• Transmission is impossible if Battery Level 0 is
detected when you press PTT .
• As long as you press PTT , an error tone sounds, TX
and CH blink.
CAUTION
• Although the battery level is 0, it is possible to
receive.
Battery
Level
LEVEL 4
100% Full
LEVEL 0
Low Battery
(flashing)*
*Note: Battery Low Alert sounds every 5 seconds and this condition results in
power shutdown after 60 seconds.
**Note: Power off before charging.
Attach and Remove Beltclip
To attach:
1. Position beltclip below its receptacle
on the upper back side of the radio.
2. Slide the beltclip up into its receptacle
until you hear it click. The belt-clip is
firmly attached.
To remove:
1. Turn the radio upside down.
2. Slide the beltclip up and out of its
receptacle.
8
Icon
Battery Level
LEVEL 3
Battery
Approx.40%
capacity
LEVEL 0
Empty Battery
(Shutdown)**
Icon
