  • Page 1 ® ® ® DVI Extender Over Fiber EXT-DVI-1500HD User Manual...
  • Page 2 Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging, and any accompanying doc u men ta tion without prior written notice. DVI 1500 Extender is a trademark of Gefen, LLC © 2011 Gefen, LLC. All rights reserved.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction / Operation Notes Features Sender Panel Descriptions Receiver Panel Descriptions Connecting and Operating the DVI 1500 Network Cable Wiring Diagram Specifi cations Warranty...
  • Page 4: Introduction / Operation Notes

    INTRODUCTION The Gefen DVI•1500 allows a single link video signal to be extended over long distances by using a multimode with LC termination. Fiber Optics technology allows the DVI•1500 to carry video signals over long distances that would not be possible with traditional CAT5 extension.
  • Page 5: Features

    FEATURES Features • Extends any DVI (digital visual interface) compliant device up to 1640 feet/500 meters (330 feet with HDCP) from the computer • Uses a four-strand multimode LC-LC fi ber optic cable for video signals • Uses one CAT-5 cable for DDC and control signals •...
  • Page 6: Sender Panel Descriptions

    SENDER PANEL DESCRIPTIONS Front Panel Power LED Indicator Status LED Indicator Back Panel DVI Input RJ-45 Port Port Fiber Optic LC-LC Terminals 5V DC Power Input...
  • Page 7: Receiver Panel Descriptions

    RECEIVER PANEL DESCRIPTIONS Front Panel Power LED Indicator Status LED Indicator Back Panel RJ-45 DVI Output Port Port Fiber Optic LC-LC Terminals 5V DC Power Input...
  • Page 8: Connecting And Operating The Dvi 1500

    Power on the display, then the source. No further adjustments are necessary to operate the DVI 1500. 4X FIBER OPTIC LC-LC CABLE (Up To 1,640 FT) CAT-5 CABLE (Up To 1,640 FT, 330 FT w/HDCP) DVI CABLE Computer Receiver DVI Monitor Sender EXT-DVI-1500HD...
  • Page 9: Network Cable Wiring Diagram

    Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B specifi cation. Please adhere to the table below when fi eld terminating cable for use with Gefen products. Failure to do so may produce unexpected results and reduced performance.
  • Page 10: Specifi Cations

    SPECIFICATIONS Video Amplifi er Bandwidth ............225 MHz maximum Input Video Signal ................1.2 Volts p-p Input DDC Signal ................. 5 Volts p-p (TTL) Single Link Range ............1080p, 2k, 1920 x 1200 DVI Connector ..............DVI-D (19 pin) female Video Link Connector ..................
  • Page 12: Warranty

    Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
  • Page 13 Rev X6 This product uses UL listed power supplies.
