    NETWORK CAMERA User Manual V2.0.0 2009-8...
  • Page 2 DS-2CD852MF-E, DS-2CD762MF-FB(H), DS-2CD752MF-FB(H), DS-2CD752MF(-E), DS-2CD852F series Network Camera This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual.

  • Page 3: Safety Instruction

    User Manual of Network Camera Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected.
  • Page 4 User Manual of Network Camera Notice: 1. Make sure the power supply voltage is correct before using the camera. 2. Do not drop the camera or subject it to physical shock. 3. Do not touch CCD (Charge Coupled Device) modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.

  • Page 5: Table Of Contents

    3.4.2 Visit network camera with dynamic IP ..................... 27 Chapter 4 Menu Introduction ............................. 31 4.1 Main Menu ..............................31 4.2 Menu Introduction of 2.0 Megapixels CMOS Network Camera ..............32 4.2.1 Language settings ..........................32 4.2.2 Flicker Control ..........................32 4.2.3 Resolution settings ..........................
  • Page 6 User Manual of Network Camera 4.3.8 White Balance Settings ........................40 4.3.9 BACKLIGHT COMPENSATION ....................41 4.3.10 Mirror mode settings ........................42 Appendix 1 SADP Introduction ..........................44 Appendix 2 Port Map ..............................46 Appendix 3 Pin Definition ............................48 Appendix 4 Product Specification ..........................

  • Page 7: Chapter 1 Introduction

    User Manual of Network Camera Chapter 1 Introduction Network camera is a kind of embedded digital surveillance product that combines the features of both traditional analog camera and net DVS (Digital Video Server). Due to the embedded Linux operation system and the latest Davinci hardware platform of TI, the system operates with high scheduling efficiency.

  • Page 8: Applications

    User Manual of Network Camera Remote Control:  The product offers a 10M/100M self-adaptive Ethernet interface.  Support TCP / IP, HTTP, DNS, RTP / RTCP, PPPoE protocols.  Set the parameters, browse real time videos or check the camera performance through software or IE, and get external alarming and store the compressed bit rate through network.

  • Page 9: Chapter 2 Installation

    Never attempt to disassemble the camera yourself. Users are responsible for any problem caused by modification or repairing without authorization. 2.1 Panels Description 2.1.1 Side Elevation of the Camera Fig 2.1.1 Side Elevation of DS-2CD852MF-E and DS-2CD852F network camera Fig 2.1.2 Side Elevation of DS-2CD862MF-E network camera...
  • Page 10 User Manual of Network Camera Fig 2.1.3 Side Elevation of DS-2CD752MF-E network camera Fig 2.1.4 Side Elevation of DS-2CD752MF-FB DS-2CD762MF-FB network camera...

  • Page 11: Rear Panel Description

    4. 1 channel alarm output (1A 1B). 1 channel alarm input signal (IN,G). RS-485 bus interface (T＋ T-). 5. SD card slot (Support SDHC ). 6. Power supply interface of 12VDC, ±10%. Fig. 2.1.6 Rear Panel of DS-2CD852MF-E, DS-2CD862MF-E network camera 1. Standard Ethernet (UTP) RJ45 (10M/100M self-adaptive).
  • Page 12 User Manual of Network Camera 2. 1 channel voice talk input,3.5mm audio interface, 2.0～2.4Vp-p, 1kΩ. 3. 1 channel voice talk output, 3.5mm audio interface, electric line level, 600Ω. 4. SDHC card slot (Support SDHC ). 5. 1 channel alarm input signal.
  • Page 13 User Manual of Network Camera Notices: There are invalid dial switches for DS-2CD702, DS-2CD712, DS-2CD792, DS-2CD732 series from 6 to 10; SD card slot：Supports SDHC card, and the dimensions of SD meet the market’s normal standard. Fixed Screw: Loosen this screw to rotate the camera horizontally and vertically to adjust the pan and tilt position.

  • Page 14: Product Installation

    User Manual of Network Camera cable hole with a waterproof plug. 6. Lens: First, loosen the zoom lock handle, rotate it until there is an appropriate view angle between TELE and WIDE, then tighten the handle. Loosen the focus lock handle, rotate it until getting a clear image between NEAR and FAR, then tighten the handle.

  • Page 15: Dome Camera Installation

    User Manual of Network Camera Fig 2.2.1 Fix Ceiling Bracket Fig 2.2.2 Fix Camera Fig 2.2.3 Fix Lens 2.2.2 Dome camera Installation Dome camera can be installed include hold equipment, ceiling mounted, cylinders and other styles. Client can be installed in accordance with their own ways to achieve the installation.Please according the following specific steps to install (take ceiling mounted as example), when the wall is wood, use the self-tapping screws to fix the ceiling plate to the wall surface.

  • Page 16: Vandal Proof Dome Camera Installation

    User Manual of Network Camera Fig 2.2.4 Fix card Fig 2.2.5 Fix in Ceiling Take the three columns of Dome camera insert in the three fix slot of the ceiling plate. Pay attention to the direction of insertion. Let the ceiling plate “I” logo and the Dome camera “I” logo in the same direction.
  • Page 17 User Manual of Network Camera transparent cover shown as below: Fig. 2.2.8 Unload the Cover 2. Use the screws to fix the dome camera on the ceiling. Fig. 2.2.9 Install the Camera 3. Adjust the camera’s view angle while watching the video on the adjustment monitor.

  • Page 18: Topological Graph Of Network Camera

    User Manual of Network Camera Fig. 2.2.10 Install the Cover 2.2.4 Topological graph of network camera Megapixels Network Box Camera Application: Megapixels Network Dome Camera Application:...

  • Page 19: Client Software Installation

    User Manual of Network Camera Notice: Fig 2.1.12 Alarm output The alarm output is an on/off output that requires external power supply on connection. The external power supply shall be 12V DC/30mA, or use AC with external relays. Equipment damage or electric shock may cause if without relays.
  • Page 20 User Manual of Network Camera Fig.2.3.1 Client Software Installation Step2: Input “User Name”, “Company Name”; Fig.2.3.2 Customer Information Step3: Select the destination folder and click ‘Next’ to go to the next step.
  • Page 21 User Manual of Network Camera Fig2.3.3 Ready to Install the Program Step4: Click ‘Install’ to start installation till finish the installation; Fig2.3.4 Installation Complete Click the ‘Finish’ button to close the dialog box. After the client software has been installed, you can find the remote client software through “Start”...

  • Page 22: Chapter 3 Parameter Configuration

    Fig. 3.1.3 Cross Line Connection Fig. 3.1.1 Direct Line Connection Before visiting network camera, user should detect its IP address. SADP is a tool software which can automatically detect hikvision’s network device in the LAN and give the device’s information like IP...

  • Page 23: Configuration Via Web Browser

    User Manual of Network Camera Fig. 3.1.2 Select the device, and set its IP address and mask at the same network segment with the PC. The detailed introduction of SADP, please refer to Appendix 1. 3.2 Configuration via Web browser Before visit the camera via web browser, user should adjust security level.
  • Page 24 User Manual of Network Camera Fig. 3.2.1 Set the Security Level The default IP of the camera is 192.0.0.64 with 8000 as the default port, admin as the administrator,...
  • Page 25 User Manual of Network Camera and 12345 as the password. The administrator can create up to 15 separate operators with different right levels. To login the camera through IE, input the IP address in the address column, and the “Login” dialog box will pop-up as Fig.

  • Page 26: Configuration Via Client Software

    User Manual of Network Camera dialog box to pop up, and then set the parameters like IP address, etc. for your demand as Fig. 3.2.4. Enter the menu by invoking the 95 preset. Select the function you want by clicking the direction key.
  • Page 27 User Manual of Network Camera Fig.3.4.1 Register Administrator Enter the registered user name and password as Fig. 3.3.2. Click “Login” to enter the “Preview” menu as Fig. 3.3.3. Fig. 3.4.2 User Login Fig. 3.4.3 Preview Menu Click the “Configure” button in Fig. 3.3.4, and then right click the blank white space. Click the “Add...
  • Page 28 User Manual of Network Camera Fig. 3 .4.4 Add Area Fig. 3.4.5 Add Area Properties Input the area name (you can create whatever name you like) and click “OK” as Fig. 3.3.6. Then right click the area you have just created as Fig. 3.3.7.
  • Page 29 User Manual of Network Camera Fig. 3.4.6 Area Name Adding Completed Fig. 3.4.7 Right Click the Area Name Click “Add Device”, and the “Add Device” dialog box will pop up as Fig. 3.3.8. Input your “Device Name”. Select “Normal” from “Register” option. Input your camera IP in “Device IP”, e.g. 192.0.0.64;...
  • Page 30 User Manual of Network Camera Fig. 3.4.8 Add Device Fig.3.4.9 Camera Adding Completed Click the “Preview” button to enter the “Preview” menu as Fig. 3-3-10. Double click the channel name in the left tree to preview the camera feed.
  • Page 31 User Manual of Network Camera Double click the channel Fig.3.4.10 Preview Menu Please refer to “Client Software-4000(v2.0)_ENG.pdf” for a more detailed parameters configuration. You can find the document in the PC Operating System after the installation of client software 4000 v.

  • Page 32: Visit Network Camera In Internet

    Note: Refer to Appendix 2 to for a detailed explanation about Port Map. Users can directly connect the network camera to the internet without using a router. Fig.3.5.1 Static IP through Router access IPC Fig.3.5.2 Static IP access IPC directly...

  • Page 33: Visit Network Camera With Dynamic Ip

    Please restart the network camera after completion of configuration. Then the network camera can obtain a dynamic IP from an ISP operation business. However, the obtained IP address is dynamically assigned via PPPoE, so the IP address always changes accompanied with...
  • Page 34 User Manual of Network Camera Fig.3.5.5 PPPoE configuration dialog box It is inconvenient to view a network camera with a dynamic IP, therefore, users should register with a dynamic DNS service provider. (Such as DynDns.com) Domain name resolution contains normal domain name resolution and private domain name resolution.
  • Page 35 A PC with a static IP which is running the domain name resolution service is necessary. When the network camera connects to the internet through PPPoE and obtains an IP address, it will send its name and IP address to the resolution server. When the client software connects to the...
  • Page 36 User Manual of Network Camera camera’s name. And the server will find the camera from all the registered cameras and send its IP address to the client software. Once the client software gets the IP address, it can connect the network camera.

  • Page 37: Chapter 4 Menu Introduction

    User Manual of Network Camera Chapter 4 Menu Introduction Note: In this chapter, we call DS-2CD852MF-E, DS-2CD752MF-FB, DS-2CD752MF(-E), DS-2CD852F, as 2.0 megapixels CMOS network camera. And call DS-2CD862MF-E, DS-2CD762MF-FB as 1.3 megapixels CCD network camera. 4.1 Main Menu Call preset 95 and the menu will appear on the screen.”IRIS +” means “enter”, while “IRIS -” means “cancel”.

  • Page 38: Menu Introduction Of 2.0 Megapixels Cmos Network Camera

    User Manual of Network Camera The main menu displays as below: Fig.4.1.2 Main Menu 4.2 Menu Introduction of 2.0 Megapixels CMOS Network Camera 4.2.1 Language settings Press left / right to select language between Chinese and English; 4.2.2 Flicker Control Press left / right to select frequency between 50HZ and 60HZ in the FLICKER CONTROL item;...

  • Page 39: Frame Settings

    User Manual of Network Camera 4.2.4 Frame settings FRAME can’t be changed by pressing left / right button; User can select resolution through “configuration””remote configuration” “channel configuration ”“Frame rate”; The relationship between frame and resolution is as below table: Model Resolution Max.

  • Page 40: Auto Gain Settings

    User Manual of Network Camera HD720p 15fps 15fps 5fps UXGA 10fps 10fps 5fps 4.2.6 Auto Gain settings Press left / right to adjust AUTO GAIN level among OFF, low, middle and high; 4.2.7 DAY / NIGHT Settings Press left / right to select DAY / NIGHT mode among DAY, NIGHT and AUTO;...

  • Page 41: White Balance Settings

    User Manual of Network Camera Fig.4.2.2 NIGHT Mode 4.2.8 White Balance Settings Press left / right to set WHITE BALANCE AUTO or OFF; 4.2.9 Effect Mode settings Press left / right to select EFFECTS MODE among OFF, SPEIA, NEGTIVE, SOLARIZE1 and SLOARIZE2;...

  • Page 42: Mirror Mode Settings

    User Manual of Network Camera Fig.4.2.3 SEPIA Mode Fig.4.1.1 NEGATIVE Mode 4.2.10 Mirror mode settings Press left / right to select MIRROR mode among OFF, LEFT RIGHT, UP BOTTOM, and CENTER;...

  • Page 43: Eptz Settings

    8 manual disposition patrols as well. HD720p resolution only supports pan and tilt operation，does not support zoom operation. UXGA resolution does not support the ePTZ function. 4.3 Menu Introduction of 1.3Megapiixels CCD Network Camera The main menu displays as below:...

  • Page 44: Language Settings

    User Manual of Network Camera 4.3.1 Language settings Press left / right to select language between Chinese and English. 4.3.2 Resolution settings RESOLUTION can’t be changed by pressing left / right button; User can select resolution through client software, and the path is “configuration””remote configuration” “channel configuration ”“Resolution”.

  • Page 45: Shutter

    User Manual of Network Camera 4.3.5 Shutter Press left / right to adjust the exposure time from 1/25s, 1/50s, 1/100s, 1/250s, 1/500s, 1/1ks, 1/2ks, 1/4ks, 1/10ks, 1/100ks. 4.3.6 Auto Gain settings Press left / right to adjust AUTO GAIN level among OFF, low, middle and high;...

  • Page 46: White Balance Settings

    User Manual of Network Camera Fig.4.2.2 NIGHT Mode 4.3.8 White Balance Settings Press left / right to set WHITE BALANCE ATW1, ATW2, ATC or MANUAL; ATW1: Camera uses TTL auto white balance algorithm to ideally recovery color, temperature range is from 2500K to 6500K.

  • Page 47: Backlight Compensation

    User Manual of Network Camera settings, move the cursor to “back” and press confirm button ”IRIS+” to return to the previous menu. Note: When DAY / NIGHT mode is NIGHT, the WHITE BALANCE is invalid. Or DAY / NIGHT mode is AUTO, and the video is white and black, WHITE BALANCE is invalid too.

  • Page 48: Mirror Mode Settings

    User Manual of Network Camera Move cursor to “POSITION”, and press “IRIS+” to enter the submenu; Press up / down / left / right to adjust the position of BLC area. After setting, press BACK to return to the previous menu.
  • Page 49 User Manual of Network Camera...

  • Page 50: Appendix 1 Sadp Introduction

    User Manual of Network Camera Appendix 1 SADP Introduction 1. Brief introduction SADP (Search Active Devices Protocol), can automatically search IP cameras in LAN. User can modify the IP address, subnet mask and port of the device without visiting IP address of the device. Additionally, password of the super user in this device can be recovered as default.
  • Page 51 You can reset the password of the super user as ‘12345’ in the case of a lost password. Input certain validation code into the ‘Resume default password’ box, and click ‘OK’ to finish the administrator’s password initiating. Note: Password reset code can be obtained by the technicians from Hikvision after you provide the device Serial NO.

  • Page 52: Appendix 2 Port Map

    User Manual of Network Camera Appendix 2 Port Map Note: The following setting is about TP-LINK router (TL-R410), which is maybe distinct from other router’s setting. 1. Firstly, select the router’s WAN connection Type. As the following Fig. shows: 2. Set the “network parameter” of the router as the below figure. The setting includes subnet mask and gateway.
  • Page 53 As the above mentioned setting, we map the router’s port 80, 8000, 554, 8200 to the network camera 192.168.1.23; and port 81, 8001, 555, 8201 to the network camera 192.168.1.24. In this way, user can visit the 192.168.1.23 through visiting the router’s port 80, 8000, 554 and 8200.

  • Page 54: Appendix 3 Pin Definition

    User Manual of Network Camera Appendix 3 Pin Definition (1)UTP between the network port of camera and HUB (Direct Cable) (2)UTP between the network port of camera and PC (Cross Cable):...

  • Page 55: Appendix 4 Product Specification

    User Manual of Network Camera Appendix 4 Product Specification DS-2CD862MF-E Specification Parameter Model DS-2CD862MF-E Camera Image Sensor 1/3 inch SONY progressive scan CCD Effective Pixels 1280 (H) × 960 (V), 1.3M CCD Min. Illumination Color: 0.1Lux @ F1.2, B / W: 0.01Lux @ F1.2...

  • Page 56: Dimension

    User Manual of Network Camera Others Working Temperature -10℃ ~ 60℃ Power Supply AC24V, ±10% / DC12V, ±10%, PoE (Power over Ethernet). Power Consumption 4W MAX (10W max with ICR working) Dimensions (mm) 68.5 x 63 x 157.5 2.71” x 2.5” x 6.25”...

  • Page 57: Ds-2Cd852Mf-E

    User Manual of Network Camera DS-2CD852MF-E Specification Parameter Model DS-2CD852MF-E Camera Image Sensor 1/3 inch CMOS Effective Pixels 1600 (H) × 1200 (V) 0.5Lux @ F1.2 Min. Illumination 0.1Lux @ F1.2, sense up × 5 Electronic Shutter Auto Auto Iris Lens Day&Night...

  • Page 58: Dimension

    User Manual of Network Camera Others Working Temperature -10℃ ~ 60℃ Power Supply AC24V, ±10% / DC12V, ±10%, PoE (Power over Ethernet). Power Consumption 4W MAX Dimensions (mm) 64.8 x 63 x 157.5 2.57”x 2.5” x 6.25” (1.32lbs) Weight 600g...

  • Page 59: Ds-2Cd762Mf-Fb

    User Manual of Network Camera DS-2CD762MF-FB Specification Model DS-2CD762MF-FB Parameter Camera Image Sensor 1/3 inch SONY progressive scan CCD Effective Pixels 1280 (H) × 960 (V), 1.3M CCD Min. Illumination 0.1Lux @ F1.2 (Color), 0.01Lux @ F1.2 (B/W) Lens 3.3-12mm @ F1.4 /Auto Iris lens Day&Night...
  • Page 60 User Manual of Network Camera Dimension(mm) φ156 × 134.5 φ6.2” × 5.33” (3.08lbs) Weight 1400g...

  • Page 61: Dimension

    User Manual of Network Camera Dimension...

  • Page 62: Ds-2Cd752Mf-Fb

    User Manual of Network Camera DS-2CD752MF-FB Specification Model DS-2CD752MF-FB Parameter Camera Image Sensor 1/3 inch CMOS Effective Pixels 1600 (H) × 1200 (V) Min. Illumination 0.5Lux @ F1.2, 0.1Lux @ F1.2, sensitization ×5 Lens 3-9mm@ F1.4 / Fixed Iris lens Day&Night...
  • Page 63 User Manual of Network Camera Dimension(mm) φ156 × 134.5 φ6.2” × 5.33” (3.08lbs) Weight 1400g...

  • Page 64: Dimension

    User Manual of Network Camera Dimension...

  • Page 65: Ds-2Cd752Mf-E

    User Manual of Network Camera DS-2CD752MF-E Specification Parameter Model DS-2CD752MF-E Camera Image Sensor 1/3 inch CMOS Effective Pixels 1600 (H) × 1200 (V) Lens 2.8 ~ 11mm, F1.4 manual Iris lens 0.5Lux @ F1.2 Min. Illumination 0.1Lux @ F1.2, sense up × 5 Video Output 1.0Vp-p Composite Output (75Ω/BNC)

  • Page 66: Dimension

    User Manual of Network Camera (1.98lbs) Weight 900g Dimension...

  • Page 67: Ds-2Cd852F

    User Manual of Network Camera DS-2CD852F Specification Parameter Model DS-2CD852F Camera Image Sensor 1/3 inch CMOS Effective Pixels 1600 (H) × 1200 (V) 0.5Lux @ F1.2 Min. Illumination 0.1Lux @ F1.2, sense up × 5 Electronic Shutter Auto Auto Iris Lens Day&Night...

  • Page 68: Dimension

    User Manual of Network Camera Others Working Temperature -10℃ ~ 60℃ Power Supply DC12V, ±10%, Power Consumption 3W MAX Dimensions (mm) 63*59*116 Weight 650g Dimension...
  • Page 69 User Manual of Network Camera First Choice for Security Professionals...
