Using the Fusion™ Charger Base
When microphones are not in use, they should be properly inserted into the
Charger Base. It is important to ensure that the system microphones are
inserted fully in the base so that charging will occur.
1. LED indicator — power / mute status indicator
2. Charger Bay — charges up to 8 Microphones.
3. Power Cord Receptacle— power supply input (on rear)
The Charger Base requires 5VDC power, provided by the AC Adapter. Plug the
supplied AC wall adapter into an appropriate power outlet 110-240 AC, 50-
60Hz. The power LED on the Charger Base will illuminate.
Charging the Microphone Batteries
First-time use — before using the wireless microphone the first time, charge
the batteries in the microphones for eight hours (or overnight) in the Charger
Base.
Page 6
3
1
2
