CONNECTION AND MAINTENANCE

I Antenna

A key element in the performance of any communication sys-
tem is an antenna. Contact your dealer about antennas and
the best places to mount them.

I Fuse replacement

A fuse is installed in each fuse holder of the supplied DC
power cable. If a fuse blows or the transceiver stops func-
tioning, track down the source of the problem if possible, and
replace the damaged fuse with a new rated one.
❑ Fuse rating: 10 A
USE the 10 A fuse only.

I Cleaning

If the transceiver becomes dusty or dirty, wipe it clean with a
soft and dry cloth.
AVOID the use of solvents such as benzene or
alcohol, as they may damage the transceiver sur-
faces.
15

I Options

• RMK-3 + OPC-609
SEPARATION KIT
Allows you to install the transceiver main unit separately
from the front panel for operating convenience.
• SP-5/SP-10/SP-22
EXTERNAL SPEAKERS
Input impedance : 4
Max. input power : 5 W
SP-5 : Large speaker for good audio quality.
SP-10 : For all-round mobile operation.
SP-22 : Compact and easy-to-install.
• HM-152/HM-152T/HM-148
HM-152 : Hand microphone
HM-152T : DTMF microphone
HM-148 : Heavy duty microphone
• SM-25
DESKTOP MICROPHONE
• UT-109R/UT-110R
SCRAMBLER UNITS
Non-rolling type (UT-109R)/Rolling type (UT-110R) voice
scrambler unit provides higher communication security.
• UT-96R
5
TONE UNIT
Some options may not available in some countries. Ask your dealer
for details.
SEPARATION CABLE
HAND MICROPHONES
