R/G/B Contrast:
Fw {Contrast} {Green-Contrast}{Red-Contrast}{Blue-Contrast}
>fw 0 8000 9000 7000
RED Formatter Contrast Register : 7000 8000 9000
GREEN Formatter Contrast Register : 7000 8000 9000
BLUE Formatter Contrast Register : 7000 8000 9000
OCMD
This command is used for sending commands to the Osram Lamp ballast. The first parameter determines which of the two
ballast ports is addressed. The second is the ballast register address (hexadecimal – e.g., STATUS = 22
Osram documentation for register details. If the command requires data to sent those bytes are appended to the
command (hexadecimal and space delimited). If the command causes the ballast to return data – no just echo the
command – the response will be output in hexadecimal bytes. The ballast status command is special in that the status bits
are decoded (see below). Examples:
Syntax: ocmd { 1 | 2 } {ballast command} [data
> ocmd 2 22
Command response = E0
LAMP BALLAST 2 STATUS BYTE:
RUN UP IN PROGRESS
MAX IGN TIME EXCEEDED
LAMP BURNING
> ocmd 2 3e
Command has no response.
> ocmd 2 60 96
Command response = 9D
> ocmd 2 60 98
Command response = D9
RST
Perform hardware RESET of the 3 formatters and re-initialize them:
Syntax: rst
> rst
Reset Formatter Board Now !!
MCGD OK to Read
ECC Index 2
ECC Enable
Freeze Frame On
Freeze Frame Off
Reload Gamma Index = 1
BOXLIGHT PRO80S3 Projector Preliminary User's Manual
Ballast Communications
] [data ] ... [data
1 2
Reset and Re-initialize the Formatters
]
n
OCMD
). See the
16
RST
