3.2
User Commands
Several ASCII Control Characters are recognized to control Brightness, Contrast, Display Mode, Patterns and Orientation.
hot keys
These are
– i.e., no need to press ENTER.
<CTRL-Z>
Brightness – Decrement Lower Level
R/G/B Brightness=1D/1D/1D
<CTRL-X>
Brightness – Increment Lower Level
R/G/B Brightness=1C/1/C/1C
<CTRL-W>
Contrast – Decrement Upper Level
R/G/B Contrast=03/03/03
<CTRL-E>
Contrast – Increment Upper Level
R/G/B Contrast=02/02/02
<CTRL-N>
Cycles through the Projection modes
CURTAIN
<CTRL-O>
Cycles through the Projection orientations (FRONT, REAR, CEILING, etc.)
REAR-CEILING
<CTRL-P>
Cycles through the Patterns (when in PATTERN MODE)
PATTERN = 6
CLOSE, OPEN
OPEN opens the projector's shutter and puts the formatters in NORMAL projection mode if:
a)
The power is ON AND
b)
The Film projector interlock is inactive
OPEN cancels a 5 MINUTE POWER DOWN sequence if it has been initiated.
CLOSE closes the projector's shutter and puts the formatters in CURTAIN projection mode if the main power is ON, i.e.,
the fans are running.
Syntax: open
close
BOXLIGHT PRO80S3 Projector Preliminary User's Manual
Control Characters
SHUTTER Control
CLOSE, OPEN
Page 17 of 33
