MODEL CMA-130VL
PARTS MANUAL
Rev 1.00
D I S T R I B U T E D E X C L U S I V E L Y B Y
C M A D I S H M A C H I N E S
1 2 7 0 0 K N O T T A V E N U E
GARDEN GROVE, CALIFORNIA 92841
8 0 0 - 8 5 4 - 6 4 1 7
F A X 7 1 4 - 8 9 5 - 2 1 4 1
www.cmadishmachines.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMA-130VL and is the answer not in the manual?

Questions and answers

Summary of Contents for CMA Dishmachines CMA-130VL

  • Page 1 MODEL CMA-130VL PARTS MANUAL Rev 1.00 D I S T R I B U T E D E X C L U S I V E L Y B Y C M A D I S H M A C H I N E S...
  • Page 2: Table Of Contents

    ABLE OF ONTENTS CMA-130VL ODEL 1. PARTS MANUAL..................3 1.1......................3 ECHANICAL RAWINGS 1.1.1. General Body Parts ....................... 3 1.1.2. Closing Paneling ......................4 1.1.3. Control Panel and Switches................... 5 1.1.4. Electric Control Components ..................6 1.1.5. Solenoid Valve Group....................7 1.1.6.
  • Page 3: Parts Manual

    Parts Manual 1. Parts Manual 1.1. Mechanical Drawings 1.1.1. General Body Parts P- Code DESCRIPTION P- Code DESCRIPTION Right/left Slide Bearing 30300 2400.01 Guide rail 30365 2400.23 O-ring 151 NBR 30305 2400.03 Rack Frame 30375 2101.11 Strainer Plate with a Strainer 2,7/2,94KW 230/240V 3 Heating Elem.
  • Page 4: Closing Paneling

    Parts Manual 1.1.2. Closing Paneling P- Code DESCRIPTION P- Code DESCRIPTION 2400.45 Guide 2400.73 Bearing Holder 2400.47 Handle 2400.75 Screw 2400.49 Bearing 2400.77 Gasket Ø 14x8x1,5 2400.51 Screw 2400.79 Hood Spring 2400.53 Filter 2400.81 Hook Screw 2400.55 Roller 2400.83 Guide, Right 2400.55 Roller 2400.85...
  • Page 5: Control Panel And Switches

    Parts Manual 1.1.3. Control Panel and Switches P- Code DESCRIPTION P- Code DESCRIPTION 42000 2401.29 42030 2401.39 Control Panel Cover Gaskets 42010 42035 2401.41 2401.31 Process Grill Membrane Board Spacer 42015 42040 2401.43 2401.33 Top Push Button Membrane Top Electronic Timer 42020 2401.35 42045...
  • Page 6: Electric Control Components

    Parts Manual 1.1.4. Electric Control Components P- Code DESCRIPTION P- Code DESCRIPTION 29700 2401.47 2401.55 Electric Component Panel 29740 Contactor25a/16a 230 50/60 2401.57 29705 2401.49 Low Noise Filter 29745 Connecting Piece 2401.59 29720 2100.37 Safety Thermostat (or 2105.12) 29750 Connecting Piece 2100.69 2401.61 29730...
  • Page 7: Solenoid Valve Group

    Parts Manual 1.1.5. Solenoid Valve Group P- Code DESCRIPTION P- Code DESCRIPTION 2401.73 Solenoid Valve N.C. Pressure Reducing Ring 1.1.6. Double Solenoid Valve Group P- Code DESCRIPTION P- Code DESCRIPTION 2401.67 Solenoid Valve N.C. Pressure Reducing Ring 2401.69 Pressure Solenoid Valve 2401.71 Pressure Reducer Page...
  • Page 8: Ways Connection

    Parts Manual 1.1.7. 3 Ways Connection P- Code DESCRIPTION P- Code DESCRIPTION 30800 2402.59 Y Connection 10/12/12 30810 2402.61 Rinse Pipe 30805 2101.42 Clamp 12/22 30815 2401.25 Pipe Gasket 1.1.8. Pressure Switch Group P- Code DESCRIPTION P- Code DESCRIPTION 2100 2402.93 Pressure Switch PR 2115...
  • Page 9: Rinse With Steady Temperature

    Parts Manual 1.1.9. Rinse With Steady Temperature P- Code DESCRIPTION P- Code DESCRIPTION 41200 2401.75 2401.91 Break Tank Assy. 41280 Boiler 2401.77 2401.93 41205 Long Pipe L=1070 41285 Heating Element 9kW 2401.79 2401.95 41210 Rubber Hose - PVC 41285 Heating Element 12kW 2401.97 41215 Pipe Coupling...
  • Page 10: Booster Pump

    Parts Manual 1.1.10. Booster Pump P- Code DESCRIPTION P- Code DESCRIPTION 7500 2401.89 7512 2402.03 220/240V 60 Hz Plus Rinsing pump O-ring EPDM 7510 2401.87 7513 2402.05 5 uF condenser - 450V Pump Rotor 7511 2402.01 7514 2402.07 Rotating Seals Scroll Page MODELCMA-130VL PARTS MANUAL Rev.
  • Page 11: Rinse Aid Dispenser Group

    Parts Manual 1.1.11. Rinse Aid Dispenser Group P- Code DESCRIPTION P- Code DESCRIPTION 45155 2402.41 45200 2402.52 Spring Sphere - Teflon 45160 2402.43 45205 2402.55 Membrane Disk Brass Pipe Fitting 45165 2402.45 45210 2402.57 Membrane Guide Valve O-Ring 45175 2402.47 45215 2101.47 Rubber Holder O 10mm...
  • Page 12: Detergent Dispenser Group

    Parts Manual 1.1.12. Detergent Dispenser Group P- Code DESCRIPTION P- Code DESCRIPTION 5135 2100.95 5100 2100.19 Detergent pump Seco Squeeze Tube 5140 2100.19 5105 2101.47 Ballast Detergent Pump 5145 2100.96 5110 2101.48 Small Filter Squeeze Tube 5150 2100.97 5120 2101.02 Complete S/S Injector Squeeze Tube 5155...
  • Page 13: Heat Recovery

    Parts Manual 1.1.13. Heat Recovery P- Code DESCRIPTION P- Code DESCRIPTION 2400.99 Spoiler 2401.17 Battery Self Cleaning Pipe 2401.01 Motor Fan 230v 50/60hZ 2401.19 Isolated Hood Trap 2401.03 Fan Support 2401.20 O-Ring 44x32x3 2401.05 Heat Recovery Battery 2401.21 Drain Fitting 2401.07 Upper Back 2401.23...
  • Page 14: Wash Pump

    Parts Manual 1.1.14. Wash Pump P- Code DESCRIPTION P- Code DESCRIPTION 30000 2402.63 Pump Base 30030 2402.73 Wash Manifold 30005 2402.65 2hp Pump 230/380/415/3p 30035 2101.56 Rotating Seals 30010 2402.67 Clamp 30/45 30040 2402.75 O-Ring 1225 30015 2402.69 Suction Pipe Coupling 30045 2402.77 Pump Rotor (2hp Pump)
  • Page 15: Drain Pump Group

    Parts Manual 1.1.15. Drain pump Group P- Code DESCRIPTION P- Code DESCRIPTION 30100 2402.87 Pump Support 30120 2100.60 Drain Hose 30105 2401.87 Condenser 30125 2101.55 Clamp 30/45 (minimum 2 pcs) 30110 2402.89 Booster Pump 220/240v 30130 2402.91 Drain Elbow - Rubber 30115 2101.54 Clamp 25/40 (Minimum 2 pcs)
  • Page 16: Turret Group

    Parts Manual 1.1.16. Turret Group P- Code DESCRIPTION P- Code DESCRIPTION 30150 2401.25 Pipe Gasket 30245 2101.67 Rinse Arm Screw 30160 2402.61 Rinse Pipe 30255 2102.15 Open Plastic Rinse Nozzle 30165 2403.01 O-Ring 112 NBR 30260 2102.16 Closed Plastic Rinse Nozzle 30170 2403.03 Coupling...
