INSTRUCTION BOOK FOR
Designer Contour
Electrol
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Designer Contour Electrol and is the answer not in the manual?

Questions and answers

Related Manuals for Da-Lite Designer Contour Electrol

Summary of Contents for Da-Lite Designer Contour Electrol

  • Page 1 INSTRUCTION BOOK FOR Designer Contour Electrol ® ®...

  • Page 2: Important Safety Instructions

    Important Safety Instructions When using your video equipment, basic safety precautions should always be followed, including the following: Read and understand all instructions before using. Position the cord so that it will not be tripped over, pulled, or contact hot surfaces. If an extension cord is necessary, a cord with a current rating at least equal to that of the appliance should be used.

  • Page 3: Installation

    Carefully unpack screen and remove outer wrapping from case. Remove the black tape from the slat bar after the case has been installed. There are three ways to install the Designer Contour Electrol: Wall Mount, Ceiling Mount, or Ceiling Hook. Procedures for each method are as follows: 4 1/4"...

  • Page 4: Electrical Installation

    Electrical Installation Internal wiring has been completed at the factory. Installer must route power to the wall switch and to the junction box located on the left end of the screen case. Standard installation is for a single 120VAC or 240VAC wall switch to control the screen. Optional Control units may have been ordered. Wiring diagrams for the built-in VPI and low voltage control are included in these instructions.
  • Page 5 Electrical Installation 120V Wiring Diagram With Optional Built-In Low Voltage Control Black Motor White (Common) Black Ground To Case White Stop Down White (Common) 120VAC 60HZ Low-Voltage Black (Hot) Wall Switch Green Optional RF Ground-Must or IR Remote Be Connected Connector To Building Ground...

  • Page 6: Screen Adjustment

    Screen Adjustment Screen travel is stopped automatically in the down and up positions by the limit switches that are preset at the factory. If it’s necessary to adjust for more or less drop follow the steps below. The case cover must be removed to access the motor limit switches.

  • Page 7: Troubleshooting

    Troubleshooting Symptom Cause Solution Verify 115-125V (or 220-240V). If insufficient voltage, rewire Incorrect line voltage. incoming electric line. Blown fuse. Replace fuse. Tripped circuit breaker. Reset circuit breaker. Check above. Tighten all loose wire connections. Correct any improper connections. No power to operating switch Down Position Screen will not operate.
  • Page 8 OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
