Product description
User manual SCA - DE
Version 02 09.2006

Power supply

Model Power rating
SCA 2.2 kW / 10 A
The device must be electrically connected according to all valid regulations (VDE 0100) as well
as national stipulations.
The type of power cable must be at least H 07 RN-F. The voltage specified on the serial plate
must match the supply voltage at the installation location.
The phase must be protected from short-circuits with 10A!
• All poles of the device must be able to be disconnected from the power supply.
• Never operate a device with a faulty power cord. Have a defective power cord or plug
replaced immediately by a qualified service technician.
• M. Schaerer AG advises against the use of extension cables!sion cables! If an extension
cable must be used, nevertheless (minimum cross-section: 1.5 mm2), please observe the
cable manufacturer's data (instructions for use) and all local regulations.
• Power cords must be connected in such a way that no one can trip over them. Do not pull
the cords over corners or sharp edges, pinch them between objects or allow them to hang
loosely in a room. Do not place cables over hot objects, and protect them from oil and
aggressive cleaning agents.
• Never lift or pull the device by its power cord. Never pull the plug out of the socket by its
cord. Never touch the power cord or plug with wet hands! Never insert a wet plug into a
power socket!

Water connection / draining

If the machine is connected to a newly installed water pipe, the pipe and the supply tube must
be thoroughly rinsed so that no dirt particles can enter the machine.
The coffee maker must be connected to an installed drinking-water pipe with shutoff valve. The
machine is installed by using the mounted pressure tube and the G 1/2" screw at the pressure
relief component mounted to the tap (set to 3 bar).
If the machine is attached to a water drainage system, the supplied temperature-resistant drain
hose must be connected to the drip pan and siphon. It must be firmly attached to the drain
and slanted at a downward angle (so that the water can flow downward).
Optimal water hardness is -9°dWH (typical in Germany) or 8-12°fWH (typical in France). The
chlorine content should not exceed 100 mg per liter. Ideal pH value = 7.
All local regulations are also binding.
Water pressure:
Minimum pressure: 1 bar
Maximum pressure: 3 bar
We recommend setting the pressure relief valve to 3 bar.
Water ingress temperature:
Minimum: 10 °C
Maximum: 30 °C
www.schaerer.com
50/60 Hz 230 V AC / PNE
