Translating from terminal mode to XML

Translating commands
The XML commands maintain the same structure as the
terminal commands, but they use a parent-child relationship
to describe the hierarchy. You can see this structure in the
examples below.
Example 1: Setting up a call.
Terminal
xCommand Dial Number: "12345" Protocol: H323
XML
<Command>
<Dial command="True">
<Number>12345</Number>
<Protocol>H323</Protocol>
</Dial>
</Command>
Example 2: Assigning video layout to a call.
Terminal
xCommand Video Layout AssignCall CallId: 2
LayoutId: 1
XML
<Command>
<Video>
<Layout>
<AssignCall command="True">
<CallId>2</CallId>
<LayoutId>1</LayoutId>
</AssignCall>
</Layout>
</Video>
</Command>
SX20 Codec API Reference Guide TC7.0, JANUARY 2014.
D14949.08
About the API About the API xConfiguration
Translating configurations
Translating from xConfiguration to XML is similar to
commands, but with the addition of a special attribute
item="NN" for specifying the index in arrays.
Example: Configuring connector for input source 2.
Terminal
xConfiguration Video Input Source 2
Connector: HDMI
XML
<Configuration>
<Video>
<Input>
<Source item="2">
<Connector>HDMI</Connector>
</Source>
</Input>
</Video>
</Configuration>
21
