7. Using an adjustable wrench, tighten the Post
Knob (11) into the Frame (1).
Next, loosen the Post Knob (11) a few turns, pull
it outward, and insert the Seat Post (5) into the
Frame (1).
Slide the Seat Post (5) upward or downward to
the desired position, and release the Post Knob
(11) into one of the adjustment holes in the Seat
Post. Move the Seat Post upward or down-
ward slightly to make sure that the Post Knob
is engaged in one of the adjustment holes in
the Seat Post. Then, tighten the Post Knob.
8. Attach the Water Bottle Holder (49) to the
Upright (3) with two M4 x 22mm Screws (54).
7
5
1
8
9
11
49
3
54
