1 General Information

Review this chapter before installing the InterServe 650, 660 or StudioZ RAX into the Intergraph rack.
u
Set up the Intergraph rack using the Intergraph Rack Installation (DHA0194x0, supplied with the
rack), and become familiar with the rack enclosure before installing the system hardware.
u
Follow the instructions in Chapter 2 to unpack and set up the InterServe 650 or 660, and in
Chapter 3 to unpack and set up the StudioZ RAX.
u
Ensure that all Intergraph equipment has the necessary mounting hardware and other associated
items as described in each section. If any items are missing, contact the local support office
immediately to obtain the missing items.
u
Retain all packaging materials. To return equipment for repair, the customer must return it in the
original packaging to obtain warranty service (if provided by their contract agreement).
WARNING If using non-Intergraph cables with the system, ensure that they are shielded and terminated on
both ends.

Safety Precautions

InterServe and StudioZ RAX Base Unit

u
The base unit is subject to high leakage current, and must be properly grounded. To assure proper
grounding, connect the base unit power cord only to the designated outlet on the AC distribution
box or Uninterruptible Power Supply (UPS).
u
The base unit weighs 125 pounds (57 kg) without RAID disk drives. Two people must lift the base
unit when removing it from the pallet and installing it into the rack.

Intergraph 19-inch Rack

WARNING The Intergraph rack is intended for use only with Underwriter's Laboratories Listed rack-
mountable accessories which meet the criteria below and are suitable for use in a 26 C ambient
temperature.
u
Fixed devices may not weigh more than 20 pounds (9.0 kg) per vertical U (1.75 inches). The
center of gravity of fixed devices must not be deeper than 15.0 inches (38.1 cm) inside the rack.
u
Slide rail devices (between 5 U and 11 U) may not weigh more than 13.6 pounds (6.2 kg) per U.
These devices may not be extended more than 31.5 inches (78.8 cm) and their center of gravity
must not extend beyond 16.5 inches (49.1 cm).
u
Slide rail devices (less than 5 U) may not weight more than 20 pounds (9.0 kg) per U. These
devices may not be extended more than 24 inches (61 cm) and their center of gravity must not
extend beyond 13 inches (33 cm).
u
If more than one slide rail device is installed, only one device may be extended at a time. Should
you need access to a device while another is extended, push the extended device back into the rack
before extending the next device.
WARNING Extending more than one device at a time could cause the rack to fall forward, causing damage
to the equipment and injuring anyone standing in front of the rack.
