- Page 1 The Da-Lite Difference. Instruction Book for DA-LITE SCREEN COMPANY, INC. 3100 North Detroit Street senIor electrol® Post Office Box 137 Warsaw, Indiana 46581-0137 Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 www.da-lite.com e-mail: info@da-lite.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your video equipment, basic safety precautions should always be followed, including the following: 1. R ead and understand all instructions before using. 2. P osition the cord so that it will not be tripped over, pulled, or contact hot surfaces. 3. If an extension cord is necessary, a cord with a current rating at least equal to that of the appliance should be used. Cords rated for less amperage than the appliance may overheat. 4. To reduce the risk of electric shock, do not disassemble this appliance. Contact an authorized ser- vice dealer when repair work is required. Incorrect reassembly can cause electric shock when the appliance is used subsequently. 5. The use of an accessory attachment not recommended by the manufacturer may cause a risk of fire, electric shock, or injury to persons. SAVE THESE INSTRUCTIONS PRE-INSTALLATION 1. C arefully unpack screen and remove outer wrapping from case. 2. R emove instruction cover plate (Fig. 1). Do not remove metal shipping brace (secures roller), wrapping paper, or tape strips until screen is installed. 3. Make sure to recheck measurement of screen location before installation. NOTE: Screen is not centered in box. Screen surface is set 18 ⁄... - Page 3 N OTE: The picture surface, when rolled down, should have a full wrap around the roller. Do not allow any part of the roller to become exposed. SCREEN ADJUSTMENT Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly ad- justed at Da-Lite. Should it be necessary to adjust for more or less drop of picture (viewing area), proceed in the following manner: MORE SCREEN DROP 1. Place operating switch in “down” position. 2. When the screen stops, turn the “down” limit knob one-quarter turn clockwise.
- Page 4 2. Place operating switch in “off” position. 3. Turn the “up” limit knob one-quarter turn clockwise. 4. P ress operating switch to raise picture surface. Repeat operation if picture surface continues to roll too far into case. DOWN PICTURE SURFACE DOES NOT ROLL COMPLETELY INTO CASE 1. Place operating switch in “up” position. 2. Turn the “up” limit knob one-quarter turn counterclockwise. 3. T est by lowering picture surface approximately two feet with operating switch, then raise picture. Repeat operation if desired position is not reached. SENIOR ELECTROL INSTRUCTIONS ® END VIEW SIDE VIEW ⁄ ⁄ ⁄ ⁄ ±...
- Page 5 SENIOR ELECTROL INSTRUCTIONS ® FOR SCREENS 20' AND LARGER IN FOR SCREENS UP TO 18' X 18' HEIGHT OR WIDTH MOTOR COMPARTMENT MOTOR COMPARTMENT 9-1/2" 10-3/4" REINFORCED REINFORCED 11-5/16" 12-9/16" HINGED ACCESS PANEL HINGED ACCESS PANEL FOR MOTOR COMPARTMENT FOR MOTOR COMPARTMENT 18-5/8" 18-5/8" 4-3/8" 4-3/8" FABRIC HEIGHT x WIDTH AS ORDERED, FABRIC HEIGHT x WIDTH AS ORDERED,...
- Page 6 Visit www.da -lite.com/products/tutorials.php to find installation and troubleshooting tutorials. You will also find a link to Live Chat for interactive support and you can contact us by email at info@da-lite.com or by phone at (800) 622-3737 or (574) 267-8101 with any troubleshooting questions.
- Page 7 TROUBLESHOOTING SYMPTOM CAUSE SOLUTION 3. S creen will not move “up.” (a) B lown fuse or tripped circuit (a) R eplace fuse or reset circuit breaker. breaker. Motor does not hum. (b) N o power between red and white (b) C orrect improper wiring. leads in junction box. (c) T hermal overload tripped. (c) L et motor cool for 15 minutes. Try again. (d) Burned out motor winding. (d) C heck for power between red Motor hums.
- Page 8 INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137 , Warsaw, IN 46581-0137 , (574) 267-8101, (800) 622-3737 . IMPORTANT: THIS WARRANTY SHALL NOT BE VALID AND DA-LITE SHALL NOT BE BOUND BY THIS WARRANTY IF THE PRODUCT IS NOT OPERATED IN ACCORDANCE WITH DA-LITE’S WRITTEN INSTRUCTIONS.
