- Page 1 HIGH SPEED SABRE SAW MODEL NO: CAT32B PART NO: 3110426 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0720 - ISS 2...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing this CLARKE Sabre Saw, suitable for cutting metal, wood, polymers and other materials. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION................... 2 GUARANTEE..................2 ENVIRONMENTAL PROTECTION............2 TABLE OF CONTENTS................. 3 SAFETY PRECAUTIONS..............4 OVERVIEW................... 6 AIR SUPPLY REQUIREMENTS............. 7 ASSEMBLY................... 8 OPERATION..................9 MAINTENANCE.................10 TROUBLESHOOTING................ 11 PARTS LIST & DIAGRAM..............12 SPECIFICATIONS................14 DECLARATION OF CONFORMITY..........15 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 4: Safety Precautions
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately: - do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 5 • Moving to another work area. • Passing the saw to another person. 10. Never use the saw if it is defective or operating abnormally. 11. Always ensure the saw has stopped before putting it down. 12. The saw should be repaired if required by qualified service personnel. 13.
-
Page 6: Overview
Your sabre saw has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 7: Air Supply Requirements
COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND A COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source. •... -
Page 8: Assembly
1. Removethe plastic blanking plug from the connection port of the tool. 2. Pour 2-3 drops of CLARKE airline oil into the air inlet. This should be done regardless of whether or not a lubricated air supply is to be used. -
Page 9: Operation
4. Connect the other end of the hose to the compressor. (A whip hose with a quick fit coupling is available from your CLARKE dealer). 5. Turn on the air supply and check for air leaks. Rectify any found before proceeding. -
Page 10: Maintenance
STORAGE If the saw is to be stored or is idle for longer than 24 hours, run a few drops of Clarke air-line oil into the air inlet and depress the trigger in order to lubricate the internal parts. When not in use, the saw should be disconnected from the air supply and stored in a dry place out of the reach of children. -
Page 11: Troubleshooting
Tool will not shut off. 1. O-rings damaged or 1. Return to Clarke dealer ill-fitting in seat. for repair. REPLACEMENT BLADES Replacement blades are available from your CLARKE dealer: • Part no. 3110429 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 12: Parts List & Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 13 COMPONENT PARTS Description Description Valve screw cap Blade chuck cover O-ring Screw O-ring Housing Air controller Piston assembly Valve spring Set screw Valve stem Hexagonal key O-ring Guide plate O-ring Blade chuck Valve bush Work guide Inlet bush Saw blade (24 or 32 teeth) Cap screw Hexagonal key Washer...
-
Page 14: Specifications
13 mm Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
