I Supplied Accessories

Microphone Microphone hanger
and screw set
DC power cable Function name
stickers*
Mounting bracket
Flat washers
and felts
Spring washers
Nuts
Felts are already
attached.
* 1
Used for labelling the programmable
function keys according to their assin-
ged functions.
2
*
Used for the optional unit installation.
Ask your dealer for details.
Microphone
hanger cable
2
Sponges*
1
Bracket bolts
Mounting screws
(M5 12)
Self-tapping screws
(M5 16)
CONNECTION AND MAINTENANCE

I Mounting the transceiver

The universal mounting bracket supplied with your transceiv-
er allows overhead mounting.
• Mount the transceiver securely with the 4 supplied screws
to a thick surface which can support more than 1.5 kg.
Flat washer
Felt*
Spring washer
Felt*
When using
self-tapping screws *Felts reduce the vibration effects.
3
