xCommand Conference ActiveSpeaker Set
For manually setting the active speaker in a conference. Overrides normal voice switching.
Target: Identifies local or remote participant.
CallId: Identifies CallID for remote participant. Only relevant if Target is set to "remote".
Requires user role: USER
Parameters:
Target(r): <local/remote<
CallId: <0..65534>
Example:
Example 1
xCommand Conference ActiveSpeaker Set Target: local
*r ConferenceActiveSpeakerSetResult (status=OK):
** end
Example 2
xCommand Conference ActiveSpeaker Set Target: remote CallID: 3
*r ConferenceActiveSpeakerSetResult (status=OK):
** end
SX20 Codec API Reference Guide TC7.0, JANUARY 2014.
D14949.08
About the API xConfiguration
Dial commands
xCommand Dial
94
xCommand xCommand
Dial out from the system. Returns information about the CallId and ConferenceId, which are required
for some other commands.
Number: Enter the number or address.
Protocol: Select the SIP, H323 or H320 protocol.
CallRate: Set a call rate.
CallType: Select the audio or video call type.
BookingId: Any identifier that an external booking system (e.g. TMS, CTS-MAN) can use for its own
references to match placed calls with the booking systems internal identifier for a meeting. This can
be any string, e.g. a GUID. The booking Id is supplied in call logs, call events etc for the call.
DisplayName: The display name of the remote participant.
Requires user role: USER
Parameters:
Number(r): <S: 0, 255>
Protocol: <H320/H323/Sip>
CallRate: <64..6000>
CallType: <Audio/Video>
BookingId: <S: 0, 255>
Appearance(o): <1..999999999>
DisplayName(o): <S: 0, 255>
Example:
xCommand Dial Number:543210 Protocol:h323
OK
*r DialResult (status=OK):
CallId: 2
ConferenceId: 1
** end
