- Page 1 The Da-Lite Difference. Instruction Book for 3100 North Detroit Street Post Office Box 137 DESIGNER ELECTROL® Warsaw, Indiana 46581-0137 Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 Toll Free Fax: 877-325-4832 www.da-lite.com e-mail: info@da-lite.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your video equipment, basic safety precautions should always be followed, including the following: 1. Read and understand all instructions before using. 2. Position the cord so that it will not be tripped over, pulled, or contact hot surfaces. - Page 3 PRE-INSTALLATION Before proceeding with the installation of the screen, please read the installation and operations instructions thoroughly! CAUTION! Do not cut wrapping paper or tape with knife or any sharp tool. Pull orange string. 1. Carefully unpack the screen and remove the outer wrapping. 2.
- Page 4 DESIGNER ELECTROL INSTALLATION ® Hang screen from wall or ceiling. FOR WALL MOUNTING HARDWARE PROVIDED 2 – “V” Bars ( one is factory mounted to the back of the case; one will be mounted to the wall) 6 – Toggle Bolts, 4"...
- Page 5 Contact the factory for further information. 240 VOLT WIRING DIAGRAM FOR STANDARD WALL SWITCH: Da-Lite offers two styles of 240 volt wall switches for standard operation. Please see wiring diagram included in wall switch box included with screen.
- Page 6 TROUBLESHOOTING SYMPTOM CAUSE SOLUTION 1. Screen will not operate. (a) Incorrect line voltage. (a) Verify 115-125V (or 220-240V). If Motor does not hum. insufficient voltage, rewire incom- ing electric line. (b) Blown fuse. (b) Replace fuse. (c) Tripped circuit breaker. (c) Reset circuit breaker.
- Page 8 EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137 , Warsaw, IN 46581-0137 , (574) 267-8101, (800) 622-3737 .
