Preventive Maintenance; Regular Maintenance; Special Maintenance - CMA Dishmachines UC 60e Installation & Operation Manual

and the message (END) appears on the display.
•
The appliance is now ready for a new wash.
Note: the machine does not accept other cycles until the door is opened or the key (A) is pressed
twice.
•
At the end of the day, clean the machine (see "Preventive Maintenance").
3.3.

Preventive Maintenance.

3.3.1. Regular Maintenance.

In order to ensure perfect performance, the appliance must be completely cleaned at least once a day
in the following way:
•
Turn off the dishwasher by pressing the key (B) and put the machine on stand-by.
•
Turn off main water valve.
•
Remove the overflow tube, press push button (D), and the pump operates for the time set in
programming. The drain pump is activated in the following way:
• activation of a 5sec delay at start;
• activation of the drain pump for the time set in programming, up to the level indicated by the
pressure switch.
•
Remove the filters and clean it with a brush under running water.
•
Remove the spray arms loosening the fixing screws, and thoroughly clean the nozzles and
cleaning and rinsing arms under running water.
•
Reassemble all parts and refit the spray arms in their seats, fixing them with the relative
screws.
•
Clean the tank thoroughly.
Do not use bleach or chlorine based detergents.
At the end of the day, it is advisable to leave the dishwasher door open.
Note: It is advisable to replace the tank water by refilling the tank at least every 20 wash cycles, or
twice a day. Do not use metal brushes or corrosive products, which can damage the machine.

3.3.2. Special Maintenance.

Once or twice a year have a qualified technician inspect the machine:
• Clean the solenoid valve filter
• Remove scale from the heating elements
• Check the tightness of the seals
• Check condition and/or wear of the components
• Check operation of the dispenser
MODEL UC60e INSTALLATION & OPERATION MANUAL Rev. 1.00A
Operatation
Page
6
