I Optional HM-168 description

Alligator type clip

To attach the speaker-mic.

to your shirt or collar, etc.

PTT switch

Transmits while pushed

Receives while released

Microphone

Speaker

Turn the transceiver power OFF

when connecting the HM-168.

NEVER immerse the connector in water. If the connector becomes

wet, be sure to dry it BEFORE attaching it to the transceiver.

NOTE: The microphone is located at the top of the speaker-mi-

crophone, as shown in the diagram above. To maximize the

readability of your transmitted signal (voice), hold the micro-

phone approx. 5 to 10 cm from your mouth, and speak in a nor-

mal voice level.

SPEAKER-MICROPHONE
