)UTP between the network port of camera and PC (Cross Cable): © Hikvision Digital Technology Co., Ltd. All Rights Reserved. ...
