Preset commands
xCommand Preset Store
Store the connector selections for all video input sources and the current position for all cameras.
Note that information about all video input sources and all camera positions are included in the
same preset. The system may hold 15 predefined video input presets. These presets are available
for far end control, i.e. they are referred in the PresetId parameter of the xCommand FarEndControl
Preset Activate command. In contrast, the xCommand Camera Preset commands applies to
individual cameras only. Those presets are not available for far end control.
PresetId: The ID of this preset.
Type: Currently it makes no difference if you select Camera or All. However, this may change in the
future (other audio or video settings may be included in a preset). If you want to ensure that a preset
only affects camera positions we recommend that you select Camera.
Description: Enter a description of the camera preset.
Requires user role: USER
Parameters:
PresetId(r): <1..15>
Type(r): <All/Camera>
Description: <S: 0, 255>
Example:
xCommand Preset Store PresetId:3 Type:Camera Description:"Left view"
OK
*r PresetStoreResult (status=OK):
** end
xCommand Preset Activate
Activate one of the stored local presets.
PresetId: The ID of the preset you want to activate.
Requires user role: USER
Parameters:
PresetId(r): <1..15>
Example:
xCommand Preset Activate PresetId:3
OK
*r PresetActivateResult (status=OK):
** end
SX20 Codec API Reference Guide TC7.0, JANUARY 2014.
D14949.08
About the API xConfiguration
xCommand Preset Clear
107
xCommand xCommand
Delete a preset.
PresetId: The ID of the preset you want to delete.
Requires user role: USER
Parameters:
PresetId(r): <1..15>
Example:
xCommand Preset Clear PresetId:3
OK
*r PresetClearResult (status=OK):
** end
