%01$
LAMP Door Closed and Lamp TEMP OK
%02$
FANS OK
%03$
Film Projector ON – During Power-up
%04$
Film Projector OFF – During Power-up
%05$
Video Signal Detected – During Power-up
%06$
Striking Lamp – During Power-up
%07$
Restrike – Ballast RESET
%08$
Restrike – Lamp Restrike
%09$
Restrike – Restrike Fail
%0A$
Ballast COMM Failure – typically non-critical unless it least to !88$
!80$
Lamp Door Open or Lamp Overtemp – if after Power-up ► Shutdown
!81$
FAN Problem – if after Power-up ► Shutdown
!82$
NO Video – during or after Power-up
!83$
Video Signal Detected - Video Restored
!84$
Lamp Lit - During Power-up
!85$
Formatter COMM Disabled - Check SW500 – Power-up sequence halted
!86$
Restrike - Lamp Lit - After Power-up - 30 second Warm up before Shutter OPEN
!87$
Restrike Count Exceeded ► Shutdown
!88$
Ballast not Responding - After Power-up ► try Restrike
!89$
Ballast OVERTEMP ► Shutdown
!8A$
Lamp Extinguished - After Power-up ► try Restrike
!8B$
Resetting Formatters – usually non-critical
!8C$
LAMP SYNC Signal Inactive – usually non-critical
!8D$
LAMP SYNC Detected – usually non-critical
!8E$
Film Projector ON - After Power-up – Shutter CLOSED
!8F$
Film Projector OFF - After Power-up
!90$
RED FORMATTER Status Read Error – usually non-critical
!91$
GREEN FORMATTER Status Read Error – usually non-critical
!92$
BLUE FORMATTER Status Read Error – usually non-critical
!A0$
Power-up Sequence Complete – Ready for shutter OPEN
!E0$
Invalid Parameter in Command line
!E1$
Missing Parameter(s) in Command line
!E2$
Unknown Command
!F0$
Lamp Time Read from EEPROM – Lamp Hour EEPROM Read Error
!F1$
Strike Count Read from EEPROM – Lamp Hour EEPROM Read Error
!F2$
Power Off – MAIN Power OFF – System in Standby Mode
!F3$
5 Minute Power Down Can celled by OPEN or ON Command
!F4$
5 Minute Power Down Initiated – Lamp OFF and 60 second cool down in 5 minutes
!F5$
Powering Up – Main Power ON - Initiating Power-up Sequence
!F6$
Powering Down – Lamp OFF – 60 second cool down
Syntax: v+
v-
VER
Display Controller Firmware Revision:
ver
* 720p MHF-69 Monitor – Rev. D03J
*
17 Nov 2006
BOXLIGHT PRO80S3 Projector Preliminary User's Manual
Non-Verbose Message Codes
Non-critical (Informational) Messages [M+ and V-]
Critical Messages / Shutdown Messages [V-]
*Syntax:
ver
VERSION
VER
Page 24 of 33
