2. Getting Started

2.1.

Receiving and Installation

The dishwasher is shipped from the factory in a corrugated box on a wooden pallet. The
installation guidelines give a systematic procedure for setting up the machine.
Start by removing the packaging material. After removing the packing, ensure that the appliance has
not been damaged in transport. If it has, inform the retailer. Set the machine in place, and level
from side-to-side and front-to-back.

2.1.1. Electrical

Single-phase 230 volt, 60 Hz dedicated circuit should be used to supply electrical energy to the
UC60 dishwasher (see specification sheet page 2). This system requires two power wires. An
additional third wire must be provided for ground. CMA and local codes require the UC6060 to be
hardwired using a proper gauge copper wire. The power connection must be located such that
there is sufficient length of the flexible conduit remaining to permit the machine to be moved for
cleaning.

2.1.2. Plumbing

Each machine is provided with a rubber hose with a ¾" threaded attachment for water filling. A
140°F water line should be plumbed to this point. The water line used must be of sufficient length
and flexibility to permit the machine to be moved for cleaning.
The supply water to the UC60 must be a minimum of 140°F at 30 PSI (Pounds per Square Inch).
If it is less than 30 PSI dynamic pressure a pressure pump must be installed to guarantee optimal
machine operation. If, however, the water supply pressure is greater than 60 PSI, a pressure reducer
must be installed.
Connect the drain hose, supplied with the appliance to the drain union in such a way that water flows
freely (insuring a minimum slope). A drain pump is provided to empty the water at a level below
the machine drain. The drain hose should be connected to a trap to prevent odor back -up from
the screen.
2.1.3.

Rinse aid dispenser.

The machine is equipped with a rinse aid dispenser, which automatically draws the product. To
carry out priming, start the machine and do a few complete wash cycles or press adjustment
screw repeatedly. Operating the fine-adjustment screw on the dispenser can regulate the amount
dispensed from 0 to 4cc,equivalent to 0-11inches (0-30cm) drawn into chemical line. Reduce the
amount by turning the screw clockwise, increase by turning it counterclockwise.
1,2
All electrical and plumbing connections must be made by a qualified person who will comply with
all available Federal, State, and Local Health, Electrical, Plumbing and Safety codes
