Models AH, C, B, CB
Quick Setup
Instructions
STEP
1
WALL
DRAIN
Connect the drain pipe from scrap
accumulator to floor or wall drain.
STEP
2
Connect hard wire power supply from
dishmachine to power box.
STEP
3
Connect dishmachine to hot water source
recommended 140
0
temperature. (120
minimum temperature required).
FLOOR DRAIN
60"
STEP
4
Insert tube stiffener with chemical tubing into
corresponding chemical dispensers.
0
7"
11"
2" DRAIN
OUTLET
WHITE
BLUE
RED
MODEL AH REAR VIEW
1
POWER SWITCH
HARD WIRE
2
POWER SUPPLY
3/4" WATER
3
INLET
AUTO START
SWITCH
TUBE
4
STIFFENER
4
CHEMICAL
TUBING
