Network configuration

xConfiguration Network [1..1] IPStack
Select if the sFystem should use IPv4, IPv6, or dual IP stack, on the network interface. NOTE: After
changing this setting you may have to wait up to 30 seconds before it takes effect.
Requires user role: ADMIN
Value space: <Dual/IPv4/IPv6>
Dual: When set to Dual, the network interface can operate on both IP versions at the same time,
and can have both an IPv4 and an IPv6 address at the same time.
IPv4: When set to IPv4, the system will use IPv4 on the network interface.
IPv6: When set to IPv6, the system will use IPv6 on the network interface.
Example: xConfiguration Network 1 IPStack: Dual
xConfiguration Network [1..1] IPv4 Assignment
Define how the system will obtain its IPv4 address, subnet mask and gateway address. This setting
only applies to systems on IPv4 networks.
Requires user role: ADMIN
Value space: <Static/DHCP>
Static: The addresses must be configured manually using the Network IPv4 Address, Network IPv4
Gateway and Network IPv4 SubnetMask settings (static addresses).
DHCP: The system addresses are automatically assigned by the DHCP server.
Example: xConfiguration Network 1 IPv4 Assignment: DHCP
xConfiguration Network [1..1] IPv4 Address
Enter the static IPv4 network address for the system. This setting is only applicable when Network
Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv4 address.
Example: xConfiguration Network 1 IPv4 Address: "192.0.2.2"
Codec C20 API Reference Guide TC7.0, JANUARY 2014.
D14869.11
About the API xConfiguration xConfiguration
xConfiguration Network [1..1] IPv4 Gateway
xConfiguration Network [1..1] IPv4 SubnetMask
xConfiguration Network [1..1] IPv6 Assignment
39
xCommand
Define the IPv4 network gateway. This setting is only applicable when the Network Assignment is
set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv4 address.
Example: xConfiguration Network 1 IPv4 Gateway: "192.0.2.1"
Define the IPv4 network subnet mask. This setting is only applicable when the Network Assignment
is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: The valid IPv4 address format.
Example: xConfiguration Network 1 IPv4 SubnetMask: "255.255.255.0"
Define how the system will obtain its IPv6 address and the default gateway address. This setting
only applies to systems on IPv6 networks.
Requires user role: ADMIN
Value space: <Static/DHCPv6/Autoconf>
Static: The codec and gateway IP addresses must be configured manually using the Network
IPv6 Address and Network IPv6 Gateway settings. The options, for example NTP and DNS server
addresses, must either be set manually or obtained from a DHCPv6 server. The Network IPv6
DHCPOptions setting determines which method to use.
DHCPv6: All IPv6 addresses, including options, will be obtained from a DHCPv6 server. See RFC
3315 for a detailed description. The Network IPv6 DHCPOptions setting will be ignored.
Autoconf: Enable IPv6 stateless autoconfiguration of the IPv6 network interface. See RFC 4862
for a detailed description. The options, for example NTP and DNS server addresses, must either
be set manually or obtained from a DHCPv6 server. The Network IPv6 DHCPOptions setting
determines which method to use.
Example: xConfiguration Network 1 IPv6 Assignment: Autoconf
