- Page 1 MODEL GL-C INSTALLATION & OPERATION Rev. 1.00A C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841...
-
Page 2: Table Of Contents
1. RECEIVING ...2 2. SPECIFICATIONS ...3 3. INSTALLATION...4 3.1..4 LECTRICAL 3.2..4 LUMBING 4. GLC FLOW DIAGRAM ...4 OPERATION...6 5.1. ILLING THE 5.2. PERATING NSTRUCTIONS 3.2.1. Proper Chemical Dosage ... 6 5.3. LEANING NSTRUCTIONS 3.3.1. Daily Cleaning Instructions... 7 3.3.2. -
Page 3: Model Gl-C
E. Check that the detergent tank screen in the detergent tank is in position. F. Check that the drain screen is in position. 4. Important: Read and follow up instructions completely. MODEL GL-C Installation & Operation Manual Rev. 1.00A –2/23/06 Receiving Page... -
Page 4: Specifications
HEIGHT MAX CLEARANCE FOR GLASSES ELECTRICAL TANK HEATER (Not Booster Heater) WASH PUMP MOTOR SHIPPING WEIGHT GL-C (Approximate) MODEL GL-C Installation & Operation Manual Rev. 1.00 –2/23/06 Specifications 3 GAL. 11.35 L. 12 GAL. 45.42 L. 168 GAL. 636 L. -
Page 5: Nstructions
2. PVC pipe is generally recommended, as copper is prone to attack by the sanitizing chemicals. *Electrical and plumbing connections must be made by a qualified person who will comply with all available Federal, State, and Local Health, Electrical, Plumbing and Safety codes. MODEL GL-C Installation & Operation Manual Rev. 1.00A –2/23/06 Instructions Page... -
Page 6: Glc Flow Diagram
Flow Diagram 4. GLC Flow Diagram Page MODEL GL-C Installation & Operation Manual Rev. 1.00 –2/23/06... -
Page 7: Operation
Note: If a sodium Hypochlorite (Chlorine) based sanitizer at a minimum concentration of 50ppm in the final rinse is used, use chlorine test papers to verify and monitor the 50ppm chlorine level MODEL GL-C Installation & Operation Manual Rev. 1.00 –2/23/06 Operation... -
Page 8: Cleaning Instructions
Hold prime buttons in until the feed lines have been thoroughly flushed. Replace the feed lines to their proper container and prime product through lines. MODEL GL-C Installation & Operation Manual Rev. 1.00A –2/23/06 Operation Page... -
Page 9: Maintenance
Lack of pressure in rinse Rinse spray tubes dirty spray tube Shut-off valve on supply line closed Low water pressure MODEL GL-C Installation & Operation Manual Rev. 1.00 –2/23/06 Maintenance SOLUTION Reset circuit breaker Replace drive motor Remove obstruction Replace or adjust... - Page 10 Chemical supply strainer plugged Speed adjustment set too low No power to pump Pump motor defective MODEL GL-C Installation & Operation Manual Rev. 1.00 –2/23/06 SOLUTION Check coil Check and install rebuild kit Replace if necessary Remove screen and clean...
-
Page 11: Electrical Diagram
Electrical Diagram 7. Electrical Diagram Page MODEL GL-C Installation & Operation Manual Rev. 1.00A –2/23/06...
