iSolution IM-5W User Manual page 10

Show Mode
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
or (show 2) or (show 3) or
been selected, press the ENTER button to setup or automatically return to the main
functions without any change after 8 seconds. To go back to the functions without any
change press the MENU button again.
Show 1 mode - Fixture is placed on the floor. Tilt movement angle 210°.
Show 2 mode - Fixture is fixed under ceiling. Tilt movement angle 90°.
Show 3 mode - Fixture is placed on the speaker, The spot is always projecting
to the audience's direction; i.e in front of the stage. Pan movement angel ( left to
right to left ): 160°. Tilt movement angel: 90° ( 60° above horizon; 30° below
horizon.)
Show 4 mode - Fixture is fixed under ceiling. The spot is mainly projecting in
front of the stage. Pan movement angel ( left to right to left ) :160°. Tilt
movement angel: 90° ( vertically, front 75°; back 15° )
Slave Mode
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(normal) or (2 light show) mode. Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Blackout Mode
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(yes blackout) or (no blackout) mode. Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Color Mode
is showing on the display. Pressing ENTER
(show 1)
(show 4) mode. Once the mode has
is showing on the display. Pressing
is showing on the display. Pressing
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(normal) or (split color) mode. Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Pan Inversion
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
or (pan inversion) mode. Once the mode has been selected, press the ENTER
button to setup or automatically return to the main functions without any change after 8
seconds. To go back to the functions without any change press the MENU button again.
Tilt Inversion
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(normal) or (tilt inversion) mode. Once the mode has been selected, press the
10E
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Dimmer Inversion
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
or (dimmer inversion) mode. Once the mode has been selected, press the ENTER
button to setup or automatically return to the main functions without any change after 8
seconds. To go back to the functions without any change press the MENU button again.
Led Display
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(Led on) or (Led off) mode. Once the mode has been selected, press the ENTER
button to setup or automatically return to the main functions without any change after 8
seconds. To go back to the functions without any change press the MENU button again.
is showing on the display. Pressing
is showing on the display. Pressing ENTER
(normal)
is showing on the display. Pressing
is shown on the display. Pressing ENTER
(normal)
is showing on the display. Pressing
