BOXLIGHT PRO80S3 Projector Preliminary User's Manual
NOTE: When the projector is in mode, the External Interlock has absolute control over the projector power.
power control
It locks out the other power on/off methods – serial port commands ( and ), the rear panel rocker switch and the IR
on off
remote. To control the power or enable the IR remote during setup or testing, a terminal must be connected to the serial
interface and serial commands ( ) must be issued. The projector can be returned to mode
fpol, ir+, etc. power control
with .
fpol 2
Syntax: fpol [0 | 1 | 2]
> fpol
FP Polarity = 1
>
Film Projector ON
IR= 08
> fpol
FP Polarity = 0
>
Film Projector OFF
> fpol 0
FP Polarity = 0
> fpol 1
FP Polarity = 1
>
Film Projector ON
> fpol 2
FP Polarity = 2
GAMMA GAMMA Table Select GAMMA
Select GAMMA Table. It will store to EEPROM, and when system boots up will reload the gamma setting.
Syntax: GAMMA {Table Num} 0 < num < n
>gamma 2
Set Gamma index = 2
Page 19 of 33
