xConfiguration Video Output HDMI [1,2] CEC Mode
The HDMI outputs support Consumer Electronics Control (CEC). When set to on (default is off), and
the monitor connected to the HDMI output is CEC compatible and CEC is configured, the system
will use CEC to set the monitor in standby when the system enters standby. Likewise the system
will wake up the monitor when the system wakes up from standby. Please note that the different
manufacturers uses different marketing names for CEC, for example Anynet+ (Samsung); Aquos
Link (Sharp); BRAVIA Sync (Sony); HDMI-CEC (Hitachi); Kuro Link (Pioneer); CE-Link and Regza Link
(Toshiba); RIHD (Onkyo); HDAVI Control, EZ-Sync, VIERA Link (Panasonic); EasyLink (Philips); and
NetCommand for HDMI (Mitsubishi).
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable CEC control.
On: Enable CEC control.
Example: xConfiguration Video Output HDMI 1 CEC Mode: Off
xConfiguration Video Output HDMI [1,2] MonitorRole
The HDMI monitor role describes which video stream will be shown on the monitor connected to the
video output HDMI connector.
Requires user role: ADMIN
Value space: <Auto/First/Second/PresentationOnly>
Auto: The system will detect when a monitor is connected and assign a monitor role to it. The first
monitor connected will be assigned monitor role First. In a multi-monitor setup the next monitor
will be assigned monitor role Second.
First/Second: Define the role of the monitor in a multi-monitor setup. In a single-monitor setup,
there is no difference between First and Second.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: xConfiguration Video Output HDMI 1 MonitorRole: Auto
xConfiguration Video Output HDMI [1,2] OverscanLevel
Some TVs or other monitors may not display the whole image sent out on the systems video output,
but cuts the outer parts of the image. In this case this setting can be used to let the system not use
the outer parts of video resolution. Both the video and the on-screen menu will be scaled in this
case.
Requires user role: ADMIN
Value space: <None/Medium/High>
None: The system will use all of the output resolution.
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution.
Example: xConfiguration Video Output HDMI 1 OverscanLevel: None
Codec C20 API Reference Guide TC7.0, JANUARY 2014.
D14869.11
About the API xConfiguration xConfiguration
xConfiguration Video Output HDMI [1,2] Resolution
xConfiguration Video WallPaper
72
xCommand
Select the preferred resolution for the monitor connected to the video output HDMI connector. This
will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_50/1280
_720_60/1920_1080_50/1920_1080_60/1280_768_60/1360_768_60/1366_768_60/1600_1200_
60/1680_1050_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with the
connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1680x1050@60p, 1920x1200@60p
Example: xConfiguration Video Output HDMI 1 Resolution: Auto
Select a background image (wallpaper) for the video screen when idle.
Requires user role: USER
Value space: <None/Custom/Growing/Summersky/Waves>
None: There is no background image on the screen, i.e. the background is black.
Custom: Use the custom wallpaper that is stored on the system as background image on the
screen. As default, there is no custom wallpaper stored and the background will be black. You
can upload a custom wallpaper to the system using the web interface. The maximum supported
resolution is 1920x1200.
Summersky, Growing, Waves: The chosen background image is shown on the screen.
Example: xConfiguration Video Wallpaper: Summersky
