Summary of Contents for HIKVISION Network Camera

  • Page 1: Network Camera

    Network Camera User Manual V3.0.1 Hikvision Digital Technology Co., Ltd. http://www.hikvision.com...
  • Page 2 UL MAKES NO REPRESENTATIONS, WARRANTIES CERTIFICATIONS WHATSOEVER REGARDING PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.” © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 3: Regulatory Information

    (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 4: Safety Warnings And Cautions

    (AC power).The socket outlet shall be installed near the equipment and shall be readily accessible. Installation and Maintenance:Do not connect/disconnect any cables to or perform installation/maintenance on this device during an electrical storm. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 5 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 6: Safety Instruction

    4. Please make sure that the plug is firmly inserted into the power socket. 5. When the product is installed on a wall or ceiling, the device should be firmly fixed. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 7 7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 8 10. Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 9: Table Of Contents

    2.2.2 Camera Parameters Configuration ............30 2.2.3 Wireless Parameter Configuration ............34 Chapter 3 Access over Internet .................. 35 3.1 Access network camera with static IP ............. 35 3.2 Access network camera with dynamic IP ............36 Appendix 1 SADP Introduction ................... 40 Appendix 2 Port Map ....................
  • Page 10: Chapter 1 Network Camera Connection

    User Manual of Network Camera Chapter 1 Network Camera Connection 1.1 Cable Network Two methods can be used to connect between network camera and PC, shown as below: Figure 1.1.1 Cross Line Connection Figure 1.1.2 Direct Line Connection 1.2 Wireless Network Note: This section is only for wireless network camera with mark '-W' in the model number.
  • Page 11: Network Connection

    User Manual of Network Camera 1.3 Network Connection Before visiting network camera over network, user should acquire its IP address first. SADP is a software tool which can automatically detect network device in the LAN and give the device’s information like IP address, mask, port number, device serial number, software version, etc., as shown in Figure 1.3.1.
  • Page 12: Chapter 2 Network Access

    Type the IP address of the network camera and press Enter, then the ActiveX mention dialog will pop Click Install to install the ActiveX control. Figure 2.1.2 Install the ActiveX Control © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 13 Capture Picture Start/Stop Record Digital Zoom Video Parameters Digital Zoom Click mouse in the desired position of live video image and scroll the mouse to realize zoom in and zoom out function. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 14: Parameters Configuration

    Restore default Note: This menu varies depending on Figure2.1.5 Video Parameters different camera models. 2.1.2 Parameters Configuration Click Configuration to enter the Parameters Configuration interface. 2.1.2.1 Local Configuration Figure2.1.6 Local Configuration © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 15: Remote Configuration

    Name and Device ID, as well as view the information of IP camera, including Device Description, Device Location, MAC address, Device Type, Device SN, Firmware Version, and U-boot Version. Figure2.1.7 Basic Information © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 16 & flickering, Figure2.1.8 Display Settings transparent &unflickering, nontransparent & flickering, or nontransparent &unflickering. Channel ParametersVideo Settings: Figure2.1.9 Video Settings Parameter Description Channel Name Input the channel name for your need © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 17 “10 min” optional. Select the checkboxes below “Copy To:” to copy this Note: The time of each segment day’s settings to whole week or some days in one can’t be overlapped. week. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 18 Linkage: The Linkage method can be selected to either Email link, Trigger recording or Trigger alarm output. Click "Save" button to save the modified parameters. Figure2.1.12 Motion Detection Linkage Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 19 User can set the shutter time according different camera models. IrisMode: Figure2.1.14 Front Parameters Config There are two modes: IrisFirst and manual optional. Power Mode: There are two modes: 50Hz and 60Hz optional. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 20 After reboot, the camera will obtain a public IP address. Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. Figure2.1.16 PPPOE Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 21 The Device Name refers to the domain name applied in the DynDNS website. Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. Figure2.1.18DynDNS Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 22 NTP server achieve time synchronization. Figure 2.1.20 NTP Settings Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 23 Input the SMTP server, SMTP port, user name, password, E-mail sender and receiver. Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. Figure2.1.22 E-mail Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 24 Set the type of Relay Status to NC or NO. The Linkage can be selected to E-mail link, Trigger alarm output or Trigger recording. Click "Save" button to save the modified parameters. Figure2.1.25 Alarm Input Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 25 Figure2.1.27 Alarm Deployment Time modified parameters. Settings User Management: Figure 2.1.28 User Management When the current login user is admin, it is allowed to create other users. Up to 15 users can be © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 26 Hard disk’s total capacity. Free Space(MB) The remaining memory of the hard disks. Status The working status of the hard disks. Format Select the hard disk you want to format and press this button. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 27 Figure 2.1.33 Restore Default except IP address, subnet mask, gateway and port. Reboot Device: Click OK to reboot the network camera. Figure 2.1.34 Reboot Device © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 28: Advanced Configuration

    Please refer to “Client Software-4000(v2.0)_ENG.pdf” for a more detailed parameters configuration. You can find the document in the PC Operating System after the installation of client software 4000 v. 2.0 by selecting “Start”-> “All Programs”-> “client software 4000 v. 2.0”. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 29: Wireless Parameters Configuration

    In the WiFi settings interface, if user select Ad-Hoc mode as the operating mode, please set the PC's wireless IP address in the same network segment as the IP address of wireless network camera. Select "View Wireless Networks" in the computer's "Wireless Network Connection". Find the device which has the same name as the SSID number of the wireless camera.
  • Page 30: Access Over Client Software

    Wlan settings interface, as shown in Figure 2.1.39. Figure 2.1.39Wlan Settings Interface In the "Wlan settings" interface, user can set the wireless network camera's parameters like wireless IP address, subnet mask, gateway and DNS server address, etc. Unplug the network cable from wireless network camera.
  • Page 31: Camera Parameters Configuration

    Different types of network cameras maybe have different configuration parameters in the interface of “Config Sensor Parameters”. This section takes a type of network camera for example to introduce configuration parameters in the interface of “Config Sensor Parameters”. If the information in the actual interface of “Config Sensor Parameters”...
  • Page 32 “Gain”for your need, which can be set from 1 to 100. Figure 2.2.3 Video Parameters Step 3: White Balance Configuration Select the mode to Auto1 or Off for yourneed. Figure 2.2.4 White Balance © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 33 Not all of the models have this feature. There are three modes selectable: Close, Normal Mode, Experts Mode. The Level can be adjusted from 0 to 100 to enhance the DNR effect. Figure 2.2.7 Digital Noise Reduction © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 34 “Contrast” is from 0-100 selectable. Figure 2.2.9WDR Step 9: Other Parameters Configuration Select the value of “Power Line”, “Mirror”, “E-PTZ” and “Local Output”. Figure 2.2.10 Other Parameters © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 35: Wireless Parameter Configuration

    2.2.3 Wireless Parameter Configuration Note: This section is only for wireless network camera with mark '-W' in the model number. Click “setup” in the client software to enter the devices management interface. Right click the device that needs to be configured, select “Remote Configuration” to enter the remote configuration interface.
  • Page 36: Chapter 3 Access Over Internet

    Note: Refer to Appendix 2 for a detailed explanation about Port Map. Users can directly connect the network camera to the internet without using a router. Figure 3.1.1 Access IPC through Router with Static IP Figure3.1.2 Access IPC with Static IP directly For the client software to view the camera, in the adding equipment column, select the normal model, and then fill in the IP info.
  • Page 37: Access Network Camera With Dynamic Ip

    This camera supports the PPPoE auto dial-up function. The camera will get a public IP address by ADSL dial-up after the camera is connected to a Modem; First, access to the network camera through local network, select “Configure””Right Click the Device”, “Remote Configuration”, and finally select “PPPoE Settings”...
  • Page 38 User Manual of Network Camera Figure 3.2.2PPPoE configuration Dialog box It is inconvenient to view a network camera with a dynamic IP, therefore, users should register with a dynamic DNS provider. (Such as DynDns.com) Domain name resolution contains normal domain name resolution and private domain name resolution.
  • Page 39 User Manual of Network Camera software configuration as an example. Figure 3.2.4 Selecting Normal Domain Mode © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 40 A PC with a static IP which is running the domain name resolution service is necessary. When the network camera connects to the internet through PPPoE and obtains an IP address, it will send its name and IP address to the resolution server. When the client software connects to the network camera, it will connect to the resolution server and tell the resolution server the expected camera’s name.
  • Page 41: Appendix 1 Sadp Introduction

    Select the device that needs modification in the device list, then basic information of the device will be demonstrated in the information column on the right. Click “modify” button to activate © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 42 You can reset the password of the super user as “12345” in the case of a lost password. Input certain validation code into the ‘Resume default password’ box, and click ‘OK’ to finish the administrator’s password initiating. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 43: Appendix 2 Port Map

    The following figure gives the illustration. One camera’s ports are 80, 8000, 554, 8200 and its IP address is 192.168.1.23. The other camera’s ports are 81, 8001, 555, 8201 and IP is 192.168.1.24. Afterwards, enable all or TCP protocols. Enable the port map after pressing the ‘Save’. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 44 User Manual of Network Camera As the settings mentioned above, map the router’s port 80 and 8000 to the network camera at 192.168.1.23; and port 81 and 8001 to the network camera at 192.168.1.24. In this way, user can access the 192.168.1.23 through accessing the router’s port 80 and 8000.
  • Page 45: Appendix 3 Pin Definition

    User Manual of Network Camera Appendix 3 Pin Definition (1)UTP between the network port of camera and HUB (Direct Cable) (2)UTP between the network port of camera and PC (Cross Cable): © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 46 User Manual of Network Camera First Choice for Security Professionals © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
