HIKVISION NSC-4A220-PTZIR Quick Start Manual

HIKVISION NSC-4A220-PTZIR Quick Start Manual

Network ptz camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Network PTZ Camera·Quick Start Guide
Network PTZ Camera
Quick Start Guide
UD02315N
i

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION NSC-4A220-PTZIR

Summary of Contents for HIKVISION NSC-4A220-PTZIR

  • Page 1 Network PTZ Camera·Quick Start Guide Network PTZ Camera Quick Start Guide UD02315N...

  • Page 2: Regulatory Information

    Network PTZ Camera·Quick Start Guide Quick Start Guide About this Manual This Manual is applicable to Network PTZ Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network PTZ Camera·Quick Start Guide FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 Network PTZ Camera·Quick Start Guide supplier or to a designated collection point. For more information, please see: www.recyclethis.info. Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

  • Page 5: Safety Instruction

    Network PTZ Camera·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 6 Network PTZ Camera·Quick Start Guide  Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.  Please make sure that the plug is firmly connected to the power socket.  When the product is mounted on wall or ceiling, the device shall be firmly fixed.
  • Page 7 Network PTZ Camera·Quick Start Guide  The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.  Do not place the camera in extremely hot, cold (the operating temperature shall be -10°C to +60°C), dusty or damp locations, and do not expose it to high electromagnetic radiation.

  • Page 8: Table Of Contents

    Network PTZ Camera·Quick Start Guide Table of Contents 1 Overview ..................9 1.1 Introduction ................9 1.2 Cable Descriptions ..............9 1.3 Alarm Output................10 2 Installation ..................12 2.1 Installing the Memory Card ............ 12 2.1.1 2.5-inch Network PTZ Camera ......... 12 2.1.2 3-inch Network PTZ Camera ..........
  • Page 9 Network PTZ Camera·Quick Start Guide 3.2.1 Activation via Web Browser ..........43 3.2.2 Activation via SADP Software .......... 44 3.3 Modifying the IP Address ............46 4 Accessing via Web Browser ............48 viii...

  • Page 10: Overview

    Network PTZ Camera·Quick Start Guide 1 Overview 1.1 Introduction The camera series has five appearances: 2.5-inch PTZ camera, 2.5-inch IR PTZ camera, 3-inch PTZ camera, 3-inch PTZ bullet camera and 4-inch IR PTZ camera. Integrating with an optical zoom lens, this series of cameras feature in the PTZ limits, 3D positioning, Day/Night auto switch, 3D DNR, etc., and are widely applied in various kinds of indoor environments.

  • Page 11: Alarm Output

    Network PTZ Camera·Quick Start Guide Power Cord DC12V IN Video Cable RS485 Cable . . . Alarm Cable Audio Cable Network Cable Figure 1-1 Cables of PTZ Camera  Power Cord: Supports 12V DC power supply.  Video Cable: Connect BNC Cable to test the video output. ...
  • Page 12 Network PTZ Camera·Quick Start Guide Output DC 30V JQC-3FG Relay Power Supply (10A 250VAC) Direct load OUT (n) Relay Output ~220V AC Relay Output Zero OUT (n) OUT (n) FireWire Line OUT (n) Figure 1-2 Alarm Output...

  • Page 13: Installation

    Network PTZ Camera·Quick Start Guide 2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Notes:  Do not drag the PTZ camera with its waterproof cables; otherwise the waterproof performance is affected.

  • Page 14: 3-Inch Network Ptz Camera

    Network PTZ Camera·Quick Start Guide Figure 2-2 For 2.5-inch IR PTZ Camera 2. Rotate the cover to a proper position, align the memory card with the memory card slot and insert it. Figure 2-3 Insert the Memory Card 3. Rotate the cover and push it back. 2.1.2 3-inch Network PTZ Camera Steps: Loosen three screws on the bottom of camera to reveal the...

  • Page 15: 3-Inch Network Ptz Bullet Camera

    Network PTZ Camera·Quick Start Guide Reset Debug Memory Card Figure 2-4 Memory Card of 3-inch PTZ Camera Align the memory card with the memory card slot and insert it. Fix the screws and assemble the PTZ camera. 2.1.3 3-inch Network PTZ Bullet Camera For 3-inch network PTZ bullet camera, the memory card slot is in the camera module and if you need, the memory card can be installed before the camera leaves the factory.
  • Page 16 Network PTZ Camera·Quick Start Guide Silicone Plug Decorative Rim Figure 2-5 Remove the Silicone Plugs Loosen four flange screws with a screwdriver. Remove the bubble and the decorative rim as the figure below. Decorative Rim Bubble Flange Srews Figure 2-6 Remove the Bubble and the Decorative Rim Open the memory card cover and insert the memory card into the card slot as the figures below.

  • Page 17: Installing 2.5-Inch Ptz Camera

    Network PTZ Camera·Quick Start Guide Memory Card Slot Memory Card Cover Figure 2-7 For 20× Camera Module Memory Card Slot Memory Card Cover Figure 2-8 For 4× Camera Module Close the memory card cover. Fix the four flange screws and push four silicone plugs back to assemble the PTZ camera.

  • Page 18: Wall Mounting

    Network PTZ Camera·Quick Start Guide 2.2.1 Wall Mounting Before you start: Make sure the camera is power-off before you install the camera. Notes:  For cement wall, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket.
  • Page 19 Network PTZ Camera·Quick Start Guide OPEN Base Plate on the Bottom of the Dome Front View of Base Plate Figure 2-10 Base Plate for 2.5-inch IR PTZ Camera 2. Align the cable hole on the base plate with the hole on the bracket for wiring.
  • Page 20 Network PTZ Camera·Quick Start Guide Figure 2-12 For 2.5-inch IR PTZ Camera 3. Route the cables through the cable hole. 4. Align the PTZ camera with the base plate. Rotate the PTZ camera clockwise to the base plate, and the PTZ camera is secured with the base plate by three locks on the plate.
  • Page 21 Network PTZ Camera·Quick Start Guide OPEN LOCK Figure 2-14 Secure the 2.5-inch IR PTZ Camera 5. Secure the mounting base to the wall with four PA4*25 screws (supplied). Figure 2-15 Install the Mounting Base 6. Install the PTZ camera to the bracket. 1).

  • Page 22: Ceiling Mounting

    Network PTZ Camera·Quick Start Guide Figure 2-16 Secure the Mounting Base 2.2.2 Ceiling Mounting Purpose: There are two ceiling mounting types provided for the camera, we take the mounting without the junction box as the example. Before you start: The ceiling mounting is applicable to the indoor/outdoor solid ceiling construction.
  • Page 23 Network PTZ Camera·Quick Start Guide Figure 2-17 Cabling for 2.5-inch PTZ Camera Figure 2-18 Cabling for 2.5-inch IR PTZ Camera  Ceiling Mounting without Junction Box Steps: 1. Rotate the base plate counterclockwise to separate it from the PTZ camera, as shown in the Figure 2-9 and Figure 2-10. 2.
  • Page 24 Network PTZ Camera·Quick Start Guide Figure 2-19 Attach the Drill Template 3. Drill a cable hole in the ceiling according to the circle A on the template if you want to route the cables through the ceiling. Pull out the cable slot cover if you want to route the cables on the surface of the ceiling, as shown below.
  • Page 25 Network PTZ Camera·Quick Start Guide Cable Slot Cover Figure 2-21 For 2.5-inch IR PTZ Camera 4. Attach the base plate to the ceiling and secure it with the supplied 3 self-tapping screws by aligning with 3 screw holes in the ceiling, and the front arrows on the drill template and base plate should be aligned together as well, as shown in Figure 2-22 and Figure 2-23.
  • Page 26 Network PTZ Camera·Quick Start Guide Figure 2-23 For 2.5-inch IR PTZ Camera 5. Route the cables through the cable hole. 6. Align the PTZ camera with the base plate. Rotate the PTZ camera clockwise into the base plate, and the PTZ camera is secured with the base plate by three locks on the plate.

  • Page 27: Installing With Junction Box

    Network PTZ Camera·Quick Start Guide 2.2.3 Installing with Junction Box Notes:  The thickness of the ceiling shall be 5 to 40 mm.  Please make sure that the ceiling is strong enough to withstand at least 4 times the weight of the PTZ camera and the bracket. Steps: 1.
  • Page 28 Network PTZ Camera·Quick Start Guide OPEN Base Plate on the Bottom of the Dome Front View of Base Plate Figure 2-26 For 2.5-inch IR PTZ Camera 2. Attach the drill template (supplied) to the place where you want to fix the PTZ camera, and make sure the front arrow appoints to the monitoring area.
  • Page 29 Network PTZ Camera·Quick Start Guide the direction of Figure 2-28. Make sure the front arrows on the drill template and junction box should be aligned together as well. Figure 2-28 Fix the Junction Box 5. Connect the cables and route the cables clockwise through the hooks and fix the camera and the junction box with three hooks.

  • Page 30: Installing 3-Inch Ptz Camera

    Network PTZ Camera·Quick Start Guide 2.3 Installing 3-inch PTZ Camera 3-inch PTZ camera supports ceiling mounting and in-ceiling mounting. Note: Wall mounting, installation with junction box, and installation with tripod are supported for 3-inch PTZ camera. The corresponding accessories shall be purchased separately. 2.3.1 Ceiling Mounting Notes: ...
  • Page 31 Network PTZ Camera·Quick Start Guide Figure 2-30 Attach the Drill Template 3. Insert the expansion screws into the ceiling. (Optional) 4. Insert four PM4*10 screws into the ceiling and fix the base plate, as shown in Figure 2-31. Make sure the FRONT arrow of the base plate is of the same direction as the arrow of the drill template.

  • Page 32: In-Ceiling Mounting

    Network PTZ Camera·Quick Start Guide clockwise into the base plate, and the PTZ camera is secured with the base plate by three locks on the plate. 6. Fix the screws on the side with a screwdriver, as shown in Figure 2-32.
  • Page 33 Network PTZ Camera·Quick Start Guide Figure 2-33 Drill Template 2. Fix the base plate onto the in-ceiling bracket with the four screws in the package (supplied). Make sure that the cable holes of the base plate are aligned to the cable holes of the bracket, as shown in Figure 2-34.
  • Page 34 Network PTZ Camera·Quick Start Guide 4. Align the PTZ camera with the base plate. Rotate the PTZ camera clockwise into the base plate, and the PTZ camera is secured with the base plate by three locks on the plate. 5. Fix the screws on the side with a screwdriver, as shown in Figure 2-35.

  • Page 35: Installing 3-Inch Ptz Bullet Camera

    Network PTZ Camera·Quick Start Guide 2.4 Installing 3-inch PTZ Bullet Camera 2.4.1 Dimension of 3-inch PTZ Bullet Camera Two structures of the 3-inch network PTZ bullet cameras are available: wall-mounted PTZ bullet camera and base-mounted PTZ bullet camera. Please select the proper PTZ bullet camera and the installation way according to its working environment.

  • Page 36: Wall Mounting

    Network PTZ Camera·Quick Start Guide 4-φ7 Unit: mm Figure 2-38 Base-mounted PTZ Bullet Camera 2.4.2 Wall Mounting Before you start: The wall-mounted PTZ bullet camera can be installed on cement wall and pole mounting. The installing environment shall meet the following conditions: ...

  • Page 37: Base Mounting

    Network PTZ Camera·Quick Start Guide Figure 2-39 Drill Screw Holes 2. Route the cables through the camera bracket and cover the four hex nuts with flat washers. 3. Fix the camera on the wall by knocking the expansion screws into the wall through the bracket, as shown in the figure below.
  • Page 38 Network PTZ Camera·Quick Start Guide Base-mounted PTZ bullet camera can be installed on hard plane structures such as cement surface. Note: Please make sure that the plane structure is strong enough to withstand more than 8 times the weight of the PTZ camera and the bracket.

  • Page 39: Installing 4-Inch Ir Ptz Camera

    Network PTZ Camera·Quick Start Guide 2.5 Installing 4-inch IR PTZ Camera 4-inch IR PTZ camera supports ceiling mounting and in-ceiling mounting. Note: Wall mounting, pendant mounting, and installation with junction box are supported for 4-inch IR PTZ camera. The corresponding accessories shall be purchased separately.

  • Page 40: In-Ceiling Mounting

    Network PTZ Camera·Quick Start Guide 2.5.2 In-ceiling Mounting Notes:  At least 250mm of height shall be reserved for in-ceiling mounting of 4-inch IR PTZ camera.  The thickness of the ceiling must range from 5 to 40mm.  The ceiling must be strong enough to withstand more than 4 times the weight of the PTZ camera and its accessories.
  • Page 41 Network PTZ Camera·Quick Start Guide Figure 2-44 Drill Template 3. Align the cable holes of the base plate to the cable holes of the in-ceiling bracket and then fix the base plate onto the bracket with the four screws in the package (supplied), as shown below. Figure 2-45 Fix the Base Plate to In-ceiling Bracket 4.
  • Page 42 Network PTZ Camera·Quick Start Guide ② Fix the Screw ① OPEN LOCK Figure 2-46 Fix the Camera 7. Place the camera and the bracket into the hole drilled in step 2, and rotate the screws clockwise to fix the camera. 8.

  • Page 43: Setting The Ptz Camera Over The Lan

    Network PTZ Camera·Quick Start Guide 3 Setting the PTZ Camera over the LAN Notes:  You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 44: Activating The Camera

    Network PTZ Camera·Quick Start Guide 3.2 Activating the Camera Purpose: You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via client software are supported.

  • Page 45: Activation Via Sadp Software

    Network PTZ Camera·Quick Start Guide 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 46 Network PTZ Camera·Quick Start Guide Figure 3-3 SADP Interface 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 47: Modifying The Ip Address

    Network PTZ Camera·Quick Start Guide 4. Click OK to save the password. Note: You can check whether the activation is completed on the popup window. If activation failed, please make sure that the password meets the requirement and then try again. 3.3 Modifying the IP Address Purpose: To view and configure the camera via LAN (Local Area Network), you...
  • Page 48 Network PTZ Camera·Quick Start Guide Figure 3-4 Modify the IP Address 4. Input the password and click Save to activate your IP address modification.

  • Page 49: Accessing Via Web Browser

    Network PTZ Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari...
  • Page 50 Network PTZ Camera·Quick Start Guide Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the network PTZ camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
