Configuring Front Panel Buttons - Motion Computing C5t User Manual

Button
Directional
pad
Enter
A
B
The directional pad orientation rotates to match the display orientation. To move the
pointer in a certain direction, press that direction on the pad regardless of orientation. For
example, "up" in landscape orientation becomes "left" in portrait orientation.

Configuring front panel buttons

As you become more familiar with your tablet, you can customize the buttons on the front
panel. You can configure the buttons to start your favorite program, run a command, or
enter a key combination.
To configure the front panel buttons:
1. Open
2. Tap Pen & Tablet.
3. Tap the Tablet PC Settings button.
4. In the Tablet PC Settings window, tap the Buttons tab.
5. Select the primary or secondary orientation for which you want to change the button
settings from the Button settings for: drop-down list.
T : You can configure different button settings for different orientations.
IP
6. Select the button combination you want to change. The currently selected buttons
appear in red.
7. Tap Change.
8. Select the appropriate action for the button.
For some actions, you must enter more information, such as the location of a program to
start. You can select an action for Press and another for Press and hold. For more
information, tap What is press and hold?
N : To reset the buttons to their default values, tap the Reset button.
OTE
Chapter 2 Using your C5t/F5t
Primary
Moves the pointer or navigates
through documents. Equivalent to
arrow keys on a keyboard.
Makes a selection—equivalent to
the Enter key
Performs application-specific
function
Activates the barcode scanner (if
installed)
Motion Dashboard.
Secondary
(Function+button)
Left = Shift+Tab
Right = Tab
Up = Page Up
Down = Page Down
Windows® logo key
Rotates the display orientation
Cancels the current task—
equivalent to the Esc key
Using the front panel buttons 29
