Status

A status contains the current state of the codec, such as
connected calls, the status of the gatekeeper registration,
connected inputs and output sources.
Writing xStatus ? on the command line lists all top level
statuses.
Writing xStatus lists all statuses and their current values.
To list out only some of the statuses, write xstatus followed by
the relevant part of the status path.
Codec C20 API Reference Guide TC7.0, JANUARY 2014.
D14869.11
About the API About the API xConfiguration
xStatus ?
– Status –
Audio
Call[...]
Camera [1..1]
Conference
Diagnostics
Experimental
H320
OK
Addressing status information with xStatus
To read the status from the system type the root command (xStatus) followed by a path (address expression):
xStatus <address expression>
Example 1: Query all ongoing Call information:
xStatus Call
*s Call 2 Status: Connected
*s Call 2 Direction: Outgoing
*s Call 2 Protocol: "sip"
*s Call 2 CallType: Video
*s Call 2 RemoteNumber: "name@company.com"
*s Call 2 CallbackNumber: "sip:name@company.com"
*s Call 2 DisplayName: "name@company.com"
*s Call 2 TransmitCallRate: 1152
*s Call 2 ReceiveCallRate: 1920
*s Call 2 CallPriority: None
*s Call 2 FacilityServiceId: 0
*s Call 2 Encryption Type: "None"
*s Call 2 PlacedOnHold: False
*s Call 2 Duration: 6
*s Call 2 AnswerState: Answered
*s Call 2 ModifyState: Idle
*s Call 2 DeviceType: Endpoint
** end
OK
14
xCommand xStatus
H323
HttpFeedback[1..4]
ICE
MediaChannels
Network [1..1]
NetworkServices
Preset[1..15]
Example 2: Query the protocol for a call:
xStatus Call Protocol
*s Call 3 Protocol: "sip"
OK
Copyright © 2010–2014 Cisco Systems, Inc. All rights reserved.
API Reference Guide
Appendices
Provisioning
Security
SIP
Standby
SystemUnit
Time
Video
