  • Page 1: Network Camera

    Network Camera User Manual V3.0.0 Hangzhou Hikvision Digital Technology Co., Ltd. http://www.hikvision.com 2010-04...
  • Page 2 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to Network Camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.

  • Page 3: Safety Instruction

    7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 4 The average time varies because of differences between operating environment and usage history, so regular checking is recommended for all users. Please contact with your dealer for more details. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 5: Table Of Contents

    2.2.2 Live View ....................21 2.2.3 Sensor Parameters Configuration ............24 Chapter 3 Access over Internet .................. 28 3.1 Access network camera with static IP ............28 3.2 Access network camera with dynamic IP ..........29 Appendix 1 SADP Introduction ................... 33 Appendix 2 Port Map ....................

  • Page 6: Chapter 1 Network Camera Connection

    Fig. 1.1 Cross Line Connection Fig. 1.2 Direct Line Connection Before visiting network camera over network, user should acquire its IP address first. SADP is a software tool which can automatically detect Hikvision’s network device in the LAN and give the device’s information like IP address, mask, port number, device serial number, software version, etc.,...
  • Page 7 For the detailed introduction of SADP, please refer to Appendix 1. Note: The network camera is set with the factory default IP address of “192.0.0.64”, the port of “8000”, the super user name of “admin” and the password of “12345”.

  • Page 8: Chapter 2 Network Access

    Open the IE browser, and set the security level to [Low] in [Tools/ InternetOptions/Security/Custom Level...], and enable or prompt Activex Control and Plug-in directly as well. Fig. 2.1.1 Adjust the Security Level Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 9: Live View

    Fig. 2.1.3 Install the ActiveX Control Step 3: Input the “Username” (default: admin), “Password” (default: 12345) and “Port” (default: 8000) of the camera, and then click [Login]. Fig. 2.1.4 Login Interface Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 10 Capture Picture Start/Stop Record Digital Zoom Video Parameters Digital Zoom Click mouse in the desired position of live video image and scroll the mouse to realize zoom in and zoom out function. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 11 Click the functional buttons to realize zoom, Fig. 2.1.7 PTZ Control focus and iris control. Select a preset number and click button to call preset. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 12: Parameters Configuration

    The default directory for saving record files is C: \OCXRecordFiles, which can be modified by user Save captured picture as The default directory for saving captured files is C:\OCXBMPCaptureFiles, which can be modified by user Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 13: Remote Configuration

    Week by clicking the checkbox. Different date formats can be selected. The OSD Status can be set to transparent & flickering, transparent & unflickering, nontransparent & flickering, or nontransparent & unflickering. Fig. 2.1.10 Display Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 14 Select or custom bitrate according to the resolution Multicast Set the multicast address, with the default multicast of 0.0.0.0 RTSP Port Set the RTSP port, with the default RTSP port of 554 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 15 0, 1, 2, 3, 4 and 5. When it is set to 0, the sensitivity is disabled. Linkage: The Linkage method can be selected to either Email link or Trigger alarm output. Fig. 2.1.13 Motion Detection Linkage Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 16 Fig. 2.1.14 Text Overlay Settings Network ParametersNetwork Setting: Set the IP Address, Subnet Mask, Gateway and DNS Server of the network camera. Fig. 2.1.15 Network Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 17 Fig. 2.1.16 PPPOE Settings Network ParametersDDNS Setting: Click the checkbox of Enable DDNS to enable this function. The protocol type can be set to DynDNS or IPServer. Fig. 2.1.17 DDNS Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 18 DynDNS website. Fig. 2.1.18 DynDNS Settings If the protocol type is selected to IPServer, please input the Server Address of the IPServer. Fig. 2.1.19 IPServer Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 19 E-mail address when alarm event occurs. Input the SMTP server, SMTP port, user name, password, E-mail sender and receiver, and finally click Save to finish E-mail settings. Fig. 2.1.21 E-mail Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 20 The alarm deployment time setting is valid only when the camera has already been configured with the motion detection, alarm input and alarm output functions. Fig. 2.1.24 Alarm Deployment Time Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 21 MAC address, and then select user type. Finally, Fig. 2.1.27 Modify User click OK to finish the user modification. Note: The user admin can only be modified with its password. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 22: Advanced Configuration

    Fig. 2.1.29 Restore Default address, subnet mask, gateway and port. Reboot Device: Click OK to reboot the network camera. Fig. 2.1.29 Reboot Device 2.1.2.3 Advanced Configuration Note: This chapter is applicable to professional configuration. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 23 Please refer to “Client Software-4000(v2.0)_ENG.pdf” for a more detailed parameters configuration. You can find the document in the PC Operating System after the installation of client software 4000 v. 2.0 by selecting “Start”-> “All Programs”-> “client software 4000 v. 2.0”. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 24: Access Over Client Software

    Setup’ dialog will automatically pop up as shown n Fig.2.6. Fig. 2.6 Client Software Installation Step 2: Input the User Name and Company Name, and then click Next. Fig.2.7 Customer Information Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 25 Fig. 2.8 Ready to Install the Program Step 4: Click Install to start installation till finishing the installation. Fig. 2.9 Installation Step 5: Click Finish to close the dialog box. Fig. 2.10 Done Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 26: Live View

    “Verification”, and click OK, then user can log in as the administrator. Fig. 2.11 Register Administrator User login: Input “User”, “Password” and click Login to enter the GUI window of the software. Fig. 2.12 User Login Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 27 Fig. 2.14 Device Management Step 3: Right click the left area, and then click Add Area. Input “Area Name” for your need, and then click OK to add area. Fig. 2.15 Add Area Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 28 Select “TCP”, “UTP”, “MCAST” or “RTP” in [Protocol] for your need. Select “Main Stream” or “Sub Stream” in Protocol for your need. Finally, click OK to finish settings. Fig. 2.16 Add Device Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 29: Sensor Parameters Configuration

    Step 5: Click the Preview, and then double click the device name in the left tree to view the live video. Fig. 2.18 Preview 2.2.3 Sensor Parameters Configuration For viewing better image, you can set the parameters of the camera, and operate as following: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 30 “Gain” for your need, which can be set from 1 to 100. Fig. 2.20 Video Parameters Step 3: White Balance Configuration Select the mode to Auto1 or Off for your need. Fig. 2.21 White Balance Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 31 Fig. 2.23 Day/ Night Mode Step 6: Other Parameters Configuration Select the value of “Power Line”, “Mirror”, “E-PTZ” and “Local Output”. Fig. 2.24 Other Parameters NOTE:Different models of the cameras’ maybe have different menus. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 32 PC Operating System after the installation of client software 4000 v. 2.0 by selecting “Start”-> “All Programs”-> “iVMS 4000( v. 2.0)” -> “iVMS 4000( v. 2.0)”. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 33: Chapter 3 Access Over Internet

    Note: Refer to Appendix 2 for a detailed explanation about Port Map. Users can directly connect the network camera to the internet without using a router. Fig. 3.1 Access IPC through Router with Static IP Fig.3.

  • Page 34: Access Network Camera With Dynamic Ip

    Please restart the network camera after completion of configuration. Then the network camera can obtain a dynamic IP from an ISP operation business. However, the obtained IP address is dynamically assigned via PPPoE, so the IP address always changes accompanied with modem rebooting.
  • Page 35 User Manual of Network Camera Fig. 3.5 PPPoE configuration Dialog box It is inconvenient to view a network camera with a dynamic IP, therefore, users should register with a dynamic DNS service provider. (Such as DynDns.com) Domain name resolution contains normal domain name resolution and private domain name resolution.
  • Page 36 User Manual of Network Camera software configuration as an example. Fig. 3.7 Selecting Normal Domain Mode Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 37 A PC with a static IP which is running the domain name resolution service is necessary. When the network camera connects to the internet through PPPoE and obtains an IP address, it will send its name and IP address to the resolution server. When the client software connects to the network camera, it will connect to the resolution server and tell the resolution server the expected camera’s name.

  • Page 38: Appendix 1 Sadp Introduction

    Select the device that needs modification in the device list, then basic information of the device will be demonstrated in the information column on the right. Click “modify” button to activate IP address, subnet mask, device port editing and password validating box, as follows: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 39 Input certain validation code into the ‘Resume default password’ box, and click ‘OK’ to finish the administrator’s password initiating. Note: Password reset code can be obtained by the technicians from Hikvision after you provide the device Serial NO. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...

  • Page 40: Appendix 2 Port Map

    The following figure gives the illustration. One camera’s ports are 80, 8000, 554, 8200 and its IP address is 192.168.1.23. The other camera’s ports are 81, 8001, 555, 8201 and IP is 192.168.1.24. Afterwards, enable all or TCP protocols. Enable the port map after pressing the ‘Save’. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
  • Page 41 User Manual of Network Camera As the settings mentioned above, map the router’s port 80 and 8000 to the network camera at 192.168.1.23; and port 81 and 8001 to the network camera at 192.168.1.24. In this way, user can access the 192.168.1.23 through accessing the router’s port 80 and 8000.

  • Page 42: Appendix 3 Pin Definition

    User Manual of Network Camera Appendix 3 Pin Definition (1)UTP between the network port of camera and HUB (Direct Cable) (2)UTP between the network port of camera and PC (Cross Cable): Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
