Page 1: Network Camera
Network Camera User Manual V3.0.0 Hangzhou Hikvision Digital Technology Co., Ltd. http://www.hikvision.com... - Page 2 UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.” Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 3: Regulatory Information
(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 4: Safety Warnings And Cautions
Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by HIKVISION Employees with knowledge and training in working with these types of devices that contain live circuits. - Page 5 Lead Content: Please recycle this device in a responsible manner. Refer to local environmental regulations for proper recycling; do not dispose of device in unsorted municipal waste. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 6: Safety Instruction
7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 7 10. Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 8: Table Of Contents
User Manual of Network Camera Table of Contents Chapter 1 Network Camera Connection ........................1 Setting the Network Camera over the LAN ..................... 1 1.1.1 Wiring over the LAN ........................1 1.1.2 Detecting and Changing the IP Address ..................2 Setting the Network Camera over the WAN .................... -
Page 9: Chapter 1 Network Camera Connection
Chapter 1 Network Camera Connection Before you start: If you want to set the network camera via a LAN (Local Area Network), please refer to Section 2.1 Setting the Network Camera over the LAN. If you want to set the network camera via a WAN (Wide Area Network), please refer to Section 2.2 Setting the Network Camera over the WAN. -
Page 10: Detecting And Changing The Ip Address
2. Change the IP address and subnet mask to the same subnet as that of your computer. 3. Enter the IP address of network camera in the address field of the web browser to view the live video. -
Page 11: Setting The Network Camera Over The Wan
1.2.2 Dynamic IP Connection Before you start: Please apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network camera to a modem or a router. Connecting the network camera via a router... - Page 12 This camera supports the PPPoE auto dial-up function. The camera gets a public IP address by ADSL dial-up after the camera is connected to a modem. You need to configure the PPPoE parameters of the network camera. Refer to Section 5.3.3 Configuring PPPoE Settings for detailed configuration.
- Page 13 1. Install and run the IP Server software in a computer with a static IP. 2. Access the network camera through the LAN with a web browser or the client software. 3. Enable DDNS and select IP Server as the protocol type. Refer to Section 5.3.4 Configuring DDNS Settings for detailed configuration.
-
Page 14: Chapter 2 Network Access
Type the IP address of the network camera and press Enter, then the ActiveX mention dialog will pop Click Install to install the ActiveX control. Fig. 2.1.2 Install the ActiveX Control Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 15 Fig. 2.1.4 Live View Page Icons on Live View Page: Icon Description Full-screen display mode Exit full-screen display mode Start Preview Stop Preview Capture Picture Start/Stop Record Digital Zoom Video Parameters Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 16: Parameters Configuration
Fig. 2.1.5 Video Parameters Note: Gain value is not configurable when the Day/Night mode is ‘Auto’. 2.1.2 Parameters Configuration Click Configuration to enter the Parameters Configuration interface. 2.1.2.1 Local Configuration Fig. 2.1.6 Local Configuration Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 17: Remote Configuration
Name and Device ID, as well as view the information of IP camera, including Device Description, Device Location, MAC address, Device Type, Device SN, Firmware Version, and U-boot Version. Fig. 2.1.7 Basic Information Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 18 Select or custom bitrate according to the resolution Multicast Set the multicast address, with the default multicast of 0.0.0.0 RTSP Port Set the RTSP port, with the default RTSP port of 554 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 19 0, the sensitivity is disabled. Linkage: The Linkage method can be selected to either Email link or Trigger alarm output. Click "Save" button to save the modified parameters. Fig. 2.1.11 Motion Detection Linkage Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 20 Mask, Gateway and DNS Server of the network camera. Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. Fig. 2.1.13 Network Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 21 The Device Name refers to the domain name applied in the DynDNS website. Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. Fig. 2.1.16 DynDNS Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 22 NTP software can be used to establish NTP server Fig.2.1.18 NTP Settings achieve time synchronization. Click "Save" button to save the modified parameters. Note: Please reboot network camera to validate the modified parameters. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 23 The output delay time can be set to 5sec, 10sec, 30sec, 1min, 2min, 5min, 10min or Manual (manually disable). Click "Save" button to save the modified parameters. Fig. 2.1.21 Alarm Output Delay Settings Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 24 Fig. 2.1.24. Input the user name, password, address, MAC address, and then select user type. Finally, Fig. 2.1.24 Add User click OK to finish the user addition. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 25 The Basic Mode refers to restore the parameters to factory default settings except IP address, subnet Fig. 2.1.27 Restore Default mask, gateway and port. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 26: Advanced Configuration
(Such as http://172.6.42.105/config), and then click [Enter]. Fig. 2.1.29 2: Type the Username (default: admin), Password (default: 12345) and Port (default: 8000) of the camera, and then click [Login]. Fig. 2.1.30 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 27: Wireless Parameters Configuration
2.1.3 Wireless Parameters Configuration Note: This section is only for wireless network camera with mark '-W' in the model number. Before configuring the wireless network camera, please set the wireless router first. For more details about wireless router configuration, please refer to the wireless router configuration instructions. - Page 28 In the WiFi settings interface, if user select Ad-Hoc mode as the operating mode, please set the PC's wireless IP address in the same network segment as the IP address of wireless network camera. Select "View Wireless Networks" in the computer's "Wireless Network Connection". Find the device which has the same name as the SSID number of the wireless camera.
-
Page 29: Access Over Client Software
The wireless network camera now can be accessed through wireless network after the related network parameters have been set. The way that accesses to wireless network camera through wireless network is similar to cable network. Refer to section 2.1. 2.2 Access over Client Software Please refer to “iVMS-4000(v2.0) introductor.pdf”... -
Page 30: Camera Parameters Configuration
Different types of network cameras maybe have different configuration parameters in the interface of “Config Sensor Parameters”. This section takes a type of network camera for example to introduce configuration parameters in the interface of “Config Sensor Parameters”. If the information in the actual interface of “Config Sensor Parameters”... - Page 31 Step 5: Day/Night Mode Configuration Select “Day”, “Night” or “Auto” mode in Mode and adjust the value of “Day->Night”, “Night->Day”, and “Filter time” for your need. Fig. 2.2.6 Day/ Night Mode Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 32: Wireless Parameter Configuration
2.2.3 Wireless Parameter Configuration Note: This section is only for wireless network camera with mark '-W' in the model number. Click “setup” in the client software to enter the devices management interface. Right click the device that needs to be configured, select “Remote Configuration” to enter the remote configuration interface. - Page 33 User Manual of Network Camera Fig. 2.2.8 Client Software Wireless Configuration Interface Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 34: Chapter 3 Access Over Internet
Note: Refer to Appendix 2 for a detailed explanation about Port Map. Users can directly connect the network camera to the internet without using a router. Fig. 3.1.1 Access IPC through Router with Static IP Fig.3.1.2 Access IPC with Static IP directly For the client software to view the camera, in the adding equipment column, select the normal model, and then fill in the IP info. -
Page 35: Access Network Camera With Dynamic Ip
This camera supports the PPPoE auto dial-up function. The camera will get a public IP address by ADSL dial-up after the camera is connected to a Modem; First, access to the network camera through local network, select “Configure””Right Click the Device”, “Remote Configuration”, and finally select “PPPoE Settings”... - Page 36 User Manual of Network Camera Fig. 3.2.2 PPPoE configuration Dialog box It is inconvenient to view a network camera with a dynamic IP, therefore, users should register with a dynamic DNS provider. (Such as DynDns.com) Domain name resolution contains normal domain name resolution and private domain name resolution.
- Page 37 User Manual of Network Camera software configuration as an example. Fig. 3.2.4 Selecting Normal Domain Mode Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 38 A PC with a static IP which is running the domain name resolution service is necessary. When the network camera connects to the internet through PPPoE and obtains an IP address, it will send its name and IP address to the resolution server. When the client software connects to the network camera, it will connect to the resolution server and tell the resolution server the expected camera’s name.
-
Page 39: Appendix 1 Sadp Introduction
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 40 Serial code is a series of characters combined by the start time and the serial number of the device. 2. Input the code in the Serial code field and click to restore the default password. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 41: Appendix 2 Port Map
The following figure gives the illustration. One camera’s ports are 80, 8000, 554, 8200 and its IP address is 192.168.1.23. The other camera’s ports are 81, 8001, 555, 8201 and IP is 192.168.1.24. Afterwards, enable all or TCP protocols. Enable the port map after pressing the ‘Save’. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 42 User Manual of Network Camera As the settings mentioned above, map the router’s port 80 and 8000 to the network camera at 192.168.1.23; and port 81 and 8001 to the network camera at 192.168.1.24. In this way, user can access the 192.168.1.23 through accessing the router’s port 80 and 8000.
-
Page 43: Appendix 3 Pin Definition
User Manual of Network Camera Appendix 3 Pin Definition (1)UTP between the network port of camera and HUB (Direct Cable) (2)UTP between the network port of camera and PC (Cross Cable): Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 44 User Manual of Network Camera First Choice for Security Professionals Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
