Summary of Contents for HIKVISION Network Dome Camera
- Page 1 Network Dome Camera Installation Manual V3.0.0 Hangzhou Hikvision Digital Technology Co., Ltd. http://www.hikvision.com 2010-04...
- Page 2 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies DS-2CD763PF(NF)-E(I), DS-2CD753F-E(I), DS-2CD793PF(NF)-E(I), DS-2CD793PFWD(NFWD)-E(I) and DS-2CD733F-E(I) Network Camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
-
Page 3: Safety Instruction
4. Please make sure that the plug is firmly inserted into the power socket. 5. When the product is installed on a wall or ceiling, the device should be firmly fixed. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 4 7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 5 9. Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment should be replaced regularly according to their average life time. The average time varies because of differences between operating environment and usage history, so regular Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 6 Installation Manual of Network Dome Camera checking is recommended for all users. Please contact with your dealer for more details. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 7: Table Of Contents
Specification ........................8 Dimensions........................9 DS-2CD753F-E(I) ........................ 10 Specification ......................... 10 Dimensions........................11 DS-2CD793PF(NF)-E(I) ..................... 12 Specification ......................... 12 Dimensions........................13 DS-2CD793PFWD(NFWD)-E(I)..................14 Specification ......................... 14 Dimensions........................15 DS-2CD733F-E(I) ........................ 16 Specification ......................... 16 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 8 Installation Manual of Network Dome Camera Dimensions........................17 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 9: Chapter 1 Introduction
User Management: Support multilevel right management. The administrator can create up to 15 separate users with different right levels, which highly improves the system security. Compression Functions: Support 1 channel video signal and standard H.264 encoding compression, which Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 10: Applications
2. Remote surveillance for nursing homes, kindergartens and schools. 3. AI janitors. 4. AI building/district management systems. 5. Self-service systems of power plants. 6. Pipelining and warehouse monitoring. 7. Surveillance for airdrome, railway station, bus stop etc. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 11: Chapter 2 Installation
Never attempt to disassemble the camera yourself. Users are responsible for any problem caused by modification or repairing without authorization. 2.1 Camera Description and Connection Camera description: Camera Connection: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 12 IP address, port number, etc., will be reset to the factory default settings. The alarm input is a NO/NC relay. If the input is not a NO/NC relay, follow the connection diagram below: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 13: Hardware Installation
12V DC/30mA, or use AC with external relays. Equipment damage or electric shock may cause if without relays. 2.2 Hardware Installation The ceiling mount is a suitable installation method for this camera. Please stick to the following steps: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 14 2. Loosen the set screws with a hexagonal screw driver (attached with the camera), and take down the dome cover. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 15 Installation Manual of Network Dome Camera 3. While viewing the video on the monitor, adjust the camera’s view angle for your need. 4. Install the dome cover and tighten the screws. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 16: Appendix Product Specification
50HZ: 12.5fps (1280 x 960), 25fps (1280 x 720) Frame Rate 60HZ: 15fps (1280×960), 30fps (1280 x 720) Saturation, Brightness, Contrast adjustable through client software or Image Settings web browser Network Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 17: Dimensions
IEC60068-2-75Eh,50J;EN50102, up to IK10 Protection IR Range -I: Within 10-20 meters (32.8-65.6ft) Dimensions(mm) φ140 × 114 (φ5.5" × 4.9") Weight 1400g (3.08lbs) *”I” series supports 10-20 meters (32.8-65.6ft) IR Range Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 18: Ds-2Cd753F-E(I)
(1280×720) Saturation, Brightness, Contrast adjustable through client software or Video Parameter web browser Network Storage Support SD/SDHC, NAS (ISCSI optional) Intelligent Alarm Motion Detection, Video Loss, Network Broken, IP address conflict, Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 19: Dimensions
IEC60068-2-75Eh,50J;EN50102, up to IK10 Protection IR Range -I: Within 10-20 meters (32.8-65.6ft) Dimensions(mm) φ140 × 114 (φ5.5" × 4.9") Weight 1400g (3.08lbs) * ”I” series supports 10-20 meters (32.8-65.6ft) IR Range Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 20: Ds-2Cd793Pf(Nf)-E(I)
60HZ:30fps (704 × 480) Saturation, Brightness, Contrast adjustable through client software or Image Settings web browser Network Storage Support SD/SDHC, NAS (ISCSI optional) Intelligent Alarm Motion Detection, Video Loss, Network Broken, IP address conflict, Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 21: Dimensions
IEC60068-2-75Eh,50J;EN50102, up to IK10 Protection IR Range -I: Within 20-30 meters (65.6-98.4ft) Dimensions(mm) φ140 × 114 (φ5.5" × 4.9") Weight 1400g (3.08lbs) *”I” series supports 20-30 meters (65.6-98.4ft) IR Range Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 22: Ds-2Cd793Pfwd(Nfwd)-E(I)
Installation Manual of Network Dome Camera DS-2CD793PFWD(NFWD)-E(I) Specification Model DS-2CD793PFWD-E(I) / DS-2CD793NFWD-E(I) Parameter 4CIF 1/3 ”CCD WDR Day&Night Vandal-proof Network Dome Camera Camera Image Sensor 1/3" SONY vertical double density interline CCD Signal System PAL / NTSC 0.1Lux @(F1.2, AGC ON) 0.14Lux @(F1.4, AGC ON) -
Page 23: Dimensions
IEC60068-2-75Eh,50J;EN50102, up to IK10 Protection IR Range -I: Within 10-20 meters (32.8-65.6ft) Dimensions(mm) φ140 × 114 (φ5.5" × 4.9") Weight 1400g (3.08lbs) *”I” series supports 10-20 meters (32.8-65.6ft) IR Range Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 24: Ds-2Cd733F-E(I)
Installation Manual of Network Dome Camera DS-2CD733F-E(I) Specification Model DS-2CD733F-E(I) Parameter VGA 1/4” CMOS Day&Night Vandal-proof Network Dome Camera Camera Image Sensor 1/4” Progressive Scan CMOS Electronic Shutter 1/25s ~1/100,000s 0.2Lux @(F1.2,,AGC ON) 0.27Lux @(F1.4, AGC ON) Min. Illumination -I : 0.2 Lux @(F1.2, AGC ON) , 0 Lux with IR... - Page 25 Impact Protection IEC60068-2-75Eh,50J;EN50102, up to IK10 IR Range -I: Within 10-20 meters (32.8-65.6ft) Dimensions(mm) φ140 × 114 (φ5.5" × 4.9") 1400g (3.08lbs) Weight *”I” series supports 10-20 meters (32.8-65.6ft) IR Range Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 26 Installation Manual of Network Dome Camera First Choice for Security Professionals Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
