Introduction

This System Reference provides the information necessary to service InterServe 650, 660, and StudioZ
RAX systems.

Restrictions

This document is restricted for use by qualified personnel. In the opening, upgrading, and servicing
instructions, heed all warnings and cautions. Personal injury and damage to equipment can occur if
documented procedures are not followed.
WARNING The system produces high-leakage current. Flip the circuit breaker to the OFF position when
servicing or upgrading the base unit.
CAUTION Use an antistatic wrist strap for all servicing procedures to avoid the possibility of electrostatic
discharge.

Conventions

Bold
Italic
Monospace
SMALL CAPS
+
CTRL D

Additional System Information

A System Setup is shipped with each system, and provides detailed information about:
u
Configuring the operating system and associated system software.
u
Using the system.
u
Using the AMIBIOS Setup program.
u
Installing system software.
A System Introduction is delivered with the system, and provides information about:
u
Intergraph Support
u
System hardware features
u
Available hardware options
Commands, words, or characters that you key in literally.
Variable values that you supply, or cross-references.
Output displayed on the screen.
Key names on the keyboard, such as
directories. You can type filenames and directory names in the dialog boxes
or the command line in lowercase unless directed otherwise.
Press a key while simultaneously pressing another key; for example, press
and simultaneously.
CTRL D
, or . Names of files and
D ALT F3
ix
