KORG D1600 Guided Tour

INSERT EFFECT mode:

8 Insert, 2 Master and 1 Final mastering effect: 11 simultaneous per song!

1. Press the INSERT EFFECT key: On this page you can set Insert effect assignments for each track and assign the effect type.

2. By pressing one of the Insert effect tabs ("InsEff1", etc.) you can apply an Insert effect. Once selected, you can press the effect

name button to access the icons and editing parameters for the Insert effect program you've selected.

There are 128 preset insert effect programs to choose from, including 98 chains of up to 5 effects at once. The D1600 features

Korg's famous REMS modeling effects - accurate amp, cabinet and microphone simulations. You can edit any of the preset effect

programs, then store your edits to 128 user effect programs. Plus, many of the effects like wah can be controlled in realtime using

the D1600's exclusive Expression Pedal input!

MASTER EFFECT mode:

Send your mix through Master and Final effects - for ultimate processing!

1. Press the MASTER EFFECT / AUX key, then press the MstEff1 tab in the display. For both Master effect 1 and Master effect

2, you can select one of 32 available effects, set return levels and balance, and easily-edit the effect parameters! The "Eff1" and

"Eff2 tabs" let you set individual send levels for all sixteen tracks.

The highest-quality effect algorithms are onboard, and if you need more external processing or audio sends, there's an AUX send

for every track. The Master and Final effect programs let you polish your mix for CD-ready mastering. You can choose from 32

preset effects, and store edited effects to one of 32 user locations.

Note:

The demo song "SISTER DANCE" includes Master and Final effects. You can view the effects by pressing the MASTER

EFFECT / AUX key, followed by pressing the "MstEff1", "MstEff2" and "FinalEff" tabs. The effects used for the demo

song are referenced on page 5.
