Uniden Atlantis 155 Owner's Manual

Marine vhf radio
Hide thumbs Also See for Atlantis 155:
Table of Contents

Advertisement

Quick Links

Atlantis
155
Marine VHF Radio
Radio VHF maritime
OWNER'S MANUAL
GUIDE D'UTILISATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atlantis 155 and is the answer not in the manual?

Questions and answers

Related Manuals for Uniden Atlantis 155

Summary of Contents for Uniden Atlantis 155

  • Page 1 Atlantis Marine VHF Radio Radio VHF maritime OWNER’S MANUAL GUIDE D’UTILISATION...
  • Page 2 13. End the message by saying “THIS IS {name or call sign of your boat}, OVER.” 14. Release the Push to Talk button and listen. If you do not get an answer after 30 seconds, repeat your call beginning at step 3 above. Uniden Atlantis 155 Owner’s Manual...
  • Page 3 13. Terminez le message en disant “ICI {nom ou indicatif d’appel de votre bateau}, À VOUS”. 14. Relâchez le bouton Push to Talk du microphone et écoutez. Si vous n’obtenez pas de réponse après 30 secondes, répétez l’appel encommençant à l’étape 3 ci-dessus. Uniden Atlantis 155 Owner’s Manual...
  • Page 4 Uniden Atlantis 155 Owner’s Manual...

  • Page 5: Table Of Contents

    GETTING STARTED ............8 WHAT’S INCLUDED ..............8 CONTROLS AND INDICATORS ..........9 KEY OPERATION ............... 10 ATLANTIS 155 LCD DISPLAY ..........11 CONNECTING POWER .............. 12 RECHARGING THE ATLANTIS 155 ......... 13 Battery Level Display ............... 14 ATTACHING THE BELTCLIP ............ 14 To attach the belt clip: ..............
  • Page 6 MAINTENANCE & TROUBLESHOOTING ....25 COMMON QUESTIONS .............. 25 SPECIFICATIONS ............26 CHANNELS AND FREQUENCIES (MHZ) ....28 MARINE RADIO CHANNEL CHART ......... 28 REGULATIONS AND SAFETY WARNINGS ...33 MARITIME RADIO SERVICES OPERATION ......33 THREE-YEAR LIMITED WARRANTY ......37 Uniden Atlantis 155 Owner’s Manual...

  • Page 7: Atlantis 155 Introduction

    This handheld VHF marine radio will give you consistent, outstanding performance in virtually all conditions and situations. To ensure that you get the most from the Atlantis 155 features, please read this operating guide carefully before using the unit. FEATURES...

  • Page 8: Getting Started

    *Protected against the effects of continuous immersion in water. The Atlantis 155 can withstand immersion in water up to 3.5 feet depth for 30 minutes. The Atlantis 275 has a special tone that will vibrate the speaker to remove water inside the casing (see page E-18).

  • Page 9: Controls And Indicators

    Antenna SQL UIC (Squelch) PTT (Push-To-Talk) VOL ▼ Power Boost WX ALERT CH ▲ VOL ▲ CH ▼ 16/9 TRI LCD Screen H/L LOCK Speaker DC IN/Headset Jacks Drainage Opening Wrist Strap SCAN MEM Microphone Uniden Atlantis 155 Owner’s Manual...

  • Page 10: Key Operation

    Turn Triple Watch on and off. 16/9 TRI 3rd press: Go back to the starting channel. Select LCD backlight level (high, middle, or low) then Turn the radio on and off. color (white or amber). E-10 Uniden Atlantis 155 Owner’s Manual...

  • Page 11: Atlantis 155 Lcd Display

    Indicates if channel numbers have leading 10 or 20 (1078, 2078). Battery Status Indicates battery level remaining. WX ALERT Displays when Weather Alert Watch enabled. WX Mode Displays when in Weather mode. Squelch Volume Uniden Atlantis 155 Owner’s Manual E-11...

  • Page 12: Connecting Power

    2. Remove the belt clip if necessary. 3. Use a screwdriver or the screwdriver tip on the belt clip to turn the battery compartment screw counterclockwise and then lift up and remove the battery cover. E-12 Uniden Atlantis 155 Owner’s Manual...

  • Page 13: Recharging The Atlantis 155

    If the rubber seal appears worn, nicked, or dried out, replace it. Visit www.uniden.com to order a replacement seal. 6. Replace the battery compartment door. Tighten the screw securely.

  • Page 14: Attaching The Beltclip

    Press and hold the belt clip lock down while simultaneously sliding it upward until it releases. OPERATION In order to get the most out of your new radio, read this owner’s manual completely before attempting to operate the unit. E-14 Uniden Atlantis 155 Owner’s Manual...

  • Page 15: Basics

    Make sure to first select a channel not in use before setting the squelch. NOTE Think of the squelch control as a gate. If you increase the squelch level to maximum, it raises the “Squelch Gate” so only the strongest signals get through. Uniden Atlantis 155 Owner’s Manual E-15...

  • Page 16: Transmitting And Receiving

    Each time you press and hold SQL UIC, the mode indicator changes (US - United States; CAN - Canada; INT - International). Refer to page 28 for a list of the available channels and corresponding frequencies. E-16 Uniden Atlantis 155 Owner’s Manual...

  • Page 17: Transmitting

    (HI - 3W) except for US channels 13, 17, 67, 75, 76, and NOTE 77, CAN channels 13, 15, 17, 20, 66A, 75, 76, and 77, and INT channels 15, 17, 75, and 76. Receiving Release PTT or BOOST to receive another party's transmissions to you. Uniden Atlantis 155 Owner’s Manual E-17...

  • Page 18: How It Works

    To transmit, remove the radio from the charger, then press and hold the PTT key. Release the key when you are finished talking. x For the best sound quality, hold the microphone about two inches from your mouth while you’re talking. E-18 Uniden Atlantis 155 Owner’s Manual...

  • Page 19: Normal Mode With Weather Alert Watch

    9 or 16 while you are actively transmitting; it waits until your transmission is finished and then checks the channels. Monitoring Channel 25 Every few seconds, the radio checks channels 16 & 9. Triple Watch on Uniden Atlantis 155 Owner’s Manual E-19...

  • Page 20: Scan Mode Operation

    Scan mode with Weather Alert Watch If you activate Weather Alert Watch while in scan mode (press and hold WX ALERT), the radio checks the most recently- used weather channel every seven seconds, then continues E-20 Uniden Atlantis 155 Owner’s Manual...

  • Page 21: Scan Mode With Triple Watch

    You cannot transmit while in weather mode. x To enter weather mode, press the WX ALERT key. x If the radio setects a WX Alert signal, it sounds an alert tone 3 times. Uniden Atlantis 155 Owner’s Manual E-21...

  • Page 22: Weather Mode With Weather Alert Watch

    Emergency Channel 16/9 While monitoring a channel (CH 20 Press 16/9 Press 16/9 again in this example), again to mon- to monitor the press 16/9 to itor CH 9. original channel monitor CH 16. (CH 20). E-22 Uniden Atlantis 155 Owner’s Manual...

  • Page 23: Triple Watch

    2. Press the icon again and the backlight level/color changes in the following order: White High (default) - White Medium - White Low - Amber High - Amber Medium - Amber Low - White High, etc. Uniden Atlantis 155 Owner’s Manual E-23...

  • Page 24: Adjust Lcd Contrast

    1. Press both VOL and VOL to activate this feature. The speaker vibrates and a tone sounds. 2. Press any key to turn off the tone. E-24 Uniden Atlantis 155 Owner’s Manual...

  • Page 25: Maintenance & Troubleshooting

    Adjust the squelch level; it is probably too high. I can’t hear anything from If the radio has fallen into water, activate the speaker. the Speaker Vibration Tone (see page 24). The vibration will help remove water from the unit. Uniden Atlantis 155 Owner’s Manual E-25...

  • Page 26: Specifications

    8.53 oz (242g) (w/batteries) Transmitter Frequency Range 156.050 ~ 161.6 MHz Frequency Stability ± 5 PPM Power Output 1W and 3W Spurious Emissions -34 dBm on Hi; -40 dBm on Lo Current Drain 1000 mA (3W) E-26 Uniden Atlantis 155 Owner’s Manual...
  • Page 27 +5.5 dB @ 500 Hz; -6.5 dB @ 2000 Hz Response Adjacent Channel 60 dB @ ±25 kHz Selectivity Audio Output Power 0.5W @10% THD Current Drain Squelched: 60 mA; Max. Audio: 150 mA Uniden Atlantis 155 Owner’s Manual E-27...

  • Page 28: Channels And Frequencies (Mhz)

    US: Non-Commercial 156.500 156.500 Commercial 156.550 156.550 Vessel Traffic System 156.600 156.600 Vessel Traffic System Bridge to Bridge 156.650 156.650 US and CAN: 1W 156.700 156.700 Vessel Traffic System Receive Inhibit 156.750 Environmental Only E-28 Uniden Atlantis 155 Owner’s Manual...
  • Page 29 157.100 157.100 US Coast Guard 157.150 161.750 Marine Operator 23B* INHIBIT 161.750 CMB Service 1023 157.150 157.150 US Coast Guard Only 157.200 161.800 Marine Operator 157.250 161.850 Marine Operator 25B* INHIBIT 161.850 CMB Service Uniden Atlantis 155 Owner’s Manual E-29...
  • Page 30 156.275 156.275 Port Operation 156.325 160.925 Marine Operator Port Operations 156.325 156.325 Canada: 1 Watt Only 1066 156.325 156.325 Port Operations 156.375 156.375 Bridge-to-Bridge, 1W 156.425 156.425 Non-Commercial 156.475 156.475 Non-Commercial Inhibit 156.5250 Only E-30 Uniden Atlantis 155 Owner’s Manual...
  • Page 31 157.075 Government 157.125 161.725 Port Operations 157.125 157.125 Canadian Coast Guard 1082 157.125 157.125 Government 157.175 161.775 Port Operations 157.175 157.175 Canadian Coast Guard Canadian CG Continuous Marine 83B* INHIBIT 161.775 Broadcast (CMB) Service Uniden Atlantis 155 Owner’s Manual E-31...
  • Page 32 162.400 MHz WX03 162.4750 162.475 MHz WX04 162.4250 162.425 MHz WX05 162.4500 162.450 MHz WX06 162.5000 162.500 MHz WX07 162.5250 162.525 MHz WX08 161.6500 161.650 MHz WX09 161.7750 161.775 MHz WX10 163.2750 163.275 MHz E-32 Uniden Atlantis 155 Owner’s Manual...

  • Page 33: Regulations And Safety Warnings

    REGULATIONS AND SAFETY WARNINGS WARNING! Read this information before using the radio. RBRC Information As part of our commitment to protect the environment and conserve natural resources, Uniden voluntarily participates in an RBRC industry program to collect and recycle used Ni-MH ®...
  • Page 34 (2) this device must accept any interference received, including interference that may cause undesired operation. Unauthorized changes or modifications to this equipment may void compliance with I.C. Rules. Any change or modification must be approved in writing by Uniden. E-34 Uniden Atlantis 155 Owner’s Manual...
  • Page 35 Changes or modifications not approved by Uniden could void the user’s authority to operate the equipment. L’appareil est conforme aux normes d’Industrie Canada. Son fonctionnement est soumis aux deux conditions suivantes : (1) Ce dispositif ne doit pas causer d’interférences et (2), il doit pouvoir accepter les interférences, incluant celles...
  • Page 36 For hand-held operation, the radio should be held 1 inch from the user’s face. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements and should be avoided. For more E-36 Uniden Atlantis 155 Owner’s Manual...

  • Page 37: Three-Year Limited Warranty

    Three-Year Limited Warranty WARRANTOR: UNIDEN AMERICA CORP. (“Uniden”) ELEMENTS OF WARRANTY: Uniden warrants, for three years, to the original retail owner, this Uniden Product to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.
  • Page 38 Uniden, or (F) installed or programmed by anyone other than as detailed by the Operating Guide for this product. STATEMENT OF REMEDY: In the event that the product does not conform to this warranty at any time while this war-...
  • Page 39 The Product should be shipped freight prepaid, by traceable means, or delivered, to warrantor at: Uniden America Corporation C/O Saddle Creek 743 Henrietta Creek, Suite 100 Roanoke, TX, 76262 Uniden Atlantis 155 Owner’s Manual E-39...
  • Page 40 QUESTIONS? Visit our website at www.uniden.com. QUESTIONS? Visitez notre site Web au www.uniden.com. Printed in Vietnam Imprimé au Vietnam U01UT659ZZZ(0)
