xStatus Video PIP Presentation Position

Shows the position of the presentation image on the screen.
Value space of the result returned:
<UpperLeft/UpperCenter/UpperRight/CenterLeft/CenterRight/LowerLeft/LowerRight>
Example:
xStatus Video PIP Presentation Position
*s Video PIP Presentation Position: CenterLeft
** end

xStatus Video OSD Output

Indicates which monitor is used for on-screen display output.
Value space of the result returned:
<Integer>
Example:
xStatus Video OSD Output
*s Video OSD Output: 3
** end

xStatus Video OSD Mode

Indicates whether on-screen display in indicator or full mode.
Indicators: The on-screen display is in passive mode when a Touch controller is paired to the
system.
Full: Full on—screen display menu is active and can be controlled with a remote control.
Value space of the result returned:
<Indicators/Full>
Example:
xStatus Video OSD Mode
*s Video OSD Mode: Full
** end
SX20 Codec API Reference Guide TC7.0, JANUARY 2014.
D14949.08
About the API xConfiguration

Experimental status

The Experimental status is for testing only and should not be used unless agreed with Cisco. These
settings are not documented and WILL change in later releases.
190
