- Page 1 INSTRUCTION BOOK FOR Executive Electrol ® ®...
-
Page 2: Important Safety Instructions
Important Safety Instructions When using your video equipment, basic safety precautions should always be followed, including the following: 1. Read and understand all instructions before using. 4. To reduce the risk of electric shock, do not disassemble this appliance. Contact an authorized service dealer when repair 2. - Page 3 The picture surface drop, and the opening and closing of the fabric door, are controlled automatically by limit switches which have been preset at Da-Lite. When the picture surface is moving upward, it is controlled by a limit switch that shuts off when the door closes. To adjust for more or less picture drop (viewing area), proceed in the following manner: Screen Unrolled in "Down"...
- Page 4 Restoring Roller Wrap CAUTION! Do not attempt to restore a lost wrap 5. Gently lift fabric up and ease it over the top of the roller. by adjusting limit switches! CAUTION! Be careful not to crease or damage fabric. 1. Run fabric all the way down. 6.
- Page 5 This Switch Cannot Be Used With L. V .C. 240 Volt Wiring Diagram For Standard Wall Switch: Da-Lite offers two styles of 240 volt wall switches for standard operation. Please see wiring diagram included in wall switch box included with screen.
-
Page 6: Troubleshooting
Troubleshooting Symptom Cause Solution Blown fuse. Replace fuse. Tripped circuit breaker. Reset circuit breaker. Tighten all loose wire connections. Correct any improper connections. Check for power. “Down” Position Improper wiring to operating switch. Check for power across black and white leads. “Up”... - Page 7 Troubleshooting Symptom Cause Solution No power between red and white leads in Check fuse. Reset circuit breaker. Correct junction box. improper wiring. Check LVC. See above. Screen will not move “up.” Motor does not hum. Thermal overload tripped (acts as a breaker). Let motor cool for 15 minutes.
- Page 8 Troubleshooting Symptom Cause Solution After securing fabric to roller, loosen set screws on Screen jammed. Will not operate, motor gear and manually rotate solenoid assembly back Closing mechanism detached from door, motor hums, door open, closing over top of roller into position, then reattach door. Match allowing it to jam into box.
- Page 12 OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
