Current State
STANDBY
POWER ON
5 MINUTE POWER DOWN
60 SECOND POWER OFF
SHUTTER CLOSED
SHUTTER OPEN
POWER ON,
SHUTTER CLOSED,
FILM PROJECTOR
INTERLOCK ACTIVE
1.4 Serial Communications
The controller UART must service communications from two sources: the RS-232 interface via the DB-9 connector on the
rear panel and the NIC interface. The NIC card controls a multiplexed that switches the UART between these two sources.
The controller firmware services three different command sets: one from the NIC card (which is not specified in this
document) and two from the RS-232 port. These two will be referred to as
interface is a verbose natural language interface that is intended for manufacturing and maintenance operations via a PC
running a terminal program attached to the port. Incoming character are typically echoed back to the terminal and a variety
of status messages are routinely sent, especially during power-up up and down sequences and when system anomalies
are detected and corrected. The
data is sent to the host unless requested.
The controller's UART is selectable at 9600 or 19200 baud, 8-bits, no parity and 1 stop bit. The receiver is interrupt driven
with a 64 byte queue. The transmitter is polled and has no queue. XON/XOFF (^Q/^S) flow control is implemented in both
directions. The DB9-F connector is wired as a standard PC computer peripheral and may be connected to a PC running
an ASCII terminal program with a straight-through serial extension cable – not a null-modem.
1.5 Film Projector Lockout
The film projector lockout feature uses an external signal control either turning the projector on/off or closing/opening the
shutter depending if the film projector lockout mode has been set to lock out or power control mode. See the command
FPOL for more details.
1.6 Enhanced Color Correction (P7)
Commands have been included to utilize Texas Instruments' Enhanced Color Correction Algorithm. When viewing
REC709 images use Entertainment Experiences' film look target color gamut by selecting index 5. When viewing
Tristimulus images use Entertainment Experiences' XYZ target color gamut by selecting index 6. See the ECC command
for more details.
BOXLIGHT PRO80S3 Projector Preliminary User's Manual
Power and Shutter Operation
Power LED Action
Serial Command – ON
RED Rocker Switch - depress Left Side ½ second or more
IR Remote - depress POWER 2 seconds or more
Serial Command – OFF
GREEN Rocker Switch - depress Left Side ½ second or more
IR Remote - depress POWER 2 seconds or more
Serial Command – ON or OPEN
Rocker Switch - depress Right Side ½ second or more (shutter OPEN)
IR Remote – depress BLANK (if IR enabled)
YELLOW
Serial Command – OFF
Rocker Switch - depress Left Side ½ second or more
IR Remote - depress POWER 2 seconds or more
Wait 60 seconds – no additional action required
Serial Command – ON
YELLOW
Rocker Switch - depress Left Side ½ second or more
IR Remote - depress POWER 2 seconds or more
Serial Command – OPEN
GREEN or
Rocker Switch - depress Right Side ½ second or more (shutter OPEN)
YELLOW
IR Remote - depress BLANK (if IR enabled)
Serial Command – CLOSE
GREEN Rocker Switch - depress Right Side ½ second or more (shutter OPEN)
IR Remote - depress FREEZE (if IR enabled)
Serial Command – no command available
Rocker Switch - depress Right Side 5 seconds or more to override Film
GREEN
Projector Interlock
IR Remote - no command available
machine
interface is a terse command set. Incoming characters are not echoed and no
human machine
and commands. The
Resulting State
POWER ON
5 MINUTE POWER DOWN
POWER ON
Power Down Cancelled
60 SECOND POWER OFF
STANDBY
POWER ON
Lamp re-strike after 90 second
lamp cool-down
SHUTTER OPEN
Cancel 5 MINUTE POWER
DOWN
if in progress
SHUTTER CLOSED
SHUTTER OPEN
Override Film Projector
Lockout
human
