Summary of Contents for Doro 565 COLOUR

  • Page 1 Manual...
  • Page 3 565 colour...
  • Page 5 English (see page 7-35) 1 Left menu button/OK 5 Intercom and On/Off 2 Talk/Redial button 6 Right menu button/erase/ phone book 3 Recall 7 Scroll button 4 Hands free button...
  • Page 6: Table Of Contents

    SMS messages Settings Other Direct call......22 Troubleshooting ....34 Wallpaper......23 Specific Absorption Rate Handset ringer ....23 (SAR) ........35 Key tone......24 Guarantee......35 Auto-talk ......24 Handset name ....24 Language......25 Message Tone ....25 www.doro.com...
  • Page 7: Installation

    5. Connect the line cord to the telephone plug and the socket on the base unit. 6. Plug into the telephone network wall socket. 7. To select a language please refer to page 25. 8. To set the time/date please refer to page 31. www.doro.com...
  • Page 8 Do not place the base unit in areas where it will be exposed to direct sunlight or other major heat sources! In order to conserve battery power, the display is very dark in standby mode. ∧ If you wish to illuminate the display press any button on the handset, e.g. www.doro.com...
  • Page 9: Belt Clip

    When the telephone is installed for the first time, the batteries must be charged for 24 hours before using the telephone. Use original batteries only. The guarantee does not cover any damage caused by incorrect use of batteries. Please dispose of any batteries in a responsible and environmentally friendly manner. www.doro.com...
  • Page 10: Battery Indicator

    If the handset is carried to far from the base unit during a call, the sound quality may deteriorate and a warning tone will be heard. Unless the handset is moved closer to the base unit within a few seconds the call will be cut off. www.doro.com...
  • Page 11: Headset

    This function is used to help locate the handset or to page the person carrying the handset. The signal will stop automatically after a while or if on the handset is pressed. The page can also be cancelled by pressing on the base unit again. www.doro.com...
  • Page 12: The Display

    Hands free Function. New SMS messages received. Flashes when inbox is full. Message indication. Alarm function enabled. Battery charge indicator Doro 1 Headset name (user selectable) and handset number. Menu Describes the function of the button shown below the display. e.g. Menu.
  • Page 13: Operation

    1. Press and hold until the list of recently dialled numbers is displayed. Scroll ∧ ∨ to the required telephone number using 2. Press to dial the displayed number. Press Options to delete or store to the Phone book. www.doro.com...
  • Page 14: Key Lock

    It is therefore essential that there are no loud noises in the immediate vicinity of the telephone, as this will disrupt the speaker function. www.doro.com...
  • Page 15: Phonebook

    9........W X Y Z w x y z 9 * ........* ; + & % = < > ? € $ [ ] { } \ ~ ^ | 0........[Space character] 0 #........Change between upper/lower case www.doro.com...
  • Page 16 2. Scroll through the entries in the phone book using . Press Options. ∧ ∨ 3. Scroll to Delete using . Press Ok. ∧ ∨ 4. Select Current or All using . Press Ok. 5. Press Ok to confirm. You can also display details and free memory status. www.doro.com...
  • Page 17: Menu

    Registration To register and de-register additional handsets. Extra Settings for time, date and alarm. *Only functions in certain countries and also requires special subscription. ∧ If you wish to illuminate the display press any button on the handset, e.g. www.doro.com...
  • Page 18: Call Lists/Caller Id

    ∧ ∨ 4. If you wish to delete a specific entry scroll to the number using . Press Options. ∧ ∨ 5. Scroll to Delete Current or Delete All using . Press Ok. 6. Press Ok again to confirm. www.doro.com...
  • Page 19 . Press Ok. ∧ ∨ 3. Scroll to the required telephone number using 4. Press to dial the displayed telephone number. 5. If you do not wish to dial any displayed number press Back repeatedly to return to standby mode. www.doro.com...
  • Page 20: Sms Messages

    Reply: Reply to the message, please refer to Writing a new SMS. Forward: Please refer to Writing a new SMS. Save Number. Store details in the phone book. Please refer to Storing numbers in the Phone book. Exit Alternatively you can also press Menu and scroll to Messages. www.doro.com...
  • Page 21 00 or left out entirely. Deleting SMS messages ∨ 1. Press ∧ ∨ 2. Scroll to SMS Settings using . Press Select. ∧ ∨ 3. Scroll to Delete all using . Press Select. 4. Press Ok to confirm. www.doro.com...
  • Page 22: Settings

    2. Scroll to Handset Set using . Press Select. ∧ ∨ 3. Scroll to Baby Call using . Press Ok. ∧ ∨ 4. Scroll to Enable using . Press Ok. Turning the function off 1. Press Menu. 2. Press Quit. www.doro.com...
  • Page 23: Wallpaper

    . Press Select to confirm. Please note! Some of the telephone’s ringer melodies do not follow the line signal, ie: the handset may continue ringing for up to 10 seconds after answering a call on an a different telephone. www.doro.com...
  • Page 24: Key Tone

    3. Scroll to Handset Name using . Press Ok. 4. Write your message. Press the corresponding number button one or more times for the first letter (please refer to the table on page 15). 5. Press Save to confirm. www.doro.com...
  • Page 25: Language

    1. Press Menu. ∧ ∨ 2. Scroll to Handset Set using . Press Select. ∧ ∨ 3. Scroll to SMS Alert using . Press Ok. ∧ ∨ 4. Scroll to required setting using . Press Ok to confirm. www.doro.com...
  • Page 26: Base Settings

    . Press Ok. ∧ ∨ 4. Scroll to Auto Pause using . Press Ok. 5. Enter the base unit PIN code (0000 by default). Press Ok. 6. Enter the required preset number (up to 5 digits). Press Ok to confirm. www.doro.com...
  • Page 27: Dialling Method

    4. Barring Number will be displayed. Press Ok. 5. Enter the base unit PIN code (0000 by default). Press Ok. ∧ ∨ 6. Scroll to required entry using . Press Ok. 7. Enter number (up to 5 digits). Press Ok to confirm. www.doro.com...
  • Page 28: Alternate Network Routing (Lcr)

    If the dialling code to be replaced is left empty the telephone will dial all numbers with the added LCR prefix. This feature is useful when the telephone is connected to a PBX where an access number is required. www.doro.com...
  • Page 29: Base Unit Pin Code

    1. Press Menu. ∧ ∨ 2. Scroll to Base Settings using . Press Select. ∧ ∨ 3. Scroll to Default Settings using . Press Ok. 4. Enter the base unit PIN code (0000 at default). 5. Press Ok to confirm. www.doro.com...
  • Page 30: Registration

    3. Scroll to De-register using . Press Ok. 4. Enter the base unit PIN code (0000 by default). Press Ok. 5. Select the required handset by pressing the corresponding digit on the handset keypad. 6. Press Ok to confirm. www.doro.com...
  • Page 31: Extra

    ∧ ∨ 2. Scroll to Extra using . Press Select. ∧ ∨ 3. Scroll to Date Set or Time Set using . Press Ok. 4. Enter the relevant date or time on the handset keypad. Press Save to confirm. www.doro.com...
  • Page 32: Expanded System(+1

    Refer to the Registration chapter for more information. If you wish to use several handsets with one base unit, you should ensure that the base unit is centrally positioned in order to evenly divide the base unit range among the handsets. www.doro.com...
  • Page 33: Intercom Calls

    By pressing to disconnect one party, any one of the handsets can terminate the conference call and let the other continue the conversation with the external party. www.doro.com...
  • Page 34: Other

    Try connecting another telephone, known to be in working order, to the line socket. If that phone works, then it is likely that the equipment is faulty. If the telephone still does not work, contact the place of purchase. Don’t forget the receipt or a copy of the invoice. www.doro.com...
  • Page 35: Specific Absorption Rate (Sar)

    This telephone measures 0.1 W/kg (measured over 10g tissue). The limit value set by the WHO is 2W/kg (measured over 10g tissue). Declaration of conformity Doro hereby declares that the product Doro 565 colour conforms with the essential requirements and other relevant regulations contained in directive 1999/5/EC.
  • Page 36: Australia And New Zealand

    (As a matter of precaution, we recommend disconnecting the telephone during a thunderstorm). This guarantee does not affect your statutory rights. AUSTRALIA NEW ZEALAND DORO Australia Pty Ltd Atlas Gentech (NZ) Limited PO Box 6760 Private Bag 14927 Baulkham Hills BC NSW 2153...
  • Page 37 Technical information REN (RN for New Zealand) The REN (Ringer Equivalence Number) or (RN) is of significance only if you wish to connect more than 1 telephone to your telephone line. A standard telephone line has a maximum REN capacity of 3 (RN of 5). It is possible to connect 3 devices with a REN of 1 (RN of 1) with no degradation to the product’s performance.
  • Page 38 English Version 1.0...
