BOXLIGHT PRO80S3 User Manual page 27

Three-chip dlp projector

Advertisement

> rdtcgd 8
GREEN = .337,.642,.000
RED = .642,.353,.000
BLUE = .140,.034,.000
MAGENTA = .000,.000,.000
CYAN = .000,.000,.000
YELLOW = .000,.000,.000
WHITE = .287,.326,.000
TOLBOX0 = .277,.336
TOLBOX1 = .297,.336
TOLBOX2 = .297,.316
TOLBOX3 = .277,.316
Use TOL BOX
Notice: 'P7 TCGD Data - 6300K - Copyright (c) 2006 Delta Products Corp.'
TDNLD
Download a User-definer Target Color Gamut Data Set for storage in controller board's EEPROM. The command takes a
decimal parameter – the target index between 10 and 13 corresponding to the index used in the ECC command. When the
command is entered, the operator is prompted to send 140 bytes of data. A description of the data packet can be found in
the Texas Instruments document –
Component Set
[Dwg #2503986, Rev. J or later] in the Target Color Gamut Data command description. Note that the first
byte listed here is 8816. This is used when actually communicating with the Formatters and should not be sent with the
TDNLD command. Byte 2 – the LS Byte of the GREEN CIE X coordinate is the first value sent. The command description
only defines bytes 2 through 140 – a total of 139. Add an extra 0 byte to the end so that full 140 bytes are sent. Unspecified
parameters such as GAIN values, CMY coordinates or the Copyright Notice should be sent as zeros.
The values can be manually typed from the terminal or stored in a file and sent to the controller board using the terminal's
"Send Text File" utility. The 140 bytes sent may be <SPACE>, <TAB>, <CR> or <LF> separated.
Characters typed of sent will NOT be echoed.
Field Contents
X
GREEN
Y
GAIN
X
RED
Y
GAIN
X
BLUE
Y
GAIN
X
MAGENTA
Y
GAIN
X
CYAN
Y
GAIN
X
YELLOW
Y
GAIN
X
WHITE
Y
GAIN
BOXLIGHT PRO80S3 Projector Preliminary User's Manual
Download User-Defined Target Color Gamut Data
Product Specification for DDP1000, DDP1010, DDP1011 Based Modular Formatter
BYTES
Positions
2
Bytes 1-2
2
Bytes 3-4
2
Bytes 5-6
2
Bytes 7-8
2
Bytes 9-10
2
Bytes 11-12
2
Bytes 13-14
2
Bytes 15-16
2
Bytes 17-18
2
Bytes 19-20
2
Bytes 21-22
2
Bytes 23-24
2
Bytes 25-26
2
Bytes 27-28
2
Bytes 29-30
2
Bytes 31-32
2
Bytes 33-34
2
Bytes 35-36
2
Bytes 37-38
2
Bytes 39-40
2
Bytes 41-42
TDNLD Data Format
Field Contents
RESERVED – 00H
W TOL BOX 1
W TOL BOX 2
W TOL BOX 3
W TOL BOX 4
RESERVED – 00H
TOL BOX MODE
RESERVED – 00H
Copyright Notice –
ASCII – 0 PADDED
RESERVED – 00H
BYTES
6
X
2
Y
2
X
2
Y
2
X
2
Y
2
X
2
Y
2
6
1
1
64
4
TDNLD
Positions
Bytes 43-48
Bytes 49-50
Bytes 51-52
Bytes 53-54
Bytes 55-56
Bytes 57-58
Bytes 59-60
Bytes 61-62
Bytes 63-64
Bytes 65-70
Byte 71
Byte 72
Bytes 73-136
Bytes 137-140
Page 27 of 33
