The RFID reader supports the following formats:
•
ISO/IEC 14443A/B
•
ISO/IEC 15693
•
ISO/IEC 18000-3
•
MIFARE Classic
To use the RFID reader:
1. Hold the unit by the handle with the right edge in front of you.
2. Aim the right edge of the unit at the RFID tag and align the RFID antenna/logo with the
tag. Ensure that the tag is 1–1.5 inches (25–40 mm) from the RFID antenna scan area.
3. Press and release the RFID button on the top of the unit. The RFID light will come on to
indicate that the unit is scanning.
The RFID light goes off and the unit beeps to indicate a successful scan. The ASCII and Hex
data appears in the RFID Tag Data window.
Chapter 2
Using your C5t/F5t
RFID tag
1 – 1.5 inches
Using the RFID reader 39
