Initial Parts Kit (P/N 01100.20)

P/N
00100.00
00120.00
00121.00
00200.10
00206.00
00304.03
00304.06
00308.50
00341.00
00363.00
00404.82
00411.00
00415.00
00418.00
00421.40
00433.00
00435.00
00500.00
00562.00
00631.00
00706.00
00715.00
00735.00
00738.10
MODEL AH, B & C PARTS MANUAL Rev. 1.03
DESCRIPTION
Drain Ball Solenoid 120V
Thermometer (Bi Metal)
Drain Ball
Pump Assy 110/220V 60Hz (Open)
Pump Seal Kit
Spray Arm B L1-C & L-1X
Spray Arm A & C
Spray Arm End Plug SS
Spray Arm Bearing (Cleanable)
Spray Base Lock Pin
Motor Contactor 120 VAC
Micro Switch
Peristaltic Pump Assy 120V/60Hz
Peristaltic Pump Cover
Start/Fill switch
Master Switch (30 Amp)
Squeeze Tube 8" Silicone
Timer Motor 90 Sec 110V/60Hz
Roller Door Switch
Ice Cube Relay 120V
3/4 Water Solenoid Repair Kit JE
1/2 Ball Check Valve
3/4 Vac Breaker Rep Kit Watts
Solenoid Coil JE 120V (3/4 &1/2)
Parts Manual
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
