BOXLIGHT PRO80S3 User Manual page 26

Syntax: mdnld
> mdnld
Enter Gx,Gy,Rx,Ry,Bx,By,Wx,Wy,Bx,By,WB,BB(x100) 12 datas:
.323,.649,.664,.334,.146,.041,.291,.307,.310,.000,3000,123
GREEN = .323,.649
RED = .664,.334
BLUE = .146,.041
WHITE = .291,.307
BLACK = .310,.037
CONTRAST= 2439
RDMCGD
Display the Measured Color Gamut Data that is currently in use. If the calibrated data in the EEPROM on the BLUE
Formatter has not been loaded or has been corrupted, a default table is loaded.
Syntax: rdmcgd
> rdmcgd
GREEN = .340,.650
RED = .640,.350
BLUE = .140,.033
WHITE = .290,.330
RDTCGD
Display the Target Color Gamut Data for the specified index. This command takes a parameter – the target index –
between 1 and 9.
Syntax: rdtcgd {1 ≤ target index ≤ 9}
For indices 1 through 4 (in this example index 4) the following will be output to the terminal:
> rdtcgd 4
GREEN = .210,.710
RED = .670,.330
BLUE = .140,.080
WHITE = .423,.399
TOLBOX = .010
For indices 5 through 8 (in this example index 8) the full contents of the used-definable table will be displayed. The third
value for each color is the GAIN. See TI document –
Modular Formatter Component Set
Copyright notice.
BOXLIGHT PRO80S3 Projector Preliminary User's Manual
Display Measured Color Gamut
Data in Use
Display Target Color Gamut Data
Product Specification for DDP1000, DDP1010, DDP1011 Based
[Dwg #2503986, Rev. J or later] for details on the tolerance box specification and the
RDMCGD
RDTCGD
Page 26 of 33
