Summary of Contents for BOXLIGHT ProjectoWrite5

  • Page 1 ProjectoWrite5 151 NE State Hwy 300, Ste A Belfair, WA 98528 360.464.2119 www.boxlight.com...
  • Page 2: About The Owner's Manual

    Projector About the Owner’s Manual Please read the owner‟s manual thoroughly to ensure correct use of the projector and its features. After reading, store the owner‟s manual in a safe place for future reference. Features 1. Designed for tough environments 2.
  • Page 3: Table Of Contents

    Contents About The Owner’s Manual Contents.................................1 Contents of Your Box...........................3 Safety Instructions............................4 Safety Labels..............................5 Part Names..............................7 Projector.................................7 Control Panel.............................8 Rear................................9 Setting Up..............................10 Arrangement............................10 Power ON / OFF............................11 Setting Up The Projector........................12 Ceiling Mounted Installation Guide......................13 Adjusting The Projector’s Elevation.....................14 How To Connect........................
  • Page 4: Contents

    Contents MENU (PC Mode)............................59 Picture Menu (PC Mode)..........................59 Audio Menu (PC Mode)..........................60 Setting Menu (PC Mode)..........................61 Picture Menu (Video Mode)........................62 Audio Menu (Video Mode)........................63 Setting Menu (Video Mode)........................64 Advanced Menu............................65 Presentation Menu.............................69 Security Menu............................71 PIN Key In Operation..........................75 Network Control Software Application …………………...............76 Browser Control............................77 Home(Status)..............................78 Control Panel..............................79...
  • Page 5 S C a ofn ete y nItn sso tr f u Y c o tu io rn B sox Check-list of your accessories Please make sure that the following items are included in the box. If any items are missing, contact your dealer. 1.
  • Page 6: Safety Instructions

    Safety Instructions The projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. WARNING / CAUTION 1.
  • Page 7: Safety Labels

    Safety Labels WARNING Do not look through the lens when the lamp is on. Never look through the lens when the lamp is on. The powerful light could adversely affect vision. Use special caution in households where children are present. Avoid shock or impact on the projector.
  • Page 8 Safety Labels Safety labels are used on or within the projector to alert you to items or areas requiring your attention. WARNING LABEL EMI LABEL LAMP DOOR WARNING LABEL...
  • Page 9: Part Names

    Part Names Projector Control panel Operating system. Lens cover Attach when not using to protect the lens from becoming dirty or damaged. Filter cover Prevents dust and other foreign particles from being drawn into projector. Remove the filter cover to clean the air filter.
  • Page 10: Control Panel

    Part Names Control Panel POWER INDICATOR LAMP INDICATOR KEYSTONE AUTO Adjust the vertical keystone with menu-up, Automatically adjust the setting to match menu-down. the current input. VOLUME + / - (POWER) Increase or decrease sound. Power On / Off. INPUT LAMP INDICATOR Select input source: Indicates a status in the internal projector...
  • Page 11: Rear

    Part Names Rear REAR IR RECEIVER Please see page76 Network Control USB Port (USB-B Type) Application for details. Connect a USB cable to a computer to control computer Interactive functions. S-VIDEO RS-232C Input the S-Video signal from a video source. Serial data port for controlling the projector with a computer or other RS-232 control AUDIO IN 3, R / L...
  • Page 12: Setting Up

    Setting Up Arrangement 1. Before installation, make sure that the projector is turned off and the power cord is disconnected. 2. Do not set up and move the projector, while it is hot. 3. The distance between the projector and screen determines the actual image size. Refer to the table below to determine the screen size at a given distance.
  • Page 13 Setting Up Arrangement 1. Before installation, make sure that the projector is turned off and the power cord is disconnected. 2. Do not set up and move the projector, while it is hot. 3. The distance between the projector and screen determines the actual image size. Refer to the table below to determine the screen size at a given distance.
  • Page 14: Power On / Off

    Setting Up Power ON / OFF Turning on the power POWER indicator 1. Make sure that power cord is firmly and correctly connected to the projector. Outlet 2. Remove the lens cover, and the POWER AC inlet indicator will light up in green. 3.
  • Page 15: Setting Up The Projector

    Setting Up Setting Up The Projector The projector supports the following four different projection methods. 1. Front projection 3. Rear ceiling projection 2. Rear projection 4. Front ceiling Projection Special installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details.
  • Page 16: Ceiling Mounted Installation Guide

    Setting Up Ceiling Mounted Installation Guide Attach ceiling mount at four-suspension bracket fixing points when suspending from a ceiling. Special installation is required in order to suspend the projector from the ceiling. Please ask your dealer for detals. MAX M4x8 mm For Mounting. Security Anchor The product is equipped with security anchor and PIN LOCK functions to help...
  • Page 17: Adjusting The Projector's Elevation

    Setting Up Adjusting The Projector’s Elevation Use the adjustable foot at the front of the projector to set the image height. Holding the projector, push the foot adjust CAUTION buttons to loosen the front adjustable foot. Position the front side of the projector to the * The adjustment range of front adjustable desired height.
  • Page 18: How To Connect

    Setting Up How To Connect Laptop or desktop computer Video recorder DVD Player, etc. AUDI O Out put S-VIDEO Output W hite(L)/Red(R) RS-232C termi nal RGB Output HDMI RGB Output/Input VIDEO Output AUDI O Input AUDI O Out put W hite(L)/Red(R) W hite(L)/Red(R) Video recorder, etc.
  • Page 19 Setting Up ●If the selected video image is not displayed after the projector is turned on and the correct video source has been selected, please check that the video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly. ●Many laptops do not turn on their external video ports when connected to a projector.
  • Page 20: Remote Control

    Remote Control Remote Control Battery Installation 1. Remove the battery cover. 2. Load the batteries. Make sure the poles are correctly oriented. 3. Close the battery cover. Caution ● Avoid excessive heat and humidity. ● Do not drop the remote control. ●...
  • Page 21 Remote Control Quick Key POWER If it is not in the On-Screen Display main menu, Power on / operation mode, Standby mode, Cool down mode. you could press the INPUT button as the quick key. Select input source : Press to select the item.
  • Page 22: Ez Suite

    E M Z E S N u U ite ( PC Mode) Main Menu Layout & Function Definition Main-items Function Sub-Function Description Definition Definition Photo Support Internal EZ Suite memory, Video USB compatible hard Audio Internal Memory disks, Office viewer EZ Media Support Photo, Photo...
  • Page 23: Ez Media Function: Layout & Behavior

    EZ Suite (EZ Media Function) Before to use: 1. Use the buttons on the remote control to select an item. 2. Use the ENTER button on the remote control to enter item. 3. Use the ESC button on the remote control to exit items. 1.
  • Page 24: Photo Function

    EZ Suite (EZ Media Function) 1.1 Photo Function It will show the file name / thumbnails display / file number progress bar 1. From the Photo layout. Press the buttons on the remote control to select the file. 2. While the highlighted photo file is selected, press the ENTER button on the remote control, the screen will display the selected file, and it will enter the Browse mode.
  • Page 25 Function) Photo navigator toolbar : Rotation Zoom in Previous Next Slide how Delete Copy Info Quit On/Off Press the buttons on the remote control, to highlight control icon and press the ENTER button on the remote control to select. Rotation: To rotate an image. Using the buttons on the remote control to rotate the image.
  • Page 26: Video Function

    Function) 1.2 Video Function It will show the file name/ file list /file size/ file number progress bar 1. From the Video layout. Press the buttons on the remote control, to highlight the file of video playlist and press the ENTER button on the remote control to display.
  • Page 27: Audio Function

    Function) ► While video navigator toolbar is hidden, press the on the remote control to play previous/next video file. ► Note: 1. Supports MPEG1/2/4, H264, WMV, RMVB video format, up to 1080P(20Mbps) resolution. Please refer to the multimedia support list document.
  • Page 28 Function) 1. From the Audio layout. Press the buttons on the remote control to highlight the file of audio playlist and press ENTER button to perform. Audio navigator toolbar: Previous Play fast Pause Play Play fast Next Repeat backward forward mode Previous: Play previous audio music file by pressing the button twice.
  • Page 29: Office Viewer Function

    Sound Spectrum Show the total time and indicate current playing time ► Note: 1. Supports mp3, wma, ogg, and wav audio file format. 2. Supports file sorting by file name and modification date same as photo function. *For more information, please check the page48 for Audio Setting. 1.4 Office Viewer Function Select and enter a document file that you want to browse.
  • Page 30 Operation info: ◄► Zoom In / Zoom out Crops the image, and magnifies or reduces the result of the cropping. ▲▼Page up/Page down These two buttons are used to go to the previous page or the next page in documents. Press “Enter”...
  • Page 31: Ez Display Function: Layout & Behavior

    2. EZ Display Function: Layout & Behavior Support USB Display, WiFi Display, LAN Display. EZ USB EZ WiFi EZ Display Function EZ LAN Function Description OS system Display PC Screen with USB cable Windows OS, Mac OS EZ USB Extended Display with USB Cable Wirelessly project the computer ‟s Windows OS, Mac OS EZ WiFi...
  • Page 32: Ez Usb

    2.1 EZ USB ► Note: EZ USB support MS Windows OS, Apple Mac OS 1. Select the EZ USB item at EZ Display interface. It will show the Ready for display image on the screen.
  • Page 33: Ez Wifi

    2. Connect the computer's USB port to the projector's USB (mini-USB) port via the USB A to USB mini-B type USB Cable. 3. Computer‟s system will examines newly discovered removable media and devices if you connect to projector via USB cable. 4.
  • Page 34 Running under WiFi AP Mode: Projector Ready: 1. Connect an optional Wireless USB WiFi Dongle unit to the projector‟s USB Port (USB -A). 2. Set the AP mode parameters at \..\settings\WiFi\AP mode\. *See „WiFi settings‟ (page 49) for more information.
  • Page 35 EZ Suite(EZ Display Function) 3. Select the EZ WiFi item at EZ Display interface on the screen. will show the Ready for display image on the screen. The 4-character pass code w i l l b e on the screen.
  • Page 36 Computer Ready: 1. For first time use, please install PC/Mac-tool (EZ WiFi/LAN.exe) program. After installed, new USB device “EZ USB” and new adapter “EZ Display” (Virtual .Graphics Card) will be installed. ► You can download the PC/Mac-tool (EZ WiFi/LAN.exe) through the intranet by web browser.
  • Page 37 EZ Suite (EZ Display F ction)
  • Page 38 Mirror mode (default): Clone or mirror desktop mode Mirror mode Extension mode: Span or extended desktop mode About: The information of EZ WiFi/LAN Exit: To quit the program and discontinue projecting images from the computer. Audio Streaming: On -Projecting images from the computer with audio sound. Off -Projecting images from the computer without audio sound.
  • Page 39 Running under WiFi Client Mode: Projector Ready: 1. Connect an optional Wireless USB WiFi Dongle unit to the projector‟s USB Port (USB -A). 2. Set the Client mode parameters at \..\settings\WiFi\Client mode\. *See „WiFi settings‟ (page 52) for more information. 3.
  • Page 40 Computer Ready: 1. We need to install PC/Mac-tool (EZ WiFi/LAN.exe) program. After installed, new USB device “EZ USB” and new adapter “EZ Display” (Virtual .Graphics Card) will be installed. ► You can download the PC/Mac-tool (EZ WiFi/LAN.exe) through the internet by web browser.
  • Page 41 EZ Suite (EZ Display Function) Mirror mode (default): Clone or mirror desktop mode Mirror mode Extension mode: Span or extended desktop mode About: The information for EZ WiFi/LAN...
  • Page 42 EZ Suite (EZ Display Function) Exit: To quit the program and discontinue projecting images from the computer. Audio Streaming: On -Projecting images from the computer with audio sound. Off -Projecting images from the computer without audio sound. ► Note: The frame rate of video would be decreased while the setting of Audio Streaming is ON.
  • Page 43 EZ Display main functions: 1. View MS-Office files (Word, Excel, PowerPoint), Adobe PDF,Apple iWorks (Pages, Numbers, Keynote). Also supports Sketch function and saves to photo roll. 2. Link your Dropbox storage and view the documents stored on it. 3. Display Web pages and support sketch function as well.
  • Page 44 EZ Suite (EZ Display Function) 4. View local photo gallery and do sketch...
  • Page 45: Ez Lan

    EZ Suite (EZ Display Function) 2.3 EZ LAN ► Note: EZ LAN Display supports MS Windows OS, Apple Mac OS Projector Ready: 1. Connects projector„s LAN port to Switch, Hub, or Local RJ45 outlet LAN port with the standard RJ45 Ethernet cable. 2.
  • Page 46 EZ Suite (EZ Display Function) Computer Ready: 1. We need to install PC/Mac-tool (EZ WiFi/LAN.exe) program. After installed, new USB device “EZ USB” and new adapter “EZ Display” (Virtual .Graphics Card) will be installed. ► You can download the PC/Mac-tool (EZ WiFi/LAN.exe) throw the internet by web browser.
  • Page 47: Setting & Configuration

    EZ Suite (Setting&Configuration) 3. Setting & Configuration Version Language Update Setting & Configuration Display Ratio Repeat Mode Display Ratio Slideshow Slideshow Duration Repeat Mode AP mode Client mode Connect PC Setting 3.1 System Setting ► Note: 1. Version: Show the EZ Suite firmware version 2.
  • Page 48: Video Setting

    EZ Suite(Setting&Configuration) 3.2 Video Setting ► Note: 1. Display ratio Original: The video aspect ratio changes in the order of original setting (according to the video image resolution). Full Screen: Change the aspect ratio to be displayed at full screen size. 2.
  • Page 49: Photo Setting

    EZ Suite (Setting&Configuration) 3.3 Photo Setting ► Note: 1. Display ratio Original: Projected the image of original size. Full Screen: Change the aspect ratio to be displayed at full screen size. 2. SlideShow OFF: Turns SlideShow function off. ON: Turns SlideShow function on. 3.
  • Page 50: Wifi Setting

    EZ Suite (Setting&Configuration) 3.5 WiFi Setting Please plug in the WIFI USB Dongle first; otherwise the projector would examine and project “No device” message on the screen. AP mode and Client mode are at the WiFi setting.
  • Page 51 EZ Suite (Setting&Configuration) AP mode (Ad Hoc): Select the button, then press the ENTER button on the remote control to go to set some parameters for being enabled under AP mode. ► These settings are only for basic wireless parameters. If you are going to modify these wireless parameters, the visual keyboard will pop-up on the screen.
  • Page 52 EZ Suite (Setting&Configuration) SSID (Service Set Identification): The same name of SSID must be assigned to wireless devices in your network. Considering your wireless network security, the default SSID is set to be “rtwap”. Security: you can configure the security settings of your wireless network. There are three wireless security modes supported by the Router: Open, WPA2 and WPA.
  • Page 53 EZ Suite (Setting&Configuration) Client mode: When wireless clients survey the local area for wireless networks to associate with, they will detect the SSID broadcast by the Router. The SSID of the AP your Router is going to connect to as a client. Select the button and press ENTER button on the remote control for starting Client mode.
  • Page 54 EZ Suite (Setting&Configuration) Press the to connect to as a client.
  • Page 55 EZ Suite(Setting&Configuration) Connect successfully. Select , then press the ENTER button on the remote control to detect the SSID broadcast with the router again.
  • Page 56 EZ Suite(Setting&Configuration) EZ Display: Main functions: - View MS-Office files (Word, Excel, PowerPoint), Adobe PDF, Apple iWorks (Pages, Numbers, Keynote). It also supports Sketch function and saves to photo roll. - View local photo gallery and do sketch - Display Web pages and support sketch function as well - Link your Dropbox storage and view the documents stored on it.
  • Page 57 EZ Suite(Setting&Configuration) Client mode: Set the client mode parameters at \..\settings\WiFi\Client mode\. See „WiFi settings‟ (Page 52) for more information to set parameters. Connects through a wireless LAN router.. ► Note: Compatible Devices: Application Compatible Devices Compatible OS version EZ display - iPhone 4 and iPhone 4S iOS 5.1.1 or later - iPad 2, and New iPad (gen 3 iPad)
  • Page 58: Connect Pc Setting

    Configuration) 3.6 Connect PC Setting Connect PC for accessing internal memory. 1. Connect the computer's USB port to the projector's USB (mini-USB) port via the USB cable. 2. Computer‟s system will examines newly discovered removable media and devices. 3. Projector will display the connecting message on the screen. 4.
  • Page 59: Menu Operation

    Menu Operation How To Operate On-Screen Display 1. Press "Menu" button. It will be shown blue main menu. The first main menu is " PICTURE" menu. 2. Choose which item you want to enter, you could press up / down /left/ right button of control panel or remote control to adjust item or value.
  • Page 60: Menu (Pc Mode)

    MENU (PC Mode) Picture Menu Step: 1. Use the ▲ /▼ buttons to select an item. 2. Use the ◄ / ► cursor buttons to select an item or adjust the value. Item Selection Description BRIGHTNESS 000/100 Adjusts the image brightness level. CONTRAST 000/100 Adjusts the image contrast level.
  • Page 61: Audio Menu (Pc Mode)

    MENU (PC Mode) Audio Menu Step: 1. Use the ▲ /▼ buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description VOLUME 00/40 Adjusts the volume. MUTE OFF/ON Mutes the volume OFF / ON.
  • Page 62: Setting Menu

    MENU (PC Mode) Setting Menu Step: 1. Use the ▲ /▼buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description Moves the image position horizontally. H POSITION 000/100 This function is only selected for computer signal.
  • Page 63: Picture Menu (Video Mode)

    MENU (Video Mode) Picture Menu Step: 1. Use the ▲ /▼ buttons to select an item. 2. Use the ◄ / ► cursor buttons to select an item or adjust the value. Item Selection Description BRIGHTNESS 000/100 Adjusts the image brightness level. CONTRAST 000/100 Adjusts the image contrast level.
  • Page 64: Audio Menu (Video Mode)

    MENU (Video Mode) Audio Menu Step: 1. Use the ▲ /▼ buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description VOLUME 00/40 Adjusts the volume. MUTE OFF/ON Mutes the volume OFF / ON.
  • Page 65: Setting Menu (Video Mode)

    MENU (Video Mode) Setting Menu Step: 1. Use the ▲ /▼buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description AUTO KEYSTONE OFF/ON Automatically corrects keystone distortion in image. V KEYSTONE -70/+70 Corrects vertical keystone distortion in image manually.
  • Page 66: Advanced Menu

    MENU Advanced Menu Step: 1. Use the ▲ /▼buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description ZOOM / PAN EXECUTE Execute digital zoom and pan function. FREEZE OFF/ON Freeze the current image on the screen.
  • Page 67 MENU Select the input source item, it will show the sub-items on the screen. Use the ▲ / ▼ buttons to change input source item. And use ►button to select input source SELECT SOURCE EXECUTE RGB2 I/O could be turned into one of analog RGB IN 2 input source or output the projected from MONITOR OUT to an external monitor by RGB 1 source.
  • Page 68 MENU Advanced Menu LOGO SETTING This function allows you to customize the start-up logo. IMPORTANT: To implement Logo setting function, please enter PIN code first. Without inputting the PIN code, you cannot modify Logo setting function. Item Selection Description Select Mode( ► cursor button) DEFAULT The factory logo.
  • Page 69 MENU Advanced Menu Logo Capture How to use this function?     Select Logo Capture item in the logo  setting menu, and press ► button.    You can see the red frame to select  captured area.
  • Page 70: Presentation Menu

    MENU Presentation Menu Step: 1. Use the ▲ /▼buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description Automatically invert the image when the projector is turned AUTO CEILING OFF / ON upside down, i.e.
  • Page 71: Reset Lamp Timer

    MENU Presentation Menu Reset Lamp Timer The lamp timer is the time counted after the last resetting. The usage time of the lamp is shown in the PRESENTATION Menu. Pressing the RESET button or the ► button displays a dialog. To reset the lamp time, select the RESET using the ►...
  • Page 72: Security Menu

    MENU Security Menu Step: 1. Use the ▲ /▼buttons to select an item. 2. Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description OFF: Turn off PIN lock protection. ON 1: After plugging in AC power, you need to key in PIN code at the first time of use.
  • Page 73 MENU Security Menu Step: 1.Use the ▲ /▼buttons to select an item. 2.Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description FILTER TIMER Show the filter use hour. RESET FILTER EXECUTE Reset the filter timer after cleaning / changing filter. TIMER 500 hours Select (500 / 800 / 1000 hours) depending on the...
  • Page 74 MENU Security Menu Step: 1.Use the ▲ /▼buttons to select an item. 2.Use the ◄ / ► buttons to select an item or adjust the value. Item Selection Description PROJECTOR Default is Projector network setting display which shows bits that can NAME Projector be recognized by ASCII.
  • Page 75: Auto Filter Alert

    MENU Auto Filter Alert Auto Filter Alert is in the SECURITY category and shows the air filter use time and alerts user to change the filter. Pressing ► cursor button will display a dialog. When the operating time reaches the set time, a warning message will appear on the screen to remind user of filter cleaning / replacing.
  • Page 76: Pin Key In Operation

    MENU PIN Key In Operation When the projector is turned on and the PIN LOCK PROTECTION is set to [ON], the image will show as on the right side. 1. Press the MENU button on the projector or remote control. Enter PIN code by keypad or remote control.
  • Page 77: Network Control Software Application

    Network Control Software Application Procedure to utilize this function It can help user to monitor and manage the projector(s) status in the local area network.  Register the projector(s) which needs to be controlled. "Auto search" can help you to seek the projector(s) source easily. After registering in the work group, you can start to control the projector.
  • Page 78: Browser Control

    Network Control Software Application Browser Control Auto IP address setting (while DHCP setting is "ON"): (1) Enable DHCP from the projector on-screen-display menu, under "SECURITY \ LAN SETTING". (2) Wait for the PC server to release IP address to the projector. (3) Enter "Given IP address (For example http://192.168.1.176/)"...
  • Page 79: Home(Status)

    Network Control Software Application ADMINISTRATOR MODE User name: admin Password: (Default password setting is disabled.) Home (Status): Show current projector status and network configuration settings.
  • Page 80: Control Panel

    Network Control Software Application ITEM ITEM SETTING DESCRIPTION Status Projector Name Show projector name. System Status Show if projector is Power On or Inactive . Input Source Show current input source. Lamp Hours Show lamp used hours on current projector. Filter Hours Show filter used hours on current projector.
  • Page 81 Network Control Software Application ITEM SETTING DESCRIPTION Basic Projector Name Show projector name on the current projector. Power Power On or Power Off the projector via network. Input Source Select input source. Picture Brightness Adjust the image brightness level. Contrast Adjust the image contrast level.
  • Page 82: Network

    Network Control Software Application Network : Set up network configuration and password from this page. ITEM SETTING DESCRIPTION Network DHCP Assign an IP address to the projector from the DHCP server automatically. IP Address Set up IP Address when DHCP is disabled. Subnet Mask Set up Subnet Mask when DHCP is disabled.
  • Page 83: Alert

    Network Control Software Application Alert: Show and setup Alert configurations. When problem occurs to the projector, it will automatically send e-mail to remind user. How to operate: 1. Enter Email Setting columns. 2. Enter SMTP Setting columns. 3. Select Alert Condition. Multiple choices are fine. 4.
  • Page 84: Schedule

    Network Control Software Application Schedule : Show and set up Schedule, including Weekly Schedule and Specific Day. Weekly Schedule To power on and power off projector based on Weekly Schedule. How to set up: 1. Choose week days. 2. Set up power-on or power-off time. (Be sure that the interval between power-on and off setting is more than 5 minutes.) 3.
  • Page 85: Time

    Control Software Application Time : 1. Current System Time Setting: Refresh the date/time on the webpage if you click “Refresh” button. 2. System Time Setting : To set the date/time manually Enter the Date in Month/Day/Year format. Enter the Time in Hour/Minute/Second format. 3.
  • Page 86: About The Tools Button

    Control Software Application ITEM SETTING DESCRIPTION Power Power On or Power Off the projector via network. Vol + (Volume +) Adjust the volume up. Vol + (Volume -) Adjust the volume down. Mute Mute the volume OFF / ON. Source List Select input source.
  • Page 87 Control Software Application 1. Click button to leave this page. 2. Creston Control Projector Name: Displays the projector name used to identify the projector when connected to a network. When editing, you can enter up to 14 single-byte alphanumeric characters. Location: Show the location where the projector is.
  • Page 88: About The "Info" Button

    Control Software Application About the “Info” button: Show current projector status from this page. Press exit button to leave this page. Click button to leave this page. About the “Contact IT Help”: Click to close Contact IT Help window dialog. Click to send the message to Creston‟s device and projector.
  • Page 89: Maintenance Of Projector

    Maintenance of Projector Air Filter When a warning message appears to remind you to clean the air filter, replace a new one as soon as possible. Check and clean the air filter periodically. Replacing the Air Filter When the use time reaches the filter counter time, the projector will display a message that indicates to replace a new filter.
  • Page 90: Lamp / Replacing New Lamp

    Maintenance of Projector Lamp 1. If you want to replace new lamp, but the projector was just turned off, please let the projector cool down and unplug power cord at least 60 minutes. 2. If the projector is mounted in the ceiling, contact your dealer to replace the lamp. Replacing New Lamp 1.
  • Page 91 Maintenance of Projector WARNING The projector uses a high-pressure mercury lamp. The explosion of lamp with a loud bang or burn out could possibly cause injury or a fire. When the bulb bursts, it is possible for shards of glass to fly into the lamp housing and for gas containing mercury to escape from the projector‟s vent holes.
  • Page 92: Other Care

    Maintenance of Projector Other Care Cleaning The Lens If the lens is dirty and dusty, display quality may be decreased. Before cleaning the lens, make sure that the projector has cooled down adequately. After the projector has cooled down adequately, lightly wipe the lens with the available lens-cleaning cloth.
  • Page 93: Troubleshooting

    Troubleshooting Indicator The power and lamp indicators show the status of the projector. Before requesting repair, check the projector status using the chart below. If the problem cannot be resolved, contact your dealer. In normal status~~~ POWER LAMP CONDITIONS DESCRIPTION Blinking In Projector is ready to be turned Stand by mode...
  • Page 94: Error For Machine Defects

    Troubleshooting Error For Machine Defects The following problems may be confused with a machine defect. Check and follow the table. If it couldn‟t be improved, contact your dealer. Symptom Cause / Remedy The power cord is disconnected. Plug the power cord into an AC outlet. Intending to turn on the projector again during the cool down mode.
  • Page 95 Troubleshooting Error For Machine Defects Symptom Cause / Remedy The projector is not connected correctly. Check if audio cable is connected correctly. The volume is set to minimum. No audio Adjust the volume. Mute is turned on. Press the MUTE button. No battery.
  • Page 96: List Of Supported Monitor Displays

    Troubleshooting List of Supported Monitor Displays Computer mode Signal Refresh Rate (Hz) Resolution (pixels) 640x480 VESA 60/72/75/85 640x480 SVGA 56/60/72/75/85 800x600 60/70/75/85 1024x768 SXGA 70/75 1152x864 SXGA 60/75 1280x960 SXGA 1280x1024 WXGA 60/75 1280x800 WXGA+ 60/75/85 1440x900 SXGA + 60/75 1400x1050 UXGA 1600x1200...
  • Page 97: Appendix

    Appendix Menu Tree (PC Mode) Brightness Contrast PICTURE Sharpness Natural Display Mode Cinema Daylight Green Board White Board Black Board Volume AUDIO User Mute Front Auto Ceiling H Position Ceiling Rear V Position Ceiling And Rear PRESENTATION Lamp Mode Phase Lamp Frequency SETTING...
  • Page 98: Menu Tree(Video Mode)

    Appendix Menu Tree (Video Mode) Brightness Front PICTURE Contrast Ceiling Auto Ceiling Rear Sharpness Ceiling And Rear Lamp Mode PRESENTATION Color Lamp Tint Natural Reset Lamp Timer Cinema Display Mode Daylight Power Managment Green Board White Board Black Board PIN Lock Protection On 1 User On 2...
  • Page 99: Appearance

    Appendix Appearance...
